Micro ATX motherboard dark PCB silver heatsinks four DDR5 slots WiFi antennas

ASRock

ASRock B760M Pro RS WiFi Intel motherboard

SKU CH-E7FN-TN6KQ MPN B760M Pro RS WiFi

Micro ATX board for LGA 1700 Intel Core 12th, 13th and 14th Gen CPUs with DDR5 up to 7200 MHz, PCIe 5.0 x16, three Gen4 M.2 slots, 2.5 GbE and Wi-Fi 802.11 ax

  • CPU Socket TypeLGA 1700
  • CPU TypeIntel Core 12th Gen (LGA 1700) / Intel Core 13th Gen (LGA 17
  • ChipsetIntel B760
  • Number of Memory Slots4x288pin (DDR5)
  • Memory StandardUp to 7200+(OC)
  • Maximum Memory Supported256GB
  • Supports 12th, 13th and 14th Gen Intel Core processors via LGA 1700 socket
  • 7+1+1 Dr.MOS power phases deliver stable voltage to CPU cores and graphics
  • Four DDR5 slots reach 7200 MHz OC with Intel XMP 3.0 for high-speed memory
  • PCIe 5.0 x16 plus three Gen4 M.2 sockets give fast GPU and storage expansion
  • 5 Gbps LAN and Wi-Fi 802.11 ax provide quick wired and wireless networking

LGA 1700 Micro ATX Board for 12th-14th Gen Intel

The ASRock B760M Pro RS WiFi fits Intel Core 12th, 13th and 14th Gen processors on an LGA 1700 socket. The Intel B760 chipset provides four DDR5 DIMM slots with dual-channel support up to 256 GB capacity. Integrated 2.5 Gbps LAN and Wi-Fi 802.11 ax handle networking without extra cards.

Ideal for Compact DDR5 Builds, Not Multi-GPU

This board suits builders who want a compact Micro ATX platform with three Gen4 M.2 sockets and a single PCIe 5.0 x16 slot for one graphics card. The second x16 slot runs at x4 electrical, so multi-GPU configurations are not practical. Users needing more than four SATA ports or legacy PCI slots should look elsewhere.

PCIe 5.0 x16 Slot Decides GPU Bandwidth

The primary PCIE1 slot delivers PCIe 5.0 x16 bandwidth to the graphics card, while the secondary PCIE2 slot operates at PCIe 3.0 x4. That single high-speed lane determines whether a modern GPU can run at its full link speed on this platform.

Highlights

  • Supports 12th, 13th and 14th Gen Intel Core processors via LGA 1700 socket
  • 7+1+1 Dr.MOS power phases deliver stable voltage to CPU cores and graphics
  • Four DDR5 slots reach 7200 MHz OC with Intel XMP 3.0 for high-speed memory
  • PCIe 5.0 x16 plus three Gen4 M.2 sockets give fast GPU and storage expansion
  • 5 Gbps LAN and Wi-Fi 802.11 ax provide quick wired and wireless networking

Specifications

BrandASRock
ModelB760M PRO RS WiFi
CPU Socket TypeLGA 1700
CPU TypeIntel Core 12th Gen (LGA 1700) / Intel Core 13th Gen (LGA 1700) / Intel Core 14th Gen (LGA 1700)
ChipsetIntel B760
Number of Memory Slots4x288pin (DDR5)
Memory StandardUp to 7200+(OC)
Maximum Memory Supported256GB
Channel SupportedDual Channel
Memory Performance ProfileIntel XMP 3.0
Memory FeatureSupports DDR5 non-ECC, un-buffered memory up to 7200+(OC)*
*1DPC 1R Up to 7200+ MHz (OC), 4800 MHz Natively.
1DPC 2R Up to 6000+ MHz (OC), 4400 MHz Natively.
2DPC 1R Up to 5600+ MHz (OC), 4000 MHz Natively.
2DPC 2R Up to 4800+ MHz (OC), 3600 MHz Natively.
PCI Express 5.0 x161 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*
PCI Express 3.0 x161 x PCIe 3.0 x16 Slot (PCIE2), supports x4 mode*
* Supports NVMe SSD as boot disks
Serial ATA (SATA)4 x SATA 6Gb/s
M.2CPU:
- 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode*
Chipset:
- 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
- 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
* Supports Intel Volume Management Device (VMD)
Supports NVMe SSD as boot disks
SATA RAID0/1/5/10
Audio ChipsetRealtek ALC897
Audio Channels7.1 Channels
Max LAN Speed2.5Gbps
Wireless LANWi-Fi 802.11 ax
BluetoothBluetooth 5.3
Back I/O Ports2 x Antenna Ports
1 x PS/2 Mouse/Keyboard Port
1 x HDMI Port
1 x DisplayPort 1.4
1 x USB 3.2 Gen1 Type-C Port
3 x USB 3.2 Gen1 Type-A Ports
2 x USB 2.0 Ports
1 x RJ-45 LAN Port
HD Audio Jacks: Line in / Front Speaker / Microphone
Onboard USB1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 4 AIC Card)
2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
1 x Front Panel Type C USB 3.2 Gen1 Header
Other Connectors1 x SPI TPM Header
1 x Chassis Intrusion and Speaker Header
1 x RGB LED Header*
3 x Addressable LED Headers**
1 x CPU Fan Connector (4-pin)***
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****
4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****
* Supports in total up to 12V/3A, 36W LED Strip
** Support in total up to 5V/3A, 15W LED Strip
*** CPU_FAN1 supports the fan power up to 1A (12W).
**** CPU_FAN2/WP supports the fan power up to 2A (24W).
***** CHA_FAN1~4/WP support the fan power up to 2A (24W).
CPU_FAN2/WP and CHA_FAN1~4/WP can auto
BIOS Feature128Mb AMI UEFI Legal BIOS with GUI support
SoftwareSoftware
- ASRock Motherboard Utility (A-Tuning)
- ASRock Dragon 2.5G LAN Software
- Killer Control Center
- ASRock Polychrome SYNC
UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Auto Driver Installer
- ASRock Instant Flash
- ASRock Easy RAID Installer
Form FactorMicro ATX
Dimensions (W x L)9.6" x 9.6"
Power Pin24 Pin
FeaturesSuperb Productivity
- PCIe Gen5 (Graphics)
- Dual Channel DDR5
Rock-Solid Durability
- 7+1+1 Power Phase, Dr.MOS for VCore+GT
- Pre-Installed I/O Shield
Ultrafast Connectivity
- 2.5G LAN, Killer 802.11axe Wi-Fi 6E Module
EZ Update
- ASRock Auto Driver Installer
EZ Troubleshooter
- ASRock Post Status Checker
Package Contents1 x User Manual
2 x SATA Data Cables
2 x ASRock WiFi 2.4/5/6 GHz Antennas
3 x Screws for M.2 Sockets
1 x Standoff for M.2 Socket
Shipping weight1.13 kg
Package size279 × 267 × 64 mm

Questions about this item

What is in the box and what has to be bought separately?

The board ships with the motherboard, an I/O shield, SATA cables and documentation. A DDR5 memory kit, an LGA 1700 CPU, a PCIe 5.0 graphics card, M.2 SSDs and a power supply must be purchased separately.

Which M.2 socket should I use for the fastest NVMe drive?

The CPU-connected M2_1 socket runs at PCIe 4.0 x4 (64 Gb/s) and accepts 2242, 2260 and 2280 drives, making it the primary slot for a boot NVMe SSD.

What does the 7200+ MHz OC rating mean once the board is in a real machine?

With a single-rank DDR5 DIMM in one slot the firmware can push the kit past 7200 MHz; populating two or four slots drops the achievable ceiling to 6000 MHz or 4800 MHz respectively.
