Green ATX motherboard with twelve white PCIe x1 slots and one black PCIe x16 slot

ASRock

ASRock H110 Pro BTC+ LGA 1151 Intel motherboard

SKU CH-1NDP-7JD9W

Designed for cryptocurrency mining with twelve PCI Express 2.0 x1 slots, one PCI Express 3.0 x16 slot, four SATA 6.0Gb/s ports, dual-channel DDR4 memory up to 32 GB and Intel I219-V Gigabit LAN

  • CPU Socket TypeLGA 1151
  • CPU TypeSupports 7th and 6th Generation Intel Core i7/i5/i3 / Pentiu
  • Supported CPU TechnologiesTurbo Boost Technology 2.0
  • ChipsetIntel H110
  • Onboard Video ChipsetSupports Intel HD Graphics Built-in Visuals: Intel Quick Syn
  • Number of Memory Slots2x288pin (DDR4)
  • Supports 7th and 6th Gen Intel Core CPUs via LGA 1151 socket
  • 12 PCI Express 2.0 x1 slots built for multi-GPU mining rigs
  • One PCI Express 3.0 x16 slot accepts NVMe SSD boot drives
  • Dual-channel DDR4 memory up to 2400 MT/s with 32 GB maximum capacity
  • Intel I219-V Gigabit LAN and Realtek ALC887 7.1 CH audio onboard

Mining-focused LGA 1151 board

This ATX motherboard uses the Intel H110 chipset and an LGA 1151 socket to support 6th and 7th Generation Intel Core, Pentium and Celeron processors. It is built specifically for cryptocurrency mining rigs that need many graphics cards.

Simple installation with riser awareness

The board fits a standard ATX case and uses a 24-pin ATX power connector plus a 4-pin CPU connector. Twelve PCI Express 2.0 x1 slots accept powered risers; the single PCI Express 3.0 x16 slot runs at x16 electrically. Ensure each riser has its own power feed to avoid overloading the board traces.

32 GB DDR4 and twelve GPU headroom

Two 288-pin slots take DDR4 2400 or 2133 non-ECC memory up to 32 GB in dual-channel mode. Twelve x1 slots plus one x16 slot give room for thirteen graphics cards, though bandwidth on the x1 links limits high-end GPU throughput. Four SATA3 6.0 Gb/s ports and one M.2 SATA socket handle boot and storage drives.

Highlights

  • Supports 7th and 6th Gen Intel Core CPUs via LGA 1151 socket
  • 12 PCI Express 2.0 x1 slots built for multi-GPU mining rigs
  • One PCI Express 3.0 x16 slot accepts NVMe SSD boot drives
  • Dual-channel DDR4 memory up to 2400 MT/s with 32 GB maximum capacity
  • Intel I219-V Gigabit LAN and Realtek ALC887 7.1 CH audio onboard

Specifications

BrandASRock
ModelH110 Pro BTC+
CPU Socket TypeLGA 1151
CPU TypeSupports 7th and 6th Generation Intel Core i7/i5/i3 / Pentium / Celeron Processors (Socket 1151)* Not Compatible with Intel 8th Gen CPUs
Supported CPU TechnologiesTurbo Boost Technology 2.0
ChipsetIntel H110
Onboard Video ChipsetSupports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD GraphicsGen9 LP, DX11.3, DX12HWA Encode/Decode: VP8, HEVC 8b, VP9, HEVC 10b (For 7th Gen Intel CPU)HWA Encode/Decode: VP8, HEVC 8b; GPU/SW Encode/Decode: VP9, HEVC 10b (For 6th Gen Intel CPU)Max. shared memory 1024MB**Supports DVI-D with max. resolution up to 1920x1200 @ 60HzSupports Accelerated Media Codecs: HEVC, VP8, VP9Supports HDCP with DVI-D PortSupports Full HD 1080p Blu-ray (BD) playback wi
Number of Memory Slots2x288pin (DDR4)
Memory StandardDDR4 2400/ 2133 non-ECC, un-buffered memory* * 7th Gen Intel CPU supports DDR4 up to 2400; 6th Gen Intel CPU supports DDR4 up to 2133.
Maximum Memory Supported32GB* Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation.
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)* * Supports NVMe SSD as boot disk
PCI Express x112 x PCI Express 2.0 x1 Slots
Serial ATA (SATA)4 x SATA3 6.0Gb/s Connectors, support NCQ, AHCI and Hot Plug* * If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled.
M.21 x M.2 Socket, supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0Gb/s module
Audio ChipsetRealtek ALC887
Audio Channels7.1 CH HD Audio* To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.Supports Surge Protection
LAN ChipsetIntel I219-V
Max LAN Speed1Gbps
Back I/O Ports1 x PS/2 Mouse Port1 x PS/2 Keyboard Port1 x DVI-D Port4 x USB 2.0 Ports (Supports ESD Protection)2 x USB 3.1 Gen1 Ports (Supports ESD Protection)1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)HD Audio Jacks: Line in / Front Speaker / Microphone
Onboard USB1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection)
Other Connectors1 x Print Port Header1 x COM Port Header1 x TPM Header1 x Chassis Intrusion and Speaker Header1 x CPU Fan Connector (4-pin)*2 x Chassis Fan Connectors (4-pin)2 x PCIe Power Connectors1 x SATA Power Connector1 x Front Panel Audio Connector* The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
Windows 11Supported
Form FactorATX
Dimensions (W x L)12.0" x 8.2"
Power Pin1 x 24 pin ATX Power Connector 1 x 8 pin 12V Power Connector
FeaturesUnique Feature:ASRock Super Alloy- Sapphire Black PCB- High Density Glass Fabric PCBASRock Full Spike Protection (for all USB, Audio, LAN Ports)ASRock Live Update & APP ShopBIOS:- 64MB AMI UEFI Legal BIOS with multilingual GUI support- ACPI 5.0 Compliant wake up events- SMBIOS 2.7 Support- CPU, DRAM, PCH 1.05V Voltage multi-adjustmentSoftware and UEFI:Software- ASRock APP Charger- ASRock XFast LANUEFI- ASRock Instant Flash* These utilities can be downloaded from ASRock Live Update & APP Shop.Support CD:- Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser an
Package ContentsAccessories:- Quick Installation Guide, Support CD, I/O Shield - 2 x SATA Data Cables - 1 x Screw for M.2 Socket

Questions about this item

Will a 7th Generation Intel Core i5 fit the LGA 1151 socket on this board?

Yes, the socket supports 7th and 6th Generation Core i7, i5, i3, Pentium and Celeron processors.

How many graphics cards can I connect using the PCI Express x1 slots?

There are 12 PCI Express 2.0 x1 slots available for riser cards.

What is the maximum system memory I can install with a 64-bit operating system?

The board supports up to 32 GB of DDR4 memory in dual-channel mode.
