ATX motherboard, matte black PCB with silver heatsinks and blue slots

ASRock

ASRock Z87 PRO4 LGA 1150 Intel motherboard

SKU CH-MX7X-1955F

ATX board for 4th-Gen Intel Core CPUs with four DDR3 slots up to 2933 MT/s, one PCIe 3.0 x16 slot, six SATA ports and 7.1 audio

  • CPU Socket TypeLGA 1150
  • CPU Type4th Generation Intel Core i7 / i5 / i3 / Pentium / Celeron (
  • Supported CPU TechnologiesTurbo Boost Technology 2.0
  • ChipsetIntel Z87
  • Number of Memory Slots4x240pin
  • Memory StandardDDR3 2933+(OC)/2800(OC)/2400(OC)/2133(OC)/1866(OC)/1600/1333
  • Supports 4th-Gen Intel Core processors on LGA 1150 socket
  • DDR3 memory overclocked up to 2933 MT/s across four slots
  • Intel Z87 chipset enables CPU Turbo Boost 2.0
  • Six SATA 6Gb/s ports with RAID 0/1/5/10 support
  • Realtek ALC892 7.1-channel audio with Intel I217V Gigabit LAN

Z87 chipset for 4th-gen Intel CPUs

This ATX motherboard uses the Intel Z87 chipset and an LGA 1150 socket to support 4th-generation Intel Core i7, i5, i3, Pentium and Celeron processors. It targets builders assembling a new system or upgrading an existing platform that relies on DDR3 memory. The board provides a standard desktop layout with four DIMM slots and multiple expansion slots.

DDR3 memory limits and SATA storage

Four 240-pin slots accept DDR3 modules at speeds from 1066 up to 2933+(OC) with a maximum capacity of 32 GB in dual-channel mode. Six SATA 6Gb/s ports offer RAID 0, 1, 5 and 10 for storage arrays. A single PCI Express 3.0 x16 slot, one PCI Express 2.0 x16 slot running at x4, two PCI Express x1 slots and two legacy PCI slots handle add-in cards.

Standard ATX install with BIOS update

The board follows the ATX form factor and mounts in any compatible case using regular standoffs and the 24-pin plus 8-pin power connectors. A BIOS upgrade to the latest version is applied before shipment, reducing the chance of a no-post situation with newer 4th-gen CPUs. Common issues include forgetting the 8-pin CPU power cable or seating memory in the wrong slots for dual-channel operation.

Highlights

  • Supports 4th-Gen Intel Core processors on LGA 1150 socket
  • DDR3 memory overclocked up to 2933 MT/s across four slots
  • Intel Z87 chipset enables CPU Turbo Boost 2.0
  • Six SATA 6Gb/s ports with RAID 0/1/5/10 support
  • Realtek ALC892 7.1-channel audio with Intel I217V Gigabit LAN

Specifications

BrandASRock
ModelZ87 PRO4
CPU Socket TypeLGA 1150
CPU Type4th Generation Intel Core i7 / i5 / i3 / Pentium / Celeron (LGA1150)
Supported CPU TechnologiesTurbo Boost Technology 2.0
ChipsetIntel Z87
Number of Memory Slots4x240pin
Memory StandardDDR3 2933+(OC)/2800(OC)/2400(OC)/2133(OC)/1866(OC)/1600/1333/1066
Maximum Memory Supported32GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16
PCI Express 2.0 x161(running at x4)
PCI Express x12 x PCI Express x1
PCI Slots2 x PCI Slots
Serial ATA (SATA)6 x SATA 6Gb/s
SATA RAID0/1/5/10
Audio ChipsetRealtek ALC892
Audio Channels7.1 Channels
LAN ChipsetGiga PHY Intel I217V
Max LAN Speed1Gbps
PS/21 x PS/2 keyboard/mouse port
Video PortsD-Sub + DVI
HDMI1 x HDMI-Out Port
1 x HDMI-In Port
USB 3.04 x USB 3.0
USB 1.1/2.04 x USB 2.0
S/PDIF Out1 x Optical
Audio Ports6 Ports
Onboard USB1 x Vertical Type A USB 3.0
2 x USB 3.0 headers (support 4 USB 3.0 ports) (ASMedia Hub)
2 x USB 2.0 headers (support 4 USB 2.0 ports)
Onboard 13941 x IR header
1 x COM Port header
1 x Power LED header
1 x TPM header
2 x CPU Fan connectors (1 x 4-pin, 1 x 3-pin)
2 x Chassis Fan connectors (1 x 4-pin, 1 x 3-pin)
1 x Power Fan connector (3-pin)
1 x 24 pin ATX power connector
1 x 8 pin 12V power connector
1 x Front panel audio connector
1 x SPDIF Out connector
Form FactorATX
Power Pin24 Pin
FeaturesA-Style : Home Cloud, HDMI-In
Supports 4th Gen Intel Core i7 / i5 / i3 / Xeon / Pentium / Celeron in LGA1150 Package
Premium Gold Capacitor Design, Digi Power, 6 Power Phase Design
Supports Dual Channel DDR3 2933+(OC)
1 x PCIe 3.0 x16, 1 x PCIe 2.0 x16, 2 x PCIe 2.0 x1
Supports AMD Quad CrossFireX, CrossFireX
Multi VGA Output Options : DVI-D, D-Sub, HDMI
Intel Gigabit LAN
7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)
6 x SATA3, 9 x USB 3.0, 8 x USB 2.0
Supports A-Tuning, XFast 555, Easy Driver Installer, FAN-Tastic Tuning, USB Key
Package ContentsASROCK Z87 PRO4 MB
Quick Installation Guide
Support CD
I/O Shield
2 x SATA Data Cables

Questions about this item

Will my 4th-generation Intel Core i5 fit the LGA 1150 socket on this board?

Yes, the socket supports 4th-generation Intel Core i7, i5, i3, Pentium and Celeron processors in the LGA 1150 package.

Can I run four DDR3 modules at 1600 MHz without overclocking?

The four 240-pin slots support DDR3 1066, 1333 and 1600 natively; higher speeds such as 1866, 2133, 2400, 2800 or 2933 require overclocking.

How many SATA 6 Gb/s drives can I connect for a RAID array?

Six SATA 6 Gb/s ports are available and the chipset supports RAID 0, 1, 5 and 10 across them.
