Green micro ATX motherboard with silver CPU socket and black memory slots

ASUS

ASUS EX-B760M-V5 D4 Intel motherboard

SKU CH-9J2H-QCW22

Micro-ATX board for Intel LGA 1700 CPUs with dual-channel DDR4 up to 64 GB and 2.5 Gb Ethernet

  • CPU Socket TypeLGA 1700
  • CPU TypeIntel Socket LGA1700 1st & 13th Gen processors for Intel Cor
  • ChipsetIntel B760
  • Memory StandardSupport dual-channel DDR4 5333 (OC)/5066 (OC)/5000 (OC)/4800
  • Maximum Memory Supported64GB
  • PCI SlotsIntel Core processors (14th & 13th & 12th Gen) 1 x PCIe 4.0
  • Supports 12, 13, 14 Gen Intel Core CPUs with LGA 1700 socket
  • Dual-channel DDR4 up to 5333 OC and 64 GB capacity
  • PCIe 4.0 x16 plus two PCIe 4.0 x1 slots for expansion
  • Realtek 2.5 Gb Ethernet for fast wired networking
  • Realtek 7.1 audio codec with 24-bit/192 kHz playback

Socket LGA 1700 micro-ATX board

The ASUS EX-B760M-V5 D4 is a micro-ATX motherboard built around the Intel B760 chipset for LGA 1700 processors. It accepts Intel Core 12, 13 and 14 generation CPUs plus Pentium Gold and Celeron parts. The board measures 24.4 by 21.1 centimetres and fits standard micro-ATX chassis.

Bundled SATA cable and I/O shield only

The package includes the motherboard, one SATA cable and the chassis I/O back panel. No other cables, manuals or driver media are supplied. The board provides four SATA III ports and two M.2 interfaces for storage, so the single cable covers one drive connection. Front-panel USB headers add six internal ports: one USB 3.2 Gen 1 header for two ports and two USB 2.0 headers for four ports.

Check DDR4 memory and cooler clearance

This board uses DDR4 memory only, supporting dual-channel kits up to 64 GB at speeds from 2133 to 5333 MT/s when overclocked. Verify that your CPU cooler fits the micro-ATX layout and does not block the two DIMM slots. The rear panel offers four USB 3.2 Gen 1 Type-A ports, two USB 2.0 Type-A ports and a Realtek 2.5 Gb Ethernet jack. Audio uses a Realtek 7.1 codec with 24-bit 192 kHz playback.

Highlights

  • Supports 12, 13, 14 Gen Intel Core CPUs with LGA 1700 socket
  • Dual-channel DDR4 up to 5333 OC and 64 GB capacity
  • PCIe 4.0 x16 plus two PCIe 4.0 x1 slots for expansion
  • Realtek 2.5 Gb Ethernet for fast wired networking
  • Realtek 7.1 audio codec with 24-bit/192 kHz playback

Specifications

BrandASUS
SeriesASUS EX-B760M-V5 D4
ModelASUS EX-B760M-V5 D4
CPU Socket TypeLGA 1700
CPU TypeIntel Socket LGA1700 1st & 13th Gen processors for Intel Core 14, Intel Core 12 Gen, Pentium Gold and Celeron processors *
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 **
ChipsetIntel B760
Memory StandardSupport dual-channel DDR4 5333 (OC)/5066 (OC)/5000 (OC)/4800 (OC)/4600 (OC)/4400 (OC)/4266 (OC)/4000 (OC)/3733 (OC)/3600 (OC)/3466 (OC)/3400 (OC)/3333 (OC)/3200/3000/2933/2800/2666/2400/2133MHz memory
Maximum Memory Supported64GB
PCI SlotsIntel Core processors (14th & 13th & 12th Gen)
1 x PCIe 4.0 x16 slot
Intel B760 chipset
2 x PCIe 4.0 x1 slots
SATA RAID2XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek 7.1 surround high fidelity Audio Codec *
- Support: jack detection, multi-stream, front panel jack reassignment
- Supports playback up to 24-bit/192 kHz
Audio features
- Advanced Audio Capacitors
- Audio masking
- Dedicated audio PCB layer
* Requires a chassis with a high definition audio module on the front panel to support 7.1 surround audio output.
LAN Chipset1 x Realtek 2.5Gb Ethernet
Onboard USBRear USB (6 ports in total)
4 x USB 3.2 Gen 1 ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
Front USB (6 ports in total)
1 x USB 3.2 Gen 1 connector supports 2 additional USB 3.2 Gen 1 ports
2 x USB 2.0 connectors support an additional 4 USB 2.0 ports

Questions about this item

Will the Realtek 7.1 audio codec need a driver update or capacitor replacement down the line?

The Realtek 7.1 surround codec uses advanced audio capacitors built onto the board; driver updates come from ASUS support pages and the capacitors are solid-state parts not scheduled for routine replacement.

What thermal limit appears first when the VRM runs a 14th Gen Core under sustained load?

The micro-ATX layout with a 24.4 by 21.1 cm PCB and no dedicated VRM heatsink shown means VRM temperature will throttle the CPU before the 2.5 Gb Ethernet or audio circuits hit any limit.

How loud does the chipset fan get when the 2.5 Gb Ethernet and all six SATA ports run 24/7?

The Intel B760 chipset is passively cooled, so only case and CPU fans produce noise; the Realtek 2.5 Gb Ethernet controller and four SATA III ports add negligible heat.
