Green rectangular micro-ATX board with silver CPU socket, four black memory slots, black PCIe slots, blue SATA ports

ASUS

ASUS EX-B460M-V5 LGA 1200 Intel motherboard

SKU CH-S17K-R5VG3

Micro-ATX board with an LGA 1200 socket, Intel B460 chipset, DDR4 memory up to 64 GB, four SATA III ports, one M.2 slot, 7.1 audio and Gigabit LAN

  • CPU Socket TypeLGA 1200
  • CPU TypeIntele Socket LGA1200 for 10' Gen Intel Core, Pentium Gold a
  • ChipsetIntel B460
  • Memory StandardSupport DDR4 2933/2800/2666/2400/2133MHz memory
  • Maximum Memory Supported64GB
  • PCI SlotsIntel 10th Gen Processors1 x PCIe 3.0x16 slot (supports x16
  • Supports 10th Gen Intel Core, Pentium Gold and Celeron processors via LGA 1200 socket
  • Handles up to 64GB DDR4 memory at speeds up to 2933 MHz
  • Realtek ALC887 7.1-channel audio with Japanese capacitors and shielding for clear sound
  • 1 Gb Ethernet from Realtek RTL8111H keeps wired connections stable
  • Micro-ATX form factor at 22.6 x 21.1 cm fits compact builds

Intel B460 micro-ATX board for 10th Gen CPUs

The ASUS EX-B460M-V5 is a micro-ATX motherboard built around the Intel B460 chipset and the LGA 1200 socket. It supports 10th Generation Intel Core, Pentium Gold and Celeron processors with a 14 nm manufacturing process. The board delivers standard connectivity for a mainstream desktop build.

Suitable for office PCs and basic home systems

This motherboard suits users building a general-purpose computer with an Intel 10th Gen processor who need up to 64 GB of DDR4 memory and a single full-size PCIe 3.0 x16 slot. It is not for builders requiring CPU overclocking, multiple graphics cards, or integrated Wi-Fi and Bluetooth.

Maximum memory capacity of 64 GB DDR4

The board provides two DDR4 slots with a maximum supported capacity of 64 GB at speeds up to 2933 MHz. This limit determines whether the platform can meet the memory requirements of your intended applications before purchase.

Highlights

  • Supports 10th Gen Intel Core, Pentium Gold and Celeron processors via LGA 1200 socket
  • Handles up to 64GB DDR4 memory at speeds up to 2933 MHz
  • Realtek ALC887 7.1-channel audio with Japanese capacitors and shielding for clear sound
  • 1 Gb Ethernet from Realtek RTL8111H keeps wired connections stable
  • Micro-ATX form factor at 22.6 x 21.1 cm fits compact builds

Specifications

BrandASUS
SeriesASUS EX-B460M-V5
ModelASUS EX-B460M-V5
CPU Socket TypeLGA 1200
CPU TypeIntele Socket LGA1200 for 10' Gen Intel Core, Pentium Gold and Celeron Processors*
Supports Intel 14nm CPU
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost MaxTechnology 3.0**
ChipsetIntel B460
Memory StandardSupport DDR4 2933/2800/2666/2400/2133MHz memory
Maximum Memory Supported64GB
PCI SlotsIntel 10th Gen Processors1 x PCIe 3.0x16 slot (supports x16 mode)Intel B460 Chipset2 x PCIe 3.0 x1 slots
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC887 7.1-Channel High Definition Audio CODECJack-detection, Multi-streaming, Front Panel Jack-retaskingSupports up to 24-Bit/192kHz playbackAudio Features
Premium Japanese audio capacitors
Audio Shielding
Dedicated audio PCB layers
LAN Chipset1 xRealtek RTL8111H 1Gb Ethernet
Onboard USBRear USB (Total 6 ports)4 xUSB 3.2 Gen 1 ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
Front USB (Total 6 ports)
1 xUSB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports2 x USB 2.0 headers support additional 4 USB 2.0 ports

Questions about this item

What accessories are included with the ASUS EX-B460M-V5 motherboard?

The package contains the motherboard, one SATA cable and a chassis I/O back panel.

Which memory speed should I choose for this board?

The motherboard supports DDR4 at 2933, 2800, 2666, 2400 and 2133 MHz; select modules that match one of these speeds for up to 64 GB total.

What does the 1 Gb Ethernet port mean for my network connection?

The Realtek RTL8111H controller provides a wired link up to 1 Gbps, suitable for typical broadband and local file transfers.
