Green micro ATX motherboard with silver PCIe slots and black memory sockets

ASRock

ASRock B760M-C/D4 (BULK) Intel motherboard

SKU CH-94MF-D0MT2 MPN B760M-C/D4 (BULK)

Micro-ATX board for Intel Core 12th, 13th and 14th Gen CPUs with four DDR4 slots up to 128 GB, one PCIe 4.0 x16 slot, two Gen4 M.2 sockets, four SATA ports and Intel I219-V LAN

  • CPU Socket TypeLGA 1700
  • CPU TypeIntel Core 12th Gen (LGA 1700) / Intel Core 13th Gen (LGA 17
  • ChipsetIntel B760
  • Number of Memory Slots4x288pin (DDR5)
  • Memory StandardDDR4 3200 / DDR4 4000 / DDR4 4266 / DDR4 4400 / DDR4 5333
  • Maximum Memory Supported128GB
  • Supports Intel Core 12th, 13th and 14th Gen CPUs on LGA 1700
  • Four DDR4 slots run up to 5333 MHz with XMP 2.0 profiles
  • PCIe 4.0 x16 slot plus two Gen4 M.2 sockets for fast GPUs and SSDs
  • Four SATA 6 Gb/s ports with RAID 0, 1, 5 and 10 support
  • Intel I219-V LAN and Realtek ALC897 7.1 channel audio built in

Socket LGA 1700 Micro ATX Board

The ASRock B760M-C/D4 is a Micro ATX motherboard built around the Intel B760 chipset for Socket LGA 1700 processors. It accepts Intel Core 12th, 13th and 14th generation CPUs and provides four DDR4 memory slots with dual-channel support up to 128 GB. The board includes one PCIe 4.0 x16 slot, three PCIe 3.0 x1 slots and two M.2 sockets for Gen4 NVMe SSDs.

DDR4 Memory With XMP 2.0

This board suits builders who want to reuse existing DDR4 modules or buy affordable high-frequency DDR4 kits up to 5333 MT/s via Intel XMP 2.0. It also supports ECC UDIMMs running in non-ECC mode for added data integrity. Users who require native DDR5 memory must choose a different model because the four slots are wired for DDR4 only.

Two Gen4 M.2 Sockets

The deciding specification is the pair of M.2 Key M sockets both wired for PCIe 4.0 x4 (64 Gb/s), one connected to the CPU and one to the chipset, each accepting 2242, 2260 or 2280 form factors. If a build needs two full-speed Gen4 NVMe drives this board delivers that; if only a single M.2 slot is required a simpler board may suffice.

Highlights

  • Supports Intel Core 12th, 13th and 14th Gen CPUs on LGA 1700
  • Four DDR4 slots run up to 5333 MHz with XMP 2.0 profiles
  • PCIe 4.0 x16 slot plus two Gen4 M.2 sockets for fast GPUs and SSDs
  • Four SATA 6 Gb/s ports with RAID 0, 1, 5 and 10 support
  • Intel I219-V LAN and Realtek ALC897 7.1 channel audio built in

Specifications

BrandASRock
ModelB760M-C/D4 (BULK)
CPU Socket TypeLGA 1700
CPU TypeIntel Core 12th Gen (LGA 1700) / Intel Core 13th Gen (LGA 1700) / Intel Core 14th Gen (LGA 1700)
ChipsetIntel B760
Number of Memory Slots4x288pin (DDR5)
Memory StandardDDR4 3200 / DDR4 4000 / DDR4 4266 / DDR4 4400 / DDR4 5333
Maximum Memory Supported128GB
Channel SupportedDual Channel
Memory Performance ProfileIntel XMP 2.0
Memory FeatureSupports DDR4 non-ECC, un-buffered memory up to 5333+(OC)*
Supports ECC UDIMM memory modules (operate in non-ECC mode)
1DPC 1R Up to 5333+ MHz (OC), 3200 MHz Natively.
1DPC 2R Up to 4400+ MHz (OC), 3200 MHz Natively.
2DPC 1R Up to 4266+ MHz (OC), 3200 MHz Natively.
2DPC 2R Up to 4000+ MHz (OC), 3200 MHz Natively.
PCI Express 4.0 x16CPU:
- 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*
PCI Express 3.0 x16Chipset:
- 1 x PCIe 3.0 x16 Slot (PCIE2), supports x1 mode*
- 1 x PCIe 3.0 x16 Slot (PCIE3), supports x1 mode*
- 1 x PCIe 3.0 x16 Slot (PCIE4), supports x1 mode*
* Supports NVMe SSD as boot disks
Other Slots1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVio/CNVio2 (Integrated WiFi/BT)
Serial ATA (SATA)4 x SATA 6Gb/s
M.2CPU:
- 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode*
Chipset:
- 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
* Supports Intel Volume Management Device (VMD)
Supports NVMe SSD as boot disks
SATA RAIDSupports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Audio ChipsetRealtek ALC897
Audio Channels7.1 Channels
LAN ChipsetIntel I219-V
Max LAN Speed1Gbps
Wireless LANWi-Fi 802.11 ac
BluetoothYes
Back I/O Ports1 x HDMI / 1 x LAN (RJ45) / 1 x PS/2 Keyboard/Mouse Combo / 2 x Antenna Bracket / 3 x Audio Jacks / 4 x USB 2.0/1.1 / 4 x USB 3.2 Gen 1
Onboard USB2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
1 x Front Panel Type C USB 3.2 Gen1 Header
Other Connectors1 x SPI TPM Header
1 x Chassis Intrusion and Speaker Header
1 x RGB LED Header*
3 x Addressable LED Headers**
1 x CPU Fan Connector (4-pin)***
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****
3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****
1 x Front Panel Audio Connector
* Supports in total up to 12V/3A, 36W LED Strip
** Support in total up to 5V/3A, 15W LED Strip
*** CPU_FAN1 supports the fan power up to 1A (12W).
**** CPU_FAN2/WP supports the fan power up to 2A (24W).
***** CHA_FAN1~3/WP support the fan power up to 2A (24W).
CPU_FA
BIOS Feature128Mb AMI UEFI Legal BIOS with GUI support
SoftwareSoftware
- ASRock Motherboard Utility (A-Tuning)
- ASRock Polychrome SYNC
UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Auto Driver Installer
- ASRock Instant Flash
*These utilities can be downloaded from ASRock Live Update & APP Shop.
Form FactorMicro ATX
Dimensions (W x L)9.6" x 9.6"
Power Pin1 x 24 pin ATX Power Connector
1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
Shipping weight0.70 kg
Package size254 × 254 × 25 mm

Questions about this item

What does the DDR4 5333 OC rating mean for actual memory speed on this board?

The board can run DDR4 up to 5333 MHz when overclocked with XMP 2.0, but native speed is 3200 MHz.

How does the PCIe 4.0 x16 slot from the CPU differ from the chipset x16 slots?

The primary PCIE1 slot runs at PCIe 4.0 x16 for a graphics card, while the three chipset slots are PCIe 3.0 x1 electrically.

What M.2 drive lengths do the two Hyper M.2 sockets accept?

The CPU-connected M2_1 socket takes 2242, 2260 and 2280 drives; the chipset M2_2 socket takes 2280 drives.
