Green micro-ATX board with silver LGA 1200 socket, two black DDR4 slots, single PCIe x16 slot, four SATA ports

ASRock

ASRock H410M-HVS LGA 1200 Intel H410 Micro ATX motherboard

SKU CH-ZEKT-KP999

Micro ATX board for LGA 1200 CPUs with four SATA ports, dual-channel DDR4 up to 2933, one PCIe 3.0 x16 slot and 7.1 audio

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core Processors
  • Supported CPU TechnologiesTurbo Boost Technology 3.0
  • ChipsetIntel H410
  • Onboard Video ChipsetSupported only by CPU with integrated graphic
  • Number of Memory Slots2x288pin (DDR4)
  • Supports 10th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 2933 MHz with 64 GB maximum capacity
  • PCI Express 3.0 x16 slot enables NVMe SSD boot support
  • Four SATA 6Gb/s ports plus USB 3.2 Gen1 for fast storage and peripherals
  • Realtek ALC887 7.1-channel audio and 1 Gbps LAN for everyday connectivity

Core Purpose

The ASRock H410M-HVS is a Micro ATX motherboard built around the Intel H410 chipset and LGA 1200 socket. It targets 10th Gen Intel Core processors and provides a compact foundation for office or home builds that need basic connectivity and dual-channel DDR4 memory up to 64 GB.

Fit and Alternatives

This board suits users running a Core i3, i5, Pentium or Celeron CPU who need four SATA 6Gb/s ports, a single PCIe 3.0 x16 slot and 7.1-channel audio from the Realtek ALC887 codec. Builders wanting memory speeds above 2666 on non-Core i9/i7 CPUs, multiple PCIe x16 slots, or overclocking headroom should consider a different chipset.

Deciding Spec

The H410 chipset locks memory frequency to 2666 for Core i5, i3, Pentium and Celeron processors, while only Core i9 and i7 models reach 2933. That ceiling is the single figure that determines whether this motherboard matches your CPU choice.

Highlights

  • Supports 10th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 2933 MHz with 64 GB maximum capacity
  • PCI Express 3.0 x16 slot enables NVMe SSD boot support
  • Four SATA 6Gb/s ports plus USB 3.2 Gen1 for fast storage and peripherals
  • Realtek ALC887 7.1-channel audio and 1 Gbps LAN for everyday connectivity

Specifications

BrandASRock
ModelH410M-HVS
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core Processors
Supported CPU TechnologiesTurbo Boost Technology 3.0
ChipsetIntel H410
Onboard Video ChipsetSupported only by CPU with integrated graphic
Number of Memory Slots2x288pin (DDR4)
Memory StandardDDR4 2933 / 2800 / 2666 / 2400 / 2133*
* Core (i9 / i7) support DDR4 up to 2933; Core (i5/i3), Pentium and Celeron support DDR4 up to 2666.
* Please refer to Memory Support List on ASRock's website for more information.
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16*
* Supports NVMe SSD as boot disks.
PCI Express x11 x PCI Express 3.0 x1
Serial ATA (SATA)4 x SATA 6Gb/s
Audio ChipsetRealtek ALC887
Audio Channels7.1 Channels
LAN ChipsetRealtek RTL8111H
Max LAN Speed1Gbps
Back I/O Ports1 x PS/2 Mouse/Keyboard Port
1 x D-Sub Port
1 x HDMI Port
4 x USB 2.0 Ports (Supports ESD Protection)
2 x USB 3.2 Gen1 Ports (Supports ESD Protection)
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
HD Audio Jacks: Line in / Front Speaker / Microphone
Onboard USB1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)
Other Connectors1 x SPI TPM Header
1 x Chassis Intrusion and Speaker Header
1 x CPU Fan Connector (4-pin)*
1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
1 x Front Panel Audio Connector
* The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
** The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.
** CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.
Form FactorMicro ATX
Dimensions (W x L)7.8" x 7.4"
Power Pin1 x 24-pin ATX Power Connector
1 x 8-pin 12V Power Connector
FeaturesUnique Feature:
ASRock Super Alloy
- Premium 50A Power Choke
- Sapphire Black PCB
- High Density Glass Fabric PCB
ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
ASRock Live Update & APP Shop
BIOS:
- 128 MB AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- CPU Core/Cache, GT, DRAM, PCH +1.0V, VCCST Voltage Multi-adjustment
Software and UEFI:
Software
- ASRock Motherboard Utility (A-Tuning)
- ASRock XFast LAN
UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock
Package ContentsAccessories:
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables

Questions about this item

What speed does the PCI Express 3.0 x16 slot run at on this board?

The slot runs at PCI Express 3.0 x16 speed and supports NVMe SSD boot drives.

What case and power connectors are required to fit this Micro ATX board?

A Micro ATX compatible case, a 24-pin ATX power connector and a 4-pin CPU power connector are needed.

How do I enable the water-pump header in BIOS after plugging in the pump?

Enter BIOS, go to the fan-tuning section, set the CPU fan header to PWM mode and select the water-pump profile.
