ATX motherboard in dark grey and yellow with large heatsinks, four DDR5 slots and four M.2 covers

ASUS

ASUS 90MB1NY0-M0VAY0 TUF GAMING X870-PRO WIFI7 AMD motherboard

SKU CH-PWD6-ZTP53 MPN 90MB1NY0-M0VAY0

AM5 board for Ryzen 7000, 8000 and 9000 CPUs with 16+2+1 80A power stages, DDR5 9600, four M.2 slots, PCIe 5.0 graphics, 5Gb Ethernet, WIFI7 and 64MB BIOS

  • CPU Socket TypeAM5
  • CPU TypeRyzen 7000 Series / Ryzen 8000 Series / Ryzen 9000 Series
  • ChipsetAMD X870
  • South BridgeAMD X870
  • Number of Memory Slots4x288pin (DDR5)
  • Memory StandardDDR5 9600
  • AM5 socket supports Ryzen 7000 8000 9000 series processors
  • 16+2+1 80A power stages with 8-layer PCB deliver stable power
  • Four M.2 slots include two PCIe 5.0 and two PCIe 4.0
  • DDR5 9600 with NitroPath technology enables up to 256GB memory
  • WIFI7 plus 5Gb Ethernet and USB4 40Gbps provide fast connectivity

AM5 Socket AMD X870 Motherboard

The ASUS TUF GAMING X870-PRO WIFI7 is built for AMD Ryzen 7000, 8000 and 9000 series desktop processors on the AM5 platform. It targets enthusiasts who need stable power delivery and high-speed connectivity for gaming or AI workloads. The board uses the X870 chipset and a 16+2+1 80A power stage design with 8+8 pin ProCool connectors.

Straightforward ATX Install With DDR5 NitroPath

Standard ATX mounting points and clearly labelled headers make physical installation routine. Four 288-pin DDR5 slots support up to 256GB at 9600 MT/s using AMD EXPO, Intel XMP or ASUS AEMP profiles. NitroPath DRAM Technology and DIMM Fit Pro reduce trace interference and improve seating confidence. The main PCIe 5.0 x16 slot and two PCIe 5.0 M.2 slots deliver full bandwidth when USB4 ports are unused.

Four M.2 Slots With Two PCIe 5.0 Lanes

Storage flexibility centres on four M.2 sockets: two wired for PCIe 5.0 x4 and two for PCIe 4.0 x4. This layout decides whether the board matches a build that needs multiple high-throughput drives without sacrificing GPU bandwidth. Two SATA 6Gb/s ports remain for additional bulk storage.

Highlights

  • AM5 socket supports Ryzen 7000 8000 9000 series processors
  • 16+2+1 80A power stages with 8-layer PCB deliver stable power
  • Four M.2 slots include two PCIe 5.0 and two PCIe 4.0
  • DDR5 9600 with NitroPath technology enables up to 256GB memory
  • WIFI7 plus 5Gb Ethernet and USB4 40Gbps provide fast connectivity

Specifications

BrandASUS
SeriesTUF
Part Number90MB1NY0-M0VAY0
CPU Socket TypeAM5
CPU TypeRyzen 7000 Series / Ryzen 8000 Series / Ryzen 9000 Series
ChipsetAMD X870
South BridgeAMD X870
Number of Memory Slots4x288pin (DDR5)
Memory StandardDDR5 9600
Maximum Memory Supported256GB
Channel SupportedDual Channel
Memory Performance ProfileAMD EXPO / Intel XMP / ASUS AEMP
ECC SupportedYes
Buffer SupportedUn-buffered
PCI Express 5.0 x161 x PCI Express 5.0 x16
PCI Express 4.0 x162 x PCI Express 4.0 x16
PCI Express x162 x PCI Express x16
PCI Express x41 x PCI Express x4
Serial ATA (SATA)2 x SATA 6Gb/s
M.24 x M.2 (Support PCIe 5.0 x4 & PCIe 4.0 x4)
SATA RAID0/1/5/10
Onboard Video ChipsetDepends on AMD Ryzen Series Processor with Integrated Graphics
Audio ChipsetRealtek ALC1220P
Audio Channels7.1 Channels
LAN ChipsetRealtek 5Gb
Max LAN Speed5Gbps
Wireless LANWi-Fi 802.11 be
BluetoothYes
Back I/O Ports2 x USB4 (40Gbps) Type-C, 3 x USB 10Gbps Type-A, 4 x USB 5Gbps Type-A, 1 x USB 2.0 Type-A, 1 x HDMI, 1 x Wi-Fi module, 1 x Realtek 5Gb Ethernet port, 3 x Audio jacks, 1 x BIOS FlashBack button, 1 x Clear CMOS button
COM1
Video PortsHDMI + 2 x USB Type-C
HDMI1 x HDMI port
RJ451 x RJ45
USB 3.13 x USB 3.1
USB 3.06 x USB 3.0
USB 1.1/2.01 x USB 2.0
USB Type-C2 x USB Type-C port, with USB4 (40Gbps) support
S/PDIF OutYes
Audio Ports3 Ports
Onboard USB1 x USB Type-C header, with USB 3.2 Gen 2x2 + 1 x USB 3.2 Gen 1 header + 3 x USB 2.0 headers
Form FactorATX
LED LightingRGB
Dimensions (W x L)12 inch x 9.6 inch
Power Pin24 Pin
Windows 11Supported
Shipping weight2.13 kg
Package size356 × 279 × 70 mm

Questions about this item

How can I confirm the board is running the 16+2+1 power stages and 64MB BIOS after first boot?

Enter the UEFI and check the hardware monitor page — it shows the 16+2+1 phase count and the 64MB BIOS size.

What comes in the box and what must I buy separately for the four M.2 slots and DDR5 memory?

The board, I/O shield, SATA cables and manual are included; DDR5 modules and up to four M.2 drives are purchased separately.

Which version should I choose for Ryzen 9000 Series with PCIe 5.0 graphics and 5.0 M.2 storage?

This single SKU delivers PCIe 5.0 x16 for the GPU and two PCIe 5.0 M.2 slots plus two PCIe 4.0 M.2 slots.
