Green ATX motherboard with black heatsinks and silver LGA 1151 socket

ASUS

ASUS E3 PRO GAMING V5 Intel C232 motherboard

SKU CH-ZJD0-K9KPW

ATX board with LGA 1151 socket, Intel C232 chipset, dual-channel DDR4 2133 up to 64 GB, SupremeFX audio, Intel I219-LM LAN, USB 3.1 Type A/C and M.2 slot

  • CPU Socket TypeLGA 1151
  • CPU TypeXeon E3-1200 v5 / Core / Pentium / Celeron (LGA1151)
  • Supported CPU TechnologiesTurbo Boost Technology 2.0 * Not Compatible with Intel 8th G
  • ChipsetIntel C232
  • Onboard Video ChipsetNone
  • Number of Memory Slots4x288pin (DDR4)
  • LGA 1151 socket fits Xeon E3‑1200 v5 and Core CPUs
  • Four DDR4 slots run dual‑channel at 2133 MT/s up to 64 GB
  • SupremeFX audio chipset delivers 8‑channel output
  • Intel I219‑LM Gigabit LAN with LANGuard protection
  • USB 3.1 Type‑A and Type‑C plus M.2 Socket 3 for SATA or PCIe SSDs

Socket and processor support

The ASUS E3 PRO GAMING V5 uses the LGA 1151 socket and the Intel C232 chipset. It accepts Xeon E3-1200 v5 series processors as well as Core, Pentium and Celeron CPUs in the same package. Turbo Boost Technology 2.0 is supported, but the board is not compatible with Intel 8th Gen CPUs.

Thermals noise and power draw

The board has no onboard video chipset, so all graphics output comes from a discrete card. Passive heatsinks cool the chipset and voltage regulators without adding fan noise. Power draw scales with the installed CPU and the number of populated DIMM slots.

Memory capacity and speed

Four 288-pin DDR4 slots support dual-channel memory up to 64 GB at 2133 MT/s. This maximum capacity and speed are the primary limits for workloads that depend on memory bandwidth and capacity.

Highlights

  • LGA 1151 socket fits Xeon E3‑1200 v5 and Core CPUs
  • Four DDR4 slots run dual‑channel at 2133 MT/s up to 64 GB
  • SupremeFX audio chipset delivers 8‑channel output
  • Intel I219‑LM Gigabit LAN with LANGuard protection
  • USB 3.1 Type‑A and Type‑C plus M.2 Socket 3 for SATA or PCIe SSDs

Specifications

BrandASUS
ModelE3 PRO GAMING V5
CPU Socket TypeLGA 1151
CPU TypeXeon E3-1200 v5 / Core / Pentium / Celeron (LGA1151)
Supported CPU TechnologiesTurbo Boost Technology 2.0 * Not Compatible with Intel 8th Gen CPUs
ChipsetIntel C232
Onboard Video ChipsetNone
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 2133
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCIe 3.0/2.0 x16 (x16 mode)1 x PCIe 3.0/2.0 x16 (max at x4 mode) *1*1: When PCIE x16_2 is occupied by x4 or faster devices, PCIE x1_1 and PCIE x1_2 will be disabled.
PCI Express x12 x PCIe 3.0/2.0 x1
PCI Slots2 x PCI Slots
Serial ATA (SATA)6 x SATA 6Gb/s
M.21 x M.2 Socket 3, with M Key design, type 2242/2260/2280/22110 storage devices support (Supports both SATA & PCIE SSD) *2*2: When the M.2 Socket 3 is operating in SATA mode, SATA port 1 will be disabled.
SATA RAID0/1/5/10
Audio ChipsetSupremeFX
Audio Channels8 Channels
LAN ChipsetIntel I219-LM
Max LAN Speed1Gbps
PS/21 x PS/2 keyboard (purple)1 x PS/2 mouse (green)
RJ451 x RJ45
USB 3.11 x USB 3.1 (red) Type-A1 x USB 3.1 Type-C
USB 3.04 x USB 3.0
USB 1.1/2.02 x USB 2.0
S/PDIF Out1 x Optical
Audio Ports5 Ports
Onboard USB1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin)2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
Other Connectors1 x COM port(s) connector(s)1 x CPU Fan connector(s) (1 x 4-pin)3 x Chassis Fan connector(s) (3 x 4-pin)1 x 24-pin EATX Power connector(s)1 x 8-pin ATX 12V Power connector(s)1 x Front panel audio connector(s) (AAFP)1 x System panel(s)1 x Thermal sensor connector(s)1 x CPU OV1 x Clear CMOS jumper(s)1 x Water Pump header (4-pin)1 x ROG extension (ROG_EXT) header(s)
Form FactorATX
Dimensions (W x L)12.0" x 9.6"
Power Pin24 Pin
FeaturesMulti-GPU Support:Supports AMD Quad-GPU CrossFireX TechnologySupports AMD 2-Way CrossFireX TechnologySpecial Features:Gamer's Guardian:- ESD Guards on LAN, Audio, KBMS and USB3.0/2.0 ports- DRAM Overcurrent Protection- Stainless Steel Back I/O- Highly Durable Components- DIGI+ VRMASUS EPU:- EPUASUS Exclusive Features:- Ai Charger+- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface- USB 3.1 Boost- Disk UnlockerASUS Quiet Thermal Solution:- Stylish Fanless Design Heat-sink solution- ASUS Fan Xpert 3ASUS EZ DIY:- ASUS CrashFree BIOS 3- ASUS EZ Flash 3- ASUS UEFI BIOS EZ
Package ContentsAccessories:User's manualI/O Shield4 x SATA 6Gb/s cable(s)1 x M.2 Screw Package1 x pack of cable tie1 x Supporting DVD1 x 12 in 1 Cable Label (s)

Questions about this item

Will an Intel Xeon E3-1200 v5 processor fit this LGA 1151 socket?

Yes, the board is built for Xeon E3-1200 v5 and other LGA 1151 CPUs such as Core, Pentium and Celeron.

Can I install 64 GB of DDR4-2133 memory across the four slots?

The four 288-pin slots support dual-channel DDR4-2133 up to a total of 64 GB.

Does the M.2 slot work with both SATA and PCIe SSDs?

The M.2 Socket 3 with M Key accepts 2242, 2260, 2280 and 22110 drives in either SATA or PCIe mode; using SATA mode disables SATA port 1.
