Green Micro ATX motherboard with silver steel heatsinks and black PCB

ASRock

ASRock B460M STEEL LEGEND LGA 1200 Intel motherboard

SKU CH-NPBV-0M0NW

Micro-ATX board for 10th Gen Intel Core, four DDR4 slots up to 2933 MT/s, dual M.2 and six SATA 6.0 Gb/s ports

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core Processors (Socket 1200)
  • Supported CPU TechnologiesTurbo Boost Technology 3.0
  • ChipsetIntel B460
  • Onboard Video ChipsetHardware Accelerated Codecs: AVC/H.264, HEVC/H.265 8bit, HEV
  • Number of Memory Slots4x288pin (DDR4)
  • Supports 10th Gen Intel Core processors on LGA 1200 socket
  • Intel B460 chipset delivers stable platform features for mainstream builds
  • Four DDR4 slots accept up to 128 GB dual-channel memory at speeds to 2933 MHz
  • Two PCIe 3.0 x16 slots plus two Ultra M.2 sockets for graphics and fast storage
  • Realtek ALC1200 codec provides 7.1-channel high-definition audio

ASRock B460M STEEL LEGEND Intel Motherboard

This Micro ATX board uses the Intel B460 chipset and an LGA 1200 socket for 10th generation Core processors. It provides four DDR4 slots, dual-channel architecture and a 128GB maximum capacity. Two PCI Express 3.0 x16 slots and two Ultra M.2 sockets handle graphics and fast storage.

LGA 1200 socket for 10th Gen Intel Core

The LGA 1200 socket is the single specification that determines compatibility. Only 10th generation Intel Core i9, i7, i5, i3, Pentium and Celeron processors fit this socket and work with the B460 chipset. Earlier or later generation CPUs will not install or boot on this motherboard.

Steady operation with 10th Gen Intel Core

Under sustained load the board delivers power through a 10-phase VRM design and alloy chokes to maintain stable voltage. Steel-reinforced PCIe slots and M.2 heatsinks reduce thermal throttling during long rendering or compile sessions. The Realtek ALC1200 codec keeps 7.1 channel audio clean without added noise.

Highlights

  • Supports 10th Gen Intel Core processors on LGA 1200 socket
  • Intel B460 chipset delivers stable platform features for mainstream builds
  • Four DDR4 slots accept up to 128 GB dual-channel memory at speeds to 2933 MHz
  • Two PCIe 3.0 x16 slots plus two Ultra M.2 sockets for graphics and fast storage
  • Realtek ALC1200 codec provides 7.1-channel high-definition audio

Specifications

BrandASRock
ModelB460M STEEL LEGEND
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core Processors (Socket 1200)
Supported CPU TechnologiesTurbo Boost Technology 3.0
ChipsetIntel B460
Onboard Video ChipsetHardware Accelerated Codecs: AVC/H.264, HEVC/H.265 8bit, HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2, MJPEG, VC-1**
Graphics, Media & Compute: Microsoft DirectX 12, OpenGL 4.5, Intel Built In Visuals, Intel Quick Sync Video, Hybrid / Switchable Graphics, OpenCL 2.1
Display & Content Security: Rec. 2020 (Wide Color Gamut), Microsoft PlayReady 3.0, Intel SGX Content Protection, UHD/HDR Blu-ray Disc
Dual graphics output: support HDMI and DisplayPort 1.4 ports by independent display controllers
Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz
Supports Displa
Number of Memory Slots4x288pin (DDR4)
Memory StandardSupports DDR4 2933/ 2800/ 2666/ 2400/ 2133 non-ECC, un-buffered memory*
* Please refer to Memory Support List on ASRock's website for more information.
* Core (i9/i7) support DDR4 up to 2933; Core (i5/i3), Pentium and Celeron support DDR4 up to 2666.
Maximum Memory Supported128GB
** Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation.
Channel SupportedDual Channel
PCI Express 3.0 x162 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3: single at x16 (PCIE1); dual at x16 (PCIE1) / x4 (PCIE3))*
* Supports NVMe SSD as boot disks
PCI Express x11 x PCI Express 3.0 x1 Slot
Other Slots1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module
Serial ATA (SATA)6 x SATA3 6.0Gb/s Connectors, support RAID, NCQ, AHCI and Hot Plug*
* If M2_2 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled.
M.21 x Ultra M.2 Socket (M2_1), supports M Key type 2242/2260/2280 M.2 PCI Express module up to Gen3 x4 (32Gb/s)**
1 x Ultra M.2 Socket (M2_2), supports M Key type 2260/2280 M.2 SATA3 6.0Gb/s module and M.2 PCI Express module up to Gen3 x4 (32Gb/s)**
** Supports Intel Optane Technology (M2_1)
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit
Intel Optane ReadyYes
SATA RAIDRAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 17
Audio ChipsetRealtek ALC1200
Audio Channels7.1 Channels
LAN ChipsetDragon RTL8125BG
Max LAN Speed2.5Gbps
Back I/O Ports1 x Antenna Bracket
1 x PS/2 Mouse/Keyboard Port
1 x HDMI Port
1 x DisplayPort 1.4
1 x Optical SPDIF Out Port
2 x USB 2.0 Ports (Supports ESD Protection)
4 x USB 3.2 Gen1 Type-A Ports (Supports ESD Protection)
1 x USB 3.2 Gen1 Type-C Port (Supports ESD Protection)
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks)
Onboard USB2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)
Other Connectors1 x SPI TPM Header
1 x Chassis Intrusion and Speaker Header
1 x RGB LED Header*
2 x Addressable LED Headers**
1 x CPU Fan Connector (4-pin)***
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****
4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****
1 x Front Panel Audio Connector
1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 3 AIC R2.0 Card only)
* Supports in total up to 12V/3A, 36W LED Strip.
** Support in total up to 5V/3A, 15W LED Strip.
*** The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
***
Windows 11Supported
Form FactorMicro ATX
LED LightingRGB
Dimensions (W x L)9.6" x 9.6"
Power Pin1 x 24-pin ATX Power Connector (Hi-Density Power Connector)
1 x 8-pin 12V Power Connector (Hi-Density Power Connector)

Questions about this item

What does the DDR4 2933 MHz rating mean once the board is installed?

Core i9 and i7 processors can run memory at 2933 MHz; Core i5, i3, Pentium and Celeron are limited to 2666 MHz. The board has four 288-pin slots supporting up to 128 GB in dual-channel mode.

How does the PCIe 3.0 interface affect the Ultra M.2 slot speed?

The primary Ultra M.2 socket (M2_1) runs at PCIe 3.0 x4, giving a theoretical 32 Gb/s bandwidth for NVMe SSDs. The second Ultra M.2 socket (M2_2) shares bandwidth with SATA3_0 when a SATA-type M.2 drive is used.

What physical space and mounting does the Micro ATX board need?

The board uses the Micro ATX form factor with an LGA 1200 socket, four DDR4 DIMM slots, two PCIe 3.0 x16 slots (single x16 or dual x16/x4), one PCIe 3.0 x1 slot, two M.2 sockets (2242/2260/2280 and 2260/2280), and six SATA3 connectors.
