Green rectangular Micro ATX board with silver CPU socket and black memory slots

ASUS

ASUS EX-B150M-V3 LGA 1151 DDR4 32GB Micro ATX Intel motherboard

SKU CH-B08F-K5FEV

Supports 6th generation Intel Core processors with LGA 1151 socket, dual-channel DDR4 2133MHz memory up to 32GB, and four SATA III ports on a Micro ATX board measuring 22.6x18.5cm

  • CPU Socket TypeLGA 1151
  • CPU TypeThe main board is equipped with a set of Central Processor s
  • ChipsetIntel B150
  • Memory StandardSupports dual-channel DDR4 2133MHz memory
  • Maximum Memory Supported32GB
  • PCI SlotsConsidering the possibility of expanding system performance
  • Supports 6th-gen Intel Core processors with LGA 1151 socket
  • Dual-channel DDR4 2133 MHz memory up to 32 GB capacity
  • Intel B150 chipset provides PCIe 3.0 x16 and x1 expansion slots
  • Four SATA III ports for storage connectivity
  • Micro ATX form factor measures 22.6 × 18.5 cm

Socket LGA 1151 Micro ATX Board

This ASUS EX-B150M-V3 motherboard uses the Intel B150 chipset and fits a micro ATX form factor of 22.6x18.5cm. It accepts 6th generation Intel Core i7, i5, i3, Pentium and Celeron processors in an LGA 1151 socket. The board provides dual-channel DDR4 2133MHz memory support up to 32GB.

Home Upgraders and Basic Builds

It suits builders assembling a basic office PC or replacing a board in an existing micro ATX chassis with DDR4 memory. It is not for buyers who need more than 32GB of RAM or who require more than four SATA III ports for storage expansion.

DDR4 32GB Maximum Capacity

The single specification that decides fit is the 32GB maximum memory limit across two DDR4 slots running at 2133MHz. If the planned system needs more memory than this ceiling, this motherboard will not meet the requirement.

Highlights

  • Supports 6th-gen Intel Core processors with LGA 1151 socket
  • Dual-channel DDR4 2133 MHz memory up to 32 GB capacity
  • Intel B150 chipset provides PCIe 3.0 x16 and x1 expansion slots
  • Four SATA III ports for storage connectivity
  • Micro ATX form factor measures 22.6 × 18.5 cm

Specifications

BrandASUS
SeriesASUS EX-B150M-V3
ModelASUS EX-B150M-V3
CPU Socket TypeLGA 1151
CPU TypeThe main board is equipped with a set of Central Processor slots and supports 6th generation Intel Core i7 Core i5 Core i3/Pentium/Celeron processors with LGA1151 specification slots.
ChipsetIntel B150
Memory StandardSupports dual-channel DDR4 2133MHz memory
Maximum Memory Supported32GB
PCI SlotsConsidering the possibility of expanding system performance in the future, this main board provides PCI Express 3.0/2 x16 and PCI Express 3.0/2 x1 expansion slots that support function expansion cards that meet their specifications.
SATA RAID4XSATA III interface

Questions about this item

How long will the CMOS battery last before it needs replacing?

The board ships with a metal battery included; typical CMOS cells run several years before a swap is needed.

What caps the memory upgrade on this board?

The B150 chipset and two DDR4 slots limit total capacity to 32 GB at 2133 MHz.

How hot does the chipset get during an all-day workload?

The B150 runs passively cooled; under sustained load it stays within normal operating temperatures for a Micro ATX board.
