Green Micro-ATX board with silver CPU socket, two black DDR4 slots, blue PCIe x16, white PCIe x1, M.2 slot, four SATA ports

ASRock

ASRock H410M-HDV/M.2 Intel motherboard

SKU CH-WT3C-5242E

Micro ATX board for 10th Gen Intel Core CPUs with DDR4 memory, one Ultra M.2 slot, four SATA3 ports and Intel I219-V Gigabit LAN

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core Processors (Socket 1200)
  • Supported CPU TechnologiesTurbo Boost Technology 3.0
  • ChipsetIntel H410
  • Onboard Video ChipsetHardware Accelerated Codecs: AVC/H.264, HEVC/H.265 8bit, HEV
  • Number of Memory Slots2x288pin (DDR4)
  • Supports 10th Gen Intel Core processors on LGA 1200 socket
  • Dual-channel DDR4 memory up to 2933 MT/s with 64 GB capacity
  • Ultra M.2 slot for PCIe Gen3 x4 NVMe or SATA storage
  • Intel I219-V Gigabit LAN controller for wired networking
  • Realtek ALC887 codec delivering 7.1-channel audio output

Socket 1200 micro-ATX board for 10th Gen Intel Core

The ASRock H410M-HDV/M.2 uses the Intel H410 chipset and an LGA 1200 socket to support 10th Generation Intel Core processors. Two 288-pin slots accept DDR4 memory up to 2933 MT/s in dual-channel mode with a maximum capacity of 64 GB. A single PCI Express 3.0 x16 slot and one x1 slot provide basic expansion for graphics or add-in cards.

Thermal and power profile

The H410 chipset runs cool enough for passive cooling in typical office or home builds. The Realtek ALC887 codec handles 7.1-channel audio without a dedicated fan. Intel I219-V Gigabit LAN adds minimal heat. Overall board power draw stays low, suiting compact chassis with modest airflow.

Bundled M.2 and connectivity options

One Ultra M.2 socket (M2_1) accepts M-key 2260 or 2280 modules running at SATA3 6.0 Gb/s or PCI Express 3.0 x4 up to 32 Gb/s. A second M.2 Key E socket (type 2230) is reserved for Wi-Fi or Bluetooth modules. Four SATA3 6.0 Gb/s ports support NCQ, AHCI and hot plug; note that SATA3_0 is disabled when a SATA-type M.2 device occupies M2_1.

Highlights

  • Supports 10th Gen Intel Core processors on LGA 1200 socket
  • Dual-channel DDR4 memory up to 2933 MT/s with 64 GB capacity
  • Ultra M.2 slot for PCIe Gen3 x4 NVMe or SATA storage
  • Intel I219-V Gigabit LAN controller for wired networking
  • Realtek ALC887 codec delivering 7.1-channel audio output

Specifications

BrandASRock
ModelH410M-HDV/M.2
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core Processors (Socket 1200)
Supported CPU TechnologiesTurbo Boost Technology 3.0
ChipsetIntel H410
Onboard Video ChipsetHardware Accelerated Codecs: AVC/H.264, HEVC/H.265 8bit, HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2, MJPEG, VC-1**
Graphics, Media & Compute: Microsoft DirectX 12, OpenGL 4.5, Intel Built In Visuals, Intel Quick Sync Video, Hybrid / Switchable Graphics, OpenCL 2.1
Display & Content Security: Rec. 2020 (Wide Color Gamut), Microsoft PlayReady 3.0, Intel SGX Content Protection, UHD/HDR Blu-ray Disc
Three graphics output options: D-Sub, DVI-D and HDMI* Supports up to 2 displays simultaneously
Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz
Supports DVI-D w
Number of Memory Slots2x288pin (DDR4)
Memory StandardSupports DDR4 2933/ 2800/ 2666/ 2400/ 2133 non-ECC, un-buffered memory*
* Please refer to Memory Support List on ASRock's website for more information.
* Core (i9/i7) support DDR4 up to 2933; Core (i5/i3), Pentium and Celeron support DDR4 up to 2666.
Maximum Memory Supported64GB
** Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation.
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16 Slot*
* Supports NVMe SSD as boot disks
PCI Express x11 x PCI Express 3.0 x1 Slot
Other Slots1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module
Serial ATA (SATA)4 x SATA3 6.0Gb/s Connectors, support NCQ, AHCI and Hot Plug*
* If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled.
M.21 x Ultra M.2 Socket (M2_1), supports M Key type 2260/2280 M.2 SATA3 6.0Gb/s module and M.2 PCI Express module up to Gen3 x4 (32Gb/s)
Audio ChipsetRealtek ALC887
Audio Channels7.1 Channels
LAN ChipsetIntel I219-V
Max LAN Speed1Gbps
Back I/O Ports1 x Antenna Bracket
1 x PS/2 Mouse/Keyboard Port
1 x D-Sub Port
1 x DVI-D Port
1 x HDMI Port
4 x USB 2.0 Ports (Supports ESD Protection)
2 x USB 3.2 Gen1 Ports (Supports ESD Protection)
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
HD Audio Jacks: Line in / Front Speaker / Microphone
Onboard USB2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)
Other Connectors1 x Print Port Header
1 x COM Port Header
1 x SPI TPM Header
1 x Chassis Intrusion and Speaker Header
1 x CPU Fan Connector (4-pin)*
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)***
1 x Front Panel Audio Connector
* The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
** The CPU/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.
*** The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.
*** CPU_FAN2/WP, CHA_FAN1/
Form FactorMicro ATX
Dimensions (W x L)8.9" x 7.4"
Power Pin1 x 24-pin ATX Power Connector
1 x 8-pin 12V Power Connector
FeaturesUnique Feature:
ASRock Super Alloy
- Premium 50A Power Choke
- Sapphire Black PCB
- High Density Glass Fabric PCB
ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)
ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
ASRock Live Update & APP Shop
BIOS:
- 128MB AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- CPU Core/Cache, GT, DRAM, VPPM, PCH 1.05V, VCCST, VCCSA Voltage Multi-adjustment
Software and UEFI:
Software
- ASRock Motherboard Utility (A-Tuning)
- ASRock XFast LAN
UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock M
Package ContentsAccessories:
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables
- 2 x Screws for M.2 Sockets

Questions about this item

How do I install the Ultra M.2 module in the M2_1 slot, and what step do people often miss?

Insert the M Key 2260 or 2280 module at an angle, press it down, and secure it with the screw; the step often missed is that fitting a SATA-type M.2 device disables the SATA3_0 connector.

What maintenance will the Realtek ALC887 audio codec need over time?

The Realtek ALC887 codec itself requires no scheduled maintenance; keep the rear-panel ports dust-free and update audio drivers from ASRock when a new Windows build is installed.

What limit appears first when the Intel I219-V LAN runs at full 1Gbps for long periods?

The 1Gbps link speed of the Intel I219-V controller is the first bottleneck; sustained transfers cannot exceed that throughput regardless of cable or switch quality.
