Green micro-ATX board with silver heatsinks and black slots

ASRock

ASRock B560M PRO4 LGA 1200 Intel motherboard

SKU CH-DCP3-031E5

Micro-ATX LGA 1200 board for 10th and 11th Gen Intel Core with four DDR4 slots up to 128 GB, PCIe 4.0 x16, dual M.2, six SATA 6Gb/s, 1 GbE and 7.1 audio

  • CPU Socket TypeLGA 1200
  • Supported CPU TechnologiesTurbo Boost Technology 3.0
  • ChipsetIntel B560
  • Onboard Video ChipsetSupported only by CPU with integrated graphic
  • Number of Memory Slots4x288pin (DDR4)
  • Memory StandardDDR4 4800+(OC) (11th Gen Intel Core Processors)* DDR4 4600+(
  • Supports 10th and 11th Gen Intel Core CPUs via LGA 1200 socket
  • Four 288-pin DDR4 slots reach 4800 MT/s on 11th Gen and 4600 MT/s on 10th Gen
  • PCIe 4.0 x16 and Hyper M.2 Gen4x4 up to 64 Gb/s with 11th Gen processors
  • Dual Ultra M.2 sockets plus six SATA 6 Gb/s ports for mixed NVMe and SATA storage
  • Intel I219-V 1 Gbps LAN and Realtek ALC897 7.1-channel audio built in

Socket and generation

The ASRock B560M PRO4 uses the LGA 1200 socket and the Intel B560 chipset to support 10th and 11th generation Intel Core processors. It provides four DDR4 memory slots with a maximum capacity of 128 GB in dual-channel mode.

Memory and CPU pairing

With an 11th generation Core i9, i7 or i5 the board runs DDR4 up to 4800 MT/s overclocked, while the same CPUs at stock operate at 2933 MT/s. Tenth generation Core i9, i7 and i5 reach 4600 MT/s overclocked; Core i3, Pentium and Celeron are limited to 2666 MT/s.

Expansion layout and daily use

A PCIe 4.0 x16 slot and a PCIe 3.0 x16 slot sit alongside a single PCIe 3.0 x1 slot for add-in cards. The Hyper M.2 socket (M2_1) accepts 2242, 2260 or 2280 PCIe Gen4 x4 NVMe drives when an 11th generation CPU is installed. The Ultra M.2 socket (M2_2) and six SATA 6 Gb/s ports handle additional storage; if a SATA-type M.2 device occupies M2_2, the first SATA port is disabled. An M.2 Key E slot (2230) supports CNVi Wi-Fi modules. Audio is driven by a Realtek ALC897 codec with 7.1-channel output, and networking uses an Intel I219-V 1 Gbps LAN controller.

Highlights

  • Supports 10th and 11th Gen Intel Core CPUs via LGA 1200 socket
  • Four 288-pin DDR4 slots reach 4800 MT/s on 11th Gen and 4600 MT/s on 10th Gen
  • PCIe 4.0 x16 and Hyper M.2 Gen4x4 up to 64 Gb/s with 11th Gen processors
  • Dual Ultra M.2 sockets plus six SATA 6 Gb/s ports for mixed NVMe and SATA storage
  • Intel I219-V 1 Gbps LAN and Realtek ALC897 7.1-channel audio built in

Specifications

BrandASRock
ModelB560M PRO4
CPU Socket TypeLGA 1200
Supported CPU TechnologiesTurbo Boost Technology 3.0
ChipsetIntel B560
Onboard Video ChipsetSupported only by CPU with integrated graphic
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 4800+(OC) (11th Gen Intel Core Processors)*
DDR4 4600+(OC) (10th Gen Intel Core Processors)*
* 11th Gen Intel Core (i9/i7/i5) support DDR4 up to 2933; Core (i3), Pentium and Celeron support DDR4 up to 2666.
* 10th Gen Intel Core (i9/i7) support DDR4 up to 2933; Core (i5/i3), Pentium and Celeron support DDR4 up to 2666.
Maximum Memory Supported128GB
Channel SupportedDual Channel
PCI Express 4.0 x161 x PCI Express 4.0 x16*
* Actual support may vary by CPU.
* Supports NVMe SSD as boot disks.
PCI Express 3.0 x161 x PCI Express 3.0 x16*
* Supports NVMe SSD as boot disks.
PCI Express x11 x PCI Express 3.0 x1
Other Slots1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVi (Integrated WiFi/BT)
Serial ATA (SATA)6 x SATA 6Gb/s*
* If M2_2 is occupied by a SATA-type M.2 device, SATA3_1 will be disabled.
M.21 x Hyper M.2 Socket (M2_1), supports M Key type 2242/2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (Socket M2_1 works with 11th Gen Intel Core processors only) *
1 x Ultra M.2 Socket (M2_2), supports M Key type 2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)*
* Supports NVMe SSD as boot disks.
* Supports ASRock U.2 Kit.
Audio ChipsetRealtek ALC897
Audio Channels7.1 Channels
LAN ChipsetIntel I219-V
Max LAN Speed1Gbps
Back I/O Ports1 x PS/2 Mouse/Keyboard Port
1 x HDMI Port
1 x DisplayPort 1.4
4 x USB 3.2 Gen1 Ports (Supports ESD Protection)
2 x USB 2.0 Ports (Supports ESD Protection)
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
HD Audio Jacks: Line in / Front Speaker / Microphone
Onboard USB2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)
1 x Front Panel Type C USB 3.2 Gen1 Header (Supports ESD Protection)
Other Connectors1 x SPI TPM Header
1 x Chassis Intrusion and Speaker Header
2 x RGB LED Headers*
2 x Addressable LED Headers**
1 x CPU Fan Connector (4-pin)***
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****
3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****
1 x Front Panel Audio Connector
1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 4 AIC Card)
* Support in total up to 12V/3A, 36W LED Strip.
** Support in total up to 5V/3A, 15W LED Strip.
*** The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
**** The CPU/
Windows 11Supported
Form FactorMicro ATX
LED LightingRGB
Dimensions (W x L)9.6" x 9.6"
Power Pin1 x 24-pin ATX Power Connector
1 x 8-pin 12V Power Connector (Hi-Density Power Connector)
FeaturesUnique Feature:
ASRock Super Alloy
- Premium 50A Power Choke
- Sapphire Black PCB
- High Density Glass Fabric PCB
ASRock Intel 4-Layer Memory POOL (Planes on Outer Layers) Technology
ASRock Steel Slot
ASRock Full Coverage M.2 Heatsink
ASRock Hyper M.2 (PCIe Gen4x4)
ASRock POST Status Checker (PSC)
ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
ASRock Live Update & APP Shop
BIOS:
- 128Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- CPU Core/Cache, GT, DRAM, VPPM, VCCIN AUX, VCCSA,VCCIO Multi-adjustment
Softw
Package ContentsAccessories:
Quick Installation Guide, Support CD, I/O Shield
2 x SATA Data Cables
3 x Screws for M.2 Sockets
1 x Standoff for M.2 Socket

Questions about this item

What comes in the box and what must I buy separately for the B560M PRO4?

The board ships with the motherboard itself, an I/O shield, SATA cables, and a quick-install guide. You must supply an LGA 1200 processor, DDR4 memory modules, storage drives, a power supply, and a case.

Which memory speed should I choose for an 11th Gen versus a 10th Gen CPU on this board?

With an 11th Gen Core i9/i7/i5 the board supports DDR4 up to 4800+(OC) and native 2933; with a 10th Gen Core it supports DDR4 up to 4600+(OC) and native 2666. Match the kit to your processor generation.

What does the 64 Gb/s Hyper M.2 slot mean for real-world SSD performance?

The M2_1 slot runs at PCIe 4.0 x4 (64 Gb/s) but only when an 11th Gen processor is installed; with a 10th Gen CPU it falls back to PCIe 3.0 speeds. An NVMe drive will still work, just at the lower bandwidth.
