Compact green Mini-ITX board, silver CPU socket, four black SATA ports, vertical M.2 slot, dual RAM slots

ASRock

ASRock H310M-ITX/ac Intel motherboard

SKU CH-GP16-D73TS

Mini-ITX Intel H310 board for 8th and 9th gen CPUs, DDR4 2666, dual-channel 32 GB, PCIe 3.0 x16, M.2 2280, 4 SATA3 6.0 Gb/s, Intel I219-V Gigabit LAN, Intel 802.11 ac dual-band Wi-Fi.

  • CPU Socket TypeLGA 1151 (300 Series)
  • CPU TypeSupports 8th Generation Intel Core Processors (Socket 1151)
  • Supported CPU TechnologiesTurbo Boost Technology 2.0
  • ChipsetIntel H310
  • Onboard Video ChipsetSupports Intel UHD Graphics Built-in Visuals: Intel Quick Sy
  • Number of Memory Slots2x288pin (DDR4)
  • Compact Mini ITX form factor fits small builds
  • Supports 8th and 9th generation Intel Core processors on LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB at 2666 MHz
  • M.2 slot with PCIe Gen2 x4 for NVMe SSD boot drives
  • Built-in Intel 802.11 ac Wi-Fi with dual-band 2.4/5 GHz up to 433 Mbps

Compact LGA 1151 platform

The ASRock H310M-ITX/ac is a Mini-ITX motherboard built around the Intel H310 chipset for LGA 1151 (300 Series) processors. It accepts 8th Generation Intel Core CPUs and is not backward compatible with older LGA 1151 chips. The board targets small-form-factor builds that need integrated graphics and wireless connectivity in a tight footprint.

Sustained thermal behaviour

The H310 chipset and compact voltage regulation run within the thermal limits of a Mini-ITX chassis during extended workloads. Turbo Boost 2.0 on supported CPUs operates within the board's power delivery envelope. A single PCI Express 3.0 x16 slot and an M.2 socket supporting PCIe Gen2 x4 (20Gb/s) or SATA3 6.0Gb/s modules keep storage throughput steady without throttling under continuous I/O.

Build and daily connectivity

Four SATA3 6.0Gb/s ports handle multiple drives, though SATA3_0 is disabled if a SATA-type M.2 device occupies the M.2 slot. Rear I/O provides DVI-I, HDMI and DisplayPort 1.2 for up to three displays, with HDMI reaching 4096x2160 @ 30Hz and DisplayPort 1.2 up to 4096x2304 @ 60Hz. Intel I219-V Gigabit LAN and the bundled Intel 802.11 ac Wi-Fi module on a vertical M.2 Key E socket deliver wired and dual-band wireless networking. Realtek ALC887 audio supports 7.1-channel output when paired with a compatible front-panel module.

Highlights

  • Compact Mini ITX form factor fits small builds
  • Supports 8th and 9th generation Intel Core processors on LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB at 2666 MHz
  • M.2 slot with PCIe Gen2 x4 for NVMe SSD boot drives
  • Built-in Intel 802.11 ac Wi-Fi with dual-band 2.4/5 GHz up to 433 Mbps

Specifications

BrandASRock
ModelH310M-ITX/ac
CPU Socket TypeLGA 1151 (300 Series)
CPU TypeSupports 8th Generation Intel Core Processors (Socket 1151)
* Not backward compatible with older generation of LGA 1151 CPUs
Supported CPU TechnologiesTurbo Boost Technology 2.0
ChipsetIntel H310
Onboard Video ChipsetSupports Intel UHD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel UHD Graphics
DirectX 12
HWA Encode/Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1 (Decode only)
Three graphics output options: DVI-I, HDMI and DisplayPort 1.2**
Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 30Hz
Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2304) @ 60Hz
Supports DVI-I with max.
Number of Memory Slots2x288pin (DDR4)
Memory StandardDDR4 2666/ 2400/ 2133
Maximum Memory Supported32GB
* Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation.
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)
* Supports NVMe SSD as boot disks
Other Slots1 x Vertical M.2 Socket (Key E) with the bundled Wi-Fi 802.11 ac module (on the rear I/O)
Serial ATA (SATA)4 x SATA3 6.0Gb/s Connectors, support NCQ, AHCI and Hot Plug*
* If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled.
M.21 x M.2 Socket, supports M Key type 2280 M.2 SATA3 6.0Gb/s module and M.2 PCI Express module up to Gen2 x4 (20Gb/s)**
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit
Audio ChipsetRealtek ALC887
Audio Channels7.1 Channels
* To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
Supports Surge Protection
LAN ChipsetIntel I219-V
Max LAN Speed1Gbps
Wireless LANIntel 802.11 ac Wi-Fi Module
Supports IEEE 802.11 a/b/g/n/ac
Supports Dual-Band (2.4/5 GHz)
Supports high speed wireless connections up to 433 Mbps
BluetoothSupports Bluetooth 4.2 / 3.0 + High speed class II
PS/21 x PS/2 keyboard/mouse port
Video Ports1 x DVI-I Port
HDMI1 x HDMI
RJ451 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
DisplayPort1 x DisplayPort 1.2
USB 3.12 x USB 3.1 Gen1 Ports (Supports ESD Protection)
USB 1.1/2.02 x USB 2.0 Ports (Supports ESD Protection)
Audio PortsHD Audio Jacks: Line in / Front Speaker / Microphone
Antenna Connectors2 x Antenna Ports
Onboard USB1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection)
Other Connectors1 x Chassis Intrusion Header
1 x CPU Fan Connector (4-pin)*
1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
1 x Front Panel Audio Connector
* The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
* The Chassis Fan Connector supports the chassis fan of maximum 1A (12W) fan power.
** The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.
** CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.
Form FactorMini ITX
Dimensions (W x L)6.7" x 6.7"
Power Pin1 x 24-pin ATX Power Connector
1 x 8-pin 12V Power Connector
FeaturesUnique Feature:
ASRock Super Alloy
- Premium 60A Power Choke
- Dual-Stack MOSFET (DSM)
- Sapphire Black PCB
- High Density Glass Fabric PCB
Intel 802.11 ac Wi-Fi
ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
ASRock Live Update & APP Shop
BIOS:
- 128MB AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- CPU, DRAM, PCH 1.0V, VCCST Voltage Multi-adjustment
Software and UEFI:
Software
- ASRock A-Tuning
- ASRock XFast LAN
UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
Package ContentsAccessories:
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables
- 2 x ASRock Wi-Fi 2.4/5 GHz Antennas
- 1 x Screw for M.2 Socket

Questions about this item

How much power does the ASRock H310M-ITX/ac draw under full load with an 8th Gen Core i5 installed?

The board uses the Intel H310 chipset and a 4-phase power design for the LGA 1151 socket, keeping VRM temperatures low during sustained workloads.

Which DDR4 modules must I already have to reach the 32 GB limit on this motherboard?

Two 288-pin DDR4 DIMMs rated at 2666, 2400 or 2133 MT/s are required; the board runs them in dual-channel mode up to 32 GB total.

Will my existing SATA SSD and NVMe drive work together on the M.2 and SATA ports?

Yes, the M.2 slot accepts a 2280 NVMe drive at PCIe Gen2 x4 while four SATA3 6.0 Gb/s ports remain available; if a SATA M.2 device is used, SATA3_0 is disabled.
