Black dual-slot graphics card with silver accents, two axial fans and a metal backplate

ASUS

ASUS ATS GeForce RTX 5060 8GB GDDR7 OC edition graphics card

SKU CH-MYCK-8BSV3

GeForce RTX 5060 graphics card with 8GB GDDR7 memory, 3840 CUDA cores and PCIe 5.0 x8 interface

  • InterfacePCI Express 5.0 x8
  • Chipset ManufacturerNVIDIA
  • GPU SeriesNVIDIA GeForce RTX 50 Series
  • GPUGeForce RTX 5060
  • ArchitectureBlackwell
  • Boost ClockOC mode: 2595MHz Default mode: 2565MHz (Boost Clock)
  • GDDR7 memory at 28 Gbps feeds the GPU with high bandwidth
  • OC boost clock reaches 2595 MHz for extra performance headroom
  • 3840 CUDA cores accelerate rendering and compute workloads
  • PCI Express 5.0 x8 interface doubles link bandwidth over previous standard
  • HDMI 2.1b plus three DisplayPort 2.1b outputs drive four displays

ASUS ATS GeForce RTX 5060 8GB GDDR7

The ASUS ATS GeForce RTX 5060 8GB GDDR7 is a graphics card built on the NVIDIA Blackwell architecture. It targets gamers and creators who need 8GB of GDDR7 memory on a 128-bit interface. The card connects via a PCI Express 5.0 x8 slot and provides 3840 CUDA cores for parallel workloads.

Thermals, noise and power draw in normal use

The card operates with a boost clock of 2565MHz in default mode and 2595MHz in OC mode. Effective memory runs at 28 Gbps across the 128-bit bus. Power consumption and thermal output scale with the selected clock profile and workload intensity. Fan behaviour and acoustics adjust automatically to the GPU temperature curve.

Display outputs and software control

One HDMI 2.1b port and three DisplayPort 2.1b connectors support up to four simultaneous monitors. ASUS GPU Tweak software lets users switch between default and OC boost profiles. The utility also provides real-time monitoring of clocks, temperatures and fan speeds. Driver support covers DirectX 12 Ultimate and OpenGL 4.6.

Highlights

  • GDDR7 memory at 28 Gbps feeds the GPU with high bandwidth
  • OC boost clock reaches 2595 MHz for extra performance headroom
  • 3840 CUDA cores accelerate rendering and compute workloads
  • PCI Express 5.0 x8 interface doubles link bandwidth over previous standard
  • HDMI 2.1b plus three DisplayPort 2.1b outputs drive four displays

Specifications

BrandASUS
SeriesATS
ModelATS-RTX5060-O8G
InterfacePCI Express 5.0 x8
Chipset ManufacturerNVIDIA
GPU SeriesNVIDIA GeForce RTX 50 Series
GPUGeForce RTX 5060
ArchitectureBlackwell
Boost ClockOC mode: 2595MHz
Default mode: 2565MHz (Boost Clock)
CUDA Cores3840
Effective Memory Clock28 Gbps
Memory Size8GB
Memory Interface128-Bit
Memory TypeGDDR7
DirectXDirectX 12 Ultimate
OpenGLOpenGL 4.6
Multi-Monitor Support4
HDMI1 x HDMI 2.1b
DisplayPort3 x DisplayPort 2.1b
ColorBlack
Max Resolution7680 x 4320
CrossFireX SupportNo
SLI SupportNo
Virtual Reality ReadyYes
CoolerTriple Fans
Recommended PSU Wattage550W
Power Connector8-Pin
HDCP ReadyYes
Form FactorATX
Max GPU Length269 mm
Card Dimensions (L x H)268.3 x 120 x 50 mm
10.56 x 4.72 x 1.97 inches
Slot Width2.5 Slots

Questions about this item

How do I install the card in a PCI Express 5.0 x8 slot and what step is often missed?

Seat the card firmly until the retention bracket clicks, then connect both supplementary power cables before closing the case; the x8 link negotiates automatically.

What maintenance will the 3840 CUDA core GPU need later?

Dust the heatsink and fans every few months with compressed air; the GDDR7 memory and PCB have no user-serviceable parts.

What limit appears first during sustained load on the 128-bit GDDR7 interface?

Memory bandwidth at 28 Gbps across the 128-bit bus becomes the bottleneck before the 2595 MHz boost clock can be fully utilised.
