ASRock Z97 Anniversary ATX motherboard, black PCB with silver heatsinks and blue slots

ASRock

ASRock Z97 Anniversary LGA 1150 Intel motherboard

SKU CH-FMRY-P1NG7

Supports LGA 1150 Intel CPUs with Z97 chipset, four DDR3 slots up to 32 GB, one PCIe 3.0 x16 slot, three PCIe 2.0 x1 slots, six SATA 6Gb/s ports with RAID, 7.1 audio and gigabit LAN

  • CPU Socket TypeLGA 1150
  • CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1150)
  • Supported CPU TechnologiesTurbo Boost Technology 2.0
  • ChipsetIntel Z97
  • Onboard Video ChipsetSupports Intel HD Graphics Built-in Visuals: Intel Quick Syn
  • Number of Memory Slots4x240pin
  • Supports 4th and 5th Gen Intel Core i7/i5/i3 processors via LGA 1150 socket
  • Four DDR3/DDR3L slots accept up to 32 GB running at speeds up to 3100 MHz overclocked
  • Single PCI Express 3.0 x16 slot plus three PCIe 2.0 x1 slots for graphics and add-in cards
  • Six SATA 6 Gb/s ports with RAID 0, 1, 5, 10 and Intel Rapid Storage Technology
  • Realtek ALC887 7.1-channel audio and Intel I218V Gigabit LAN for media and networking

Z97 Anniversary LGA 1150 motherboard

This ATX board uses the Intel Z97 chipset and LGA 1150 socket to support Core i7, i5, i3, Pentium and Celeron processors with Turbo Boost Technology 2.0. Four 240-pin slots accept DDR3 and DDR3L memory up to 3100 MT/s overclocked in dual-channel mode with a maximum capacity of 32 GB. Integrated Intel HD Graphics 4400 and 4600 provide display output through onboard video.

Build quality and everyday connectivity

The board provides one PCI Express 3.0 x16 slot, three PCI Express 2.0 x1 slots and two legacy PCI slots for expansion cards. Six SATA 6Gb/s ports support RAID 0, 1, 5 and 10 through Intel Rapid Storage Technology 13 and Smart Response Technology. Realtek ALC887 delivers 7.1-channel audio and an Intel I218V controller handles Gigabit LAN at 1 Gbps.

Bundled software impact

Intel Rapid Storage Technology 13 enables RAID configuration and SSD caching without additional drivers. Intel Smart Response Technology uses a compatible SSD as a cache drive to accelerate frequently accessed data on mechanical storage. The onboard video features Intel Quick Sync Video with full hardware encode for AVC, MVC and MPEG-2 plus Clear Video HD, InTru 3D and Insider technologies for media playback.

Highlights

  • Supports 4th and 5th Gen Intel Core i7/i5/i3 processors via LGA 1150 socket
  • Four DDR3/DDR3L slots accept up to 32 GB running at speeds up to 3100 MHz overclocked
  • Single PCI Express 3.0 x16 slot plus three PCIe 2.0 x1 slots for graphics and add-in cards
  • Six SATA 6 Gb/s ports with RAID 0, 1, 5, 10 and Intel Rapid Storage Technology
  • Realtek ALC887 7.1-channel audio and Intel I218V Gigabit LAN for media and networking

Specifications

BrandASRock
ModelZ97 Anniversary
CPU Socket TypeLGA 1150
CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1150)
Supported CPU TechnologiesTurbo Boost Technology 2.0
ChipsetIntel Z97
Onboard Video ChipsetSupports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 4400/4600
Pixel Shader 5.0, DirectX 11.1
Max. shared memory 1792MB
Supports HDMI with max. resolution up to 1920x1200 @ 60Hz
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
Supports HDCP with HDMI Port
Supports Full HD 1080p Blu-ray (BD) playback with HDMI Port
*Intel HD Graphics Built-in Visuals and the VG
Number of Memory Slots4x240pin
Memory StandardDDR3/DDR3L 3100+*(*OC)/ 2933*/ 2800*/ 2400*/ 2133*/ 1866*/ 1600/ 1333/ 1066
Maximum Memory Supported32GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)
PCI Express x13 x PCI Express 2.0 x1 Slots
PCI Slots2 x PCI Slots
Serial ATA (SATA)6 x SATA 6Gb/s
SATA RAIDRAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 13 and Intel Smart Response Technology
Audio ChipsetRealtek ALC887
Audio Channels7.1 Channels
LAN ChipsetIntel I218V
Max LAN Speed1Gbps
Back I/O Ports1 x HDMI / 1 x PS/2 Keyboard/Mouse Combo / 2 x USB 2.0/1.1 / 4 x USB 3.0
PS/21 x PS/2 keyboard/mouse port
HDMI1 x HDMI
RJ451 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
USB 3.04 x USB 3.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))
USB 1.1/2.02 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))
Audio PortsHD Audio Jacks: Line in / Front Speaker / Microphone
Onboard USB2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
Other Connectors1 x COM Port Header
1 x TPM Header
1 x Power LED Header
2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
2 x Chassis Fan Connectors (2 x 4-pin)
1 x Power Fan Connector (3-pin)
1 x 24 pin ATX Power Connector
1 x 8 pin 12V Power Connector
1 x Front Panel Audio Connector
Form FactorATX
Dimensions (W x L)12.00" x 7.50"
Power Pin24 Pin
FeaturesASRock Super Alloy
- Premium Alloy Choke (Reduces 70% core loss compared to iron powder choke)
- NexFET MOSFET
- Sapphire Black PCB
Supports 5th Generation Intel Core i7/i5/i3/Pentium/Celeron Processors (Socket 1150)
Supports New 4th and 4th Generation Intel Xeon/Core i7/i5/i3/Pentium/Celeron Processors (Socket 1150)
Solid Capacitor design, Digi Power
Supports Dual Channel DDR3/DDR3L 3100+(OC)
1 PCIe 3.0 x16, 3 PCIe 2.0 x1, 2 PCI
7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps
Intel Gigabit LAN
1 HDMI, 6 SATA3, 6 USB 3.0 (2 Front, 4 Rear), 6 USB 2.0 (4 Front, 2 Rear)
1
Package ContentsAccessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables

Questions about this item

Will my LGA 1150 Core i5 fit this board?

Yes. The socket is LGA 1150 and the chipset supports Core i7, i5, i3, Pentium and Celeron processors in that package.

Can I run four DDR3 sticks at 2400 MHz?

The board has four 240-pin slots, dual-channel, and lists 2400* as a supported DDR3/DDR3L speed with a 32 GB maximum.

What display outputs are available for the integrated graphics?

The supplier title confirms an HDMI port; the chipset supports Intel HD Graphics 4400 and 4600 with Quick Sync Video and Clear Video HD.
