ASUS
ASUS Dual GeForce RTX 5060 8GB GDDR7 Graphics Card DUAL-RTX5060-8G
GeForce RTX 5060 graphics card with 8GB GDDR7 memory, 3840 CUDA cores and boost clocks up to 2565MHz
- InterfacePCI Express 5.0 x8
- Chipset ManufacturerNVIDIA
- GPU SeriesNVIDIA GeForce RTX 50 Series
- GPUGeForce RTX 5060
- ArchitectureBlackwell
- Boost ClockOC mode: 2565MHz Default mode: 2535MHz (Boost Clock)
- 8GB GDDR7 memory at 28 Gbps feeds the GPU with high bandwidth
- Boost clock reaches 2565 MHz in OC mode for extra speed
- 3840 CUDA cores handle parallel workloads across games and creative apps
- PCI Express 5.0 x8 interface doubles link bandwidth versus older slots
- One HDMI 2.1b and three DisplayPort 2.1b outputs drive up to four monitors
ASUS Dual GeForce RTX 5060 8GB GDDR7
The ASUS Dual GeForce RTX 5060 8GB GDDR7 is a graphics card built on the NVIDIA Blackwell architecture. It connects via a PCI Express 5.0 x8 interface and provides 8GB of GDDR7 memory across a 128-bit bus running at 28 Gbps. The GPU features 3840 CUDA cores with a boost clock of 2535MHz in default mode and 2565MHz in OC mode.
Suits 1440p gaming and multi-monitor setups
This card suits users targeting 1440p gaming or driving up to four displays through one HDMI 2.1b and three DisplayPort 2.1b outputs. The 8GB frame buffer and 128-bit memory interface may limit performance in memory-heavy workloads or at higher resolutions. Builders needing more VRAM or a wider bus should consider other options.
Dual-slot cooler fits standard ATX builds
The dual-slot cooler design fits standard ATX cases without special clearance requirements. A metal backplate adds structural rigidity and helps protect the PCB during handling. No additional software licences or adapter cables are bundled beyond the standard driver package.
Highlights
- 8GB GDDR7 memory at 28 Gbps feeds the GPU with high bandwidth
- Boost clock reaches 2565 MHz in OC mode for extra speed
- 3840 CUDA cores handle parallel workloads across games and creative apps
- PCI Express 5.0 x8 interface doubles link bandwidth versus older slots
- One HDMI 2.1b and three DisplayPort 2.1b outputs drive up to four monitors
Specifications
| Brand | ASUS |
|---|---|
| Series | Dual |
| Model | DUAL-RTX5060-8G |
| Interface | PCI Express 5.0 x8 |
| Chipset Manufacturer | NVIDIA |
| GPU Series | NVIDIA GeForce RTX 50 Series |
| GPU | GeForce RTX 5060 |
| Architecture | Blackwell |
| Boost Clock | OC mode: 2565MHz Default mode: 2535MHz (Boost Clock) |
| CUDA Cores | 3840 |
| Effective Memory Clock | 28 Gbps |
| Memory Size | 8GB |
| Memory Interface | 128-Bit |
| Memory Type | GDDR7 |
| DirectX | DirectX 12 Ultimate |
| OpenGL | OpenGL 4.6 |
| Multi-Monitor Support | 4 |
| HDMI | 1 x HDMI 2.1b |
| DisplayPort | 3 x DisplayPort 2.1b |
| Color | Black |
| Max Resolution | 7680 x 4320 |
| CrossFireX Support | No |
| SLI Support | No |
| Virtual Reality Ready | Yes |
| Cooler | Double Fans |
| Recommended PSU Wattage | 550W |
| Power Connector | 8-Pin |
| HDCP Ready | Yes |
| Form Factor | ATX |
| Max GPU Length | 228 mm |
| Card Dimensions (L x H) | 228 x 123 x 50 mm 8.98 x 4.84 x 1.97 inches |
| Slot Width | 2.5 Slots |
| Package Contents | 1 x Speedsetup Manual 1 x Thank You Card |
Questions about this item
What motherboard slot does the PCI Express 5.0 x8 interface need?
It installs in any PCI Express 5.0 x8 or wider slot on the motherboard.
Will the HDMI 2.1b and DisplayPort 2.1b outputs work with my current 4K 60 Hz monitor?
Yes, the ports are backward compatible and will drive the monitor at its native resolution and refresh rate.
How can I verify the boost clock is reaching 2535 MHz in default mode?
Open GPU-Z or the ASUS GPU Tweak III overlay while the card is under load and confirm the reported boost clock matches 2535 MHz.
