Compact green Mini-ITX motherboard with silver CPU socket and black I/O shield

ASRock

ASRock Z690M-ITX/ax LGA 1700 DDR4 Mini ITX Intel Motherboard

SKU CH-T0W5-Y4F21

Mini ITX board for 12th, 13th and 14th Gen Intel Core CPUs with 8-phase Dr.MOS power, DDR4 5000 OC support and PCIe 5.0 x16 slot

  • Supports 12th, 13th and 14th Gen Intel Core processors on LGA 1700 socket
  • 8-phase Dr.MOS power design delivers stable voltage for multi-core CPUs
  • DDR4 memory overclocked to 5000 MHz for high-speed responsiveness
  • PCIe 5.0 x16 slot provides maximum bandwidth for modern graphics cards
  • Realtek ALC897 7.1-channel audio with Nahimic enhancement for immersive sound

Compact Intel Platform

This motherboard fits the Mini-ITX form factor and uses the LGA 1700 socket for 12th, 13th and 14th generation Intel Core, Pentium Gold and Celeron processors. An 8 phase Dr.MOS power design supplies the CPU. Graphics output is provided through HDMI and DisplayPort connectors.

Suitable Uses and Limits

The board suits builders who want a small system with one PCIe 5.0 x16 slot for a graphics card and DDR4 memory running up to 5000 MHz when overclocked. It is not for buyers who need more than one full-size expansion slot or who require memory types other than DDR4.

Deciding Specification

The single specification that decides fit is the LGA 1700 socket combined with the Mini-ITX layout, which restricts the build to a single PCIe 5.0 x16 slot and four SATA3 ports for storage devices.

Highlights

  • Supports 12th, 13th and 14th Gen Intel Core processors on LGA 1700 socket
  • 8-phase Dr.MOS power design delivers stable voltage for multi-core CPUs
  • DDR4 memory overclocked to 5000 MHz for high-speed responsiveness
  • PCIe 5.0 x16 slot provides maximum bandwidth for modern graphics cards
  • Realtek ALC897 7.1-channel audio with Nahimic enhancement for immersive sound

Specifications

No published specifications for this item yet.

Questions about this item

Do I need an LGA 1700 Intel Core processor from the 12th, 13th or 14th generation for this board to work?

Yes, the board only accepts LGA 1700 CPUs from those three generations, plus Pentium Gold and Celeron models.

Can I keep my existing DDR4 memory when upgrading to this Z690M-ITX/ax?

The board runs DDR4 up to 5000 MHz OC, so your current DDR4 sticks will work provided they match that specification.

How can I verify the 8-phase Dr.MOS power delivery is active after assembly?

Enter the BIOS hardware monitor and confirm the VRM phase count reads eight phases under load.
