Rectangular ATX motherboard with black and silver finish, two DDR5 slots, multiple M.2 heatsinks, and reinforced PCIe slots

ASRock

ASRock X870E Taichi OCF AMD motherboard

SKU CH-VF22-TD7J3 MPN X870E Taichi OCF

Supports Ryzen 7000, 8000 and 9000 series CPUs with DDR5 up to 10400 MT/s, dual PCIe 5.0 x16 slots, six M.2 sockets including two Gen5, 40 Gbps USB4 and Wi-Fi 7

  • CPU Socket TypeAM5
  • CPU TypeRyzen 7000 Series / Ryzen 8000 Series / Ryzen 9000 Series
  • ChipsetAMD X870E
  • Number of Memory Slots2x288pin (DDR5)
  • Memory StandardSupports up to 10400+(OC)
  • Maximum Memory Supported128GB
  • Dual-channel DDR5 reaches 10400+(OC) with two 288-pin slots
  • 128 GB maximum memory capacity for heavy workloads
  • Two PCIe 5.0 x16 slots run at x16 or x8/x8
  • Six M.2 sockets include two PCIe 5.0 x4 2280 slots
  • USB4 Type-C delivers 40 Gbps with Wi-Fi 7 connectivity

Two-DIMM DDR5 platform

The ASRock X870E Taichi OCF is an AM5 ATX motherboard built for Ryzen 7000, 8000 and 9000 series processors. It uses a 1 DIMM per channel layout with two 288-pin slots supporting up to 128 GB of dual-channel DDR5. Enthusiasts gain a clean signal path for extreme memory overclocking via AMD EXPO and Intel XMP 3.0 profiles.

Sustained-load power delivery

The Dr.MOS design with Smart Power Stage technology monitors current and temperature on each phase, delivering smoother power to the CPU during extended workloads. This improves stability when the system runs at high frequency for long periods rather than short bursts. OC buttons provide hardware-level control for extreme overclocking sessions.

Flagship expansion upgrade

Six M.2 slots include two CPU-attached Gen5 x4 sockets for 2280 NVMe drives, adding high-speed storage capacity missing on mainstream boards. USB4 brings 40 Gbps Type-C connectivity and Wi-Fi 7 adds multi-link operation for lower latency. The board replaces lesser chipsets when maximum I/O throughput and memory overclocking headroom are required.

Highlights

  • Dual-channel DDR5 reaches 10400+(OC) with two 288-pin slots
  • 128 GB maximum memory capacity for heavy workloads
  • Two PCIe 5.0 x16 slots run at x16 or x8/x8
  • Six M.2 sockets include two PCIe 5.0 x4 2280 slots
  • USB4 Type-C delivers 40 Gbps with Wi-Fi 7 connectivity

Specifications

BrandASRock
ModelX870E Taichi OCF
CPU Socket TypeAM5
CPU TypeRyzen 7000 Series / Ryzen 8000 Series / Ryzen 9000 Series
ChipsetAMD X870E
Number of Memory Slots2x288pin (DDR5)
Memory StandardSupports up to 10400+(OC)
Maximum Memory Supported128GB
Channel SupportedDual Channel
Memory Performance ProfileAMD EXPO / Intel XMP 3.0
ECC SupportedNon-ECC
Buffer SupportedUn-buffered
Memory FeatureAMD Ryzen 9000 Series Processors supports DDR5 ECC/non-ECC, un-buffered memory up to 8400+(OC)
AMD Ryzen 8000 Series Processors supports DDR5 ECC/non-ECC, un-buffered memory up to 10400+(OC)
AMD Ryzen 7000 Series Processors supports DDR5 ECC/non-ECC, un-buffered memory up to 8000+(OC)
PCI Express 5.0 x162 x PCIe 5.0 x16 Slots (PCIE2 and PCIE3), support x16 or x8/x8 modes*
* PCIE2 will run at Gen5x16 with 9000 and 7000 series processors, Gen4x8 with 8000 (Phoenix 1) series processors and Gen4x4 with 8000 (Phoenix 2) series processors.
PCIE3 will be unavailable with 8000 (Phoenix 1 and Phoenix 2) series processors.
PCI Express x41 x PCIe 4.0 x4 Slot (PCIE1), supports x4 mode*
*If M2_3 is occupied, PCIE1 will downgrade to x2 mode.
Supports NVMe SSD as boot disks
Serial ATA (SATA)2 x SATA 6Gb/s
M.2CPU:
- 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*
- 1 x Blazing M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*
Chipset:
- 1 x M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x2 (32 Gb/s) mode*
- 1 x Hyper M.2 Socket (M2_4, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
- 1 x Ultra M.2 Socket (M2_5, Key M), supports type 2280 PCIe Gen3x4 (32 Gb/s) mode*
- 1 x Hyper M.2 Socket (M2_6, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
- 2 x SATA3 6.0 Gb/s Connectors*
* Supports NVMe SSD as boot disks
SATA RAIDSupports RAID 0 and RAID 1 for SATA storage devices
Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices
Audio ChipsetRealtek ALC4082
Audio Channels5.1 Channels
LAN ChipsetRealtek RTL8126
Max LAN Speed5Gbps
Wireless LANWi-Fi 802.11 be
BluetoothBluetooth 5.4
Back I/O Ports2 x Antenna Ports
1 x PS/2 Mouse/Keyboard Port
1 x HDMI Port
1 x Optical SPDIF Out Port
2 x USB4 Type-C Ports (40 Gb/s)*
7 x USB 3.2 Gen2 Type-A Ports (10 Gb/s)
1 x USB 3.2 Gen2 Type-C Port (10 Gb/s)
2 x USB 2.0 Ports
1 x RJ-45 LAN Port
1 x Clear CMOS Button
1 x BIOS Flashback Button
1 x BIOS Selection Switch
1 x Line Out Jack (Gold Audio Jack)
1 x Microphone Input Jack (Gold Audio Jack)
* Supports USB PD 3.0 up to 5V@3A (15W) charging
USB4 controller(for USB4_TC1 and USB4_TC2) will run at Gen4x2 with with 8000 (Phoenix 2) series processors.
Onboard USB3 x USB 2.0 Headers (Support 6 USB 2.0 ports)
1 x USB 3.2 Gen1 Header (Support 2 USB 3.2 Gen1 ports)
2 x Front Panel Type C USB 3.2 Gen2x2 Headers (20 Gb/s)*****
***** USB32_TC2 supports USB PD 3.0 up to 12V@3A (36W) charging; USB32_TC3 supports USB PD 3.0 up to 5V@3A (15W) charging.
Other Connectors2 x Thermistor Cable Headers
1 x Power LED and Speaker Header
1 x RGB LED Header*
3 x Addressable LED Headers**
2 x CPU Fan Connector (4-pin) (Smart Fan Speed Control)***
4 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)***
1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)***
1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
1 x 6 pin Graphics 12V Power Connector (Hi-Density Power Connector)****
1 x Front Panel Audio Connector (15µ Gold Audio Connector)
1 x Dr. Debug with LED
1 x Power Button
Form FactorATX
Dimensions (W x L)12.0" x 9.6"
SoftwareSoftware
- ASRock Formula Drive
- ASRock Polychrome SYNC*
UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock Auto Driver Installer
- ASRock Instant Flash
Shipping weight3.54 kg
Package size358 × 318 × 84 mm

Questions about this item

How loud or hot does the Dr.MOS power stage run when the board is pushed all day?

The Dr.MOS design uses Smart Power Stage technology to monitor current and temperature per phase, delivering smoother power to the CPU with enhanced overclocking headroom.

What memory must I already own to populate the two DDR5 slots?

You need un-buffered, non-ECC DDR5 modules; the board supports AMD EXPO and Intel XMP 3.0 profiles up to 10400+(OC) with Ryzen 8000 series CPUs.

Will my existing PCIe 4.0 NVMe drives work in the chipset M.2 slots without losing speed?

The chipset provides M.2 sockets running at PCIe 4.0 x4, so current NVMe SSDs operate at their rated throughput.
