Black ASUS ATS graphics card with dual fans and metal backplate

ASUS

ASUS ATS GeForce RTX 5060 Ti 8GB graphics card

SKU CH-70X0-S8V20

8GB GDDR7 on a 128-bit bus with 4608 CUDA cores, PCIe 5.0 x8, HDMI 2.1b and three DisplayPort 2.1b outputs, plus DLSS 4.0 support

  • InterfacePCI Express 5.0 x8
  • Chipset ManufacturerNVIDIA
  • GPU SeriesNVIDIA GeForce RTX 50 Series
  • GPUGeForce RTX 5060 Ti
  • ArchitectureBlackwell
  • CUDA Cores4608
  • 8GB GDDR7 memory delivers 28 Gbps bandwidth for high-speed texture streaming
  • 4608 CUDA cores accelerate raster and ray-tracing workloads in Blackwell architecture
  • Boost clocks reach 2647 MHz in OC mode and 2617 MHz default for responsive frame rates
  • DLSS 4.0 upscaling and frame generation boost performance at 7680 x 4320 resolution
  • HDMI 2.1b and three DisplayPort 2.1b outputs drive four displays simultaneously

ASUS ATS RTX 5060 Ti 8GB for gamers

The ASUS ATS GeForce RTX 5060 Ti 8GB is a graphics card built on the NVIDIA Blackwell architecture with 4608 CUDA cores and 8GB of GDDR7 memory on a 128-bit bus. It targets gamers who want DLSS 4.0 upscaling and frame generation at 1440p or high-refresh 1080p. The card runs at a default boost clock of 2617MHz and an OC mode of 2647MHz.

Check PCIe slot and power before ordering

Verify that your motherboard provides a PCI Express 5.0 x8 slot and that your power supply has the required connectors and sufficient wattage for the card. Ensure your chassis offers enough length clearance for a dual-slot design. A modern CPU will help avoid bottlenecks with the 28 Gbps memory speed.

Thermals noise and power in normal use

The dual-fan cooler keeps GPU temperatures controlled during typical gaming sessions while fan speeds stay low at idle. Power draw scales with the 2617MHz default boost and the 28 Gbps GDDR7 memory. Fan noise remains moderate under load and the card idles quietly for desktop work.

Highlights

  • 8GB GDDR7 memory delivers 28 Gbps bandwidth for high-speed texture streaming
  • 4608 CUDA cores accelerate raster and ray-tracing workloads in Blackwell architecture
  • Boost clocks reach 2647 MHz in OC mode and 2617 MHz default for responsive frame rates
  • DLSS 4.0 upscaling and frame generation boost performance at 7680 x 4320 resolution
  • HDMI 2.1b and three DisplayPort 2.1b outputs drive four displays simultaneously

Specifications

BrandASUS
SeriesATS
ModelATS-RTX5060TI-8G
InterfacePCI Express 5.0 x8
Chipset ManufacturerNVIDIA
GPU SeriesNVIDIA GeForce RTX 50 Series
GPUGeForce RTX 5060 Ti
ArchitectureBlackwell
CUDA Cores4608
Effective Memory Clock28 Gbps
Memory Size8GB
Memory Interface128-Bit
Memory TypeGDDR7
DirectXDirectX 12 Ultimate
OpenGLOpenGL 4.6
Multi-Monitor Support4
HDMI1 x HDMI 2.1b
DisplayPort3 x DisplayPort 2.1b
ColorBlack
Max Resolution7680 x 4320
CrossFireX SupportNo
SLI SupportNo
Virtual Reality ReadyYes
CoolerTriple Fans
Recommended PSU Wattage550W
Power Connector8-Pin
Features• AI Performance: 758 AI TOPS
• Powered by the NVIDIA Blackwell architecture and DLSS 4
• SFF-Ready Enthusiast GeForce Card
• Axial-tech fans feature a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure
• 2.5-slot design allows for greater build compatibility while maintaining cooling performance
• Dual-ball fan bearings last up to twice as long as standard sleeve bearings
• 0dB technology lets you enjoy light gaming in relative silence
• Dual BIOS switch lets you toggle between Quiet and Performance BIOS profiles
• Auto-Extreme man
Form FactorATX
Max GPU Length304 mm
Card Dimensions (L x H)304 x 120 x 50 mm
11.96 x 4.72 x 1.97 inch
Slot Width2.5 Slots

Questions about this item

What comes in the box with the ASUS ATS GeForce RTX 5060 Ti 8GB and what must be purchased separately?

The card includes one HDMI 2.1b port and three DisplayPort 2.1b outputs for up to four monitors. A PCI Express 5.0 x8 slot and sufficient power connectors from your PSU are required but not included.

How do I choose between the default and OC modes on this RTX 5060 Ti?

Default mode runs at a 2617MHz boost clock; OC mode increases it to 2647MHz. Select OC in the vendor utility if your case airflow and power supply can sustain the higher frequency.

What does the 28 Gbps GDDR7 memory speed mean for actual gaming performance?

The 28 Gbps effective clock on the 128-bit bus delivers high bandwidth for 1440p gaming and enables DLSS 4.0 frame generation on the 4608 CUDA cores.
