Green micro-ATX motherboard with black sockets and silver heatsinks

ASRock

ASRock B560M-C Intel motherboard

SKU CH-6XW8-QVCMC MPN B560M-C

Micro-ATX board for 10th- and 11th-gen Intel CPUs with DDR4 up to 4800 MHz, HDMI, SATA 6.0 Gb/s, Gigabit LAN, Bluetooth 4.2 and Wi-Fi 802.11

  • Supports 10th and 11th Gen Intel Core processors on LGA1200 socket
  • Up to 128 GB DDR4 memory across four slots with overclocked speeds to 4800 MHz
  • SATA 6.0 Gb/s with RAID 0, 1, 10 for flexible storage arrays
  • Intel I219V Gigabit LAN plus Wi-Fi 802.11ac and Bluetooth 4.2 for wired and wireless connectivity
  • Realtek ALC897 audio codec plus RGB and addressable LED headers for sound and lighting control

Socket LGA1200 micro-ATX board

The ASRock B560M-C is a micro-ATX motherboard built around the Intel B560 chipset for socket LGA1200 processors. It supports 10th and 11th generation Intel Core CPUs and provides four DDR4 slots with a maximum capacity of 128 GB. The board targets builders who need a compact foundation for a desktop system.

Connectors and lighting headers

Rear I/O includes HDMI, USB 2.0, USB 3.2 Gen1 and a Gigabit LAN port driven by the Intel I219V controller. Internal headers supply three USB 2.0 headers for up to six ports, one USB 3.2 Gen1 header, two RGB and two addressable LED headers, plus dedicated CPU, water-pump and chassis fan connectors with smart speed control. A SPI TPM header and chassis intrusion header are also present. Buyers who need built-in Wi-Fi or Bluetooth 4.2 must add a compatible Intel module themselves.

Thermals and power delivery

The 8-pin Hi-Density 12 V connector feeds the CPU voltage regulators while the 24-pin ATX connector powers the rest of the board. Fan headers support PWM control so chassis and CPU fans can run quietly under light loads and ramp up when temperatures rise. Realtek ALC897 audio handles onboard sound. Builders who require higher overclocking headroom or more robust VRM cooling should consider boards with larger power phases.

Highlights

  • Supports 10th and 11th Gen Intel Core processors on LGA1200 socket
  • Up to 128 GB DDR4 memory across four slots with overclocked speeds to 4800 MHz
  • SATA 6.0 Gb/s with RAID 0, 1, 10 for flexible storage arrays
  • Intel I219V Gigabit LAN plus Wi-Fi 802.11ac and Bluetooth 4.2 for wired and wireless connectivity
  • Realtek ALC897 audio codec plus RGB and addressable LED headers for sound and lighting control

Specifications

No published specifications for this item yet.

Questions about this item

What SATA speed does the B560M-C provide for storage drives?

The board uses SATA 3 at 6.0 Gb/s for its storage interface, so connected SSDs or hard drives are capped at that bus speed.

Which CPU power connector is required for the LGA1200 socket?

An 8-pin 12V Hi-Density power connector is fitted on the board; the matching cable from the PSU must be plugged in for the processor to receive power.

How is the Intel Wi-Fi module installed and what step is often missed?

The module fits into the board's M.2 Key-E slot and needs its two antenna cables attached before the bracket is screwed down; forgetting the cables leaves wireless non-functional.
