Green micro-ATX board with black sockets and silver heatsinks

ASUS

ASUS EX-H410M-V3 Intel motherboard LGA 1200 DDR4 64GB Micro ATX

SKU CH-Z71T-C0S03

Micro-ATX board with LGA 1200 socket, DDR4 memory up to 64 GB, one PCIe 3.0 x16 slot, six SATA III ports, Realtek 7.1 audio and gigabit LAN

  • CPU Socket TypeLGA 1200
  • CPU TypeIntelp Socket LGA1200 for 10± Gen Intel Core, Pentiume Gold
  • ChipsetIntel H410
  • Memory StandardSupport DDR4 2933/2800/2666/2400/2133MHz memory
  • Maximum Memory Supported64GB
  • PCI SlotsIntelo 10th Gen Processors 1 x PCIe 3.0x16 slot (supports x1
  • Supports 10th Gen Intel Core processors on LGA 1200 socket
  • Up to 64GB DDR4 memory at 2933MHz for responsive multitasking
  • PCIe 3.0 x16 slot plus x1 slot for graphics and expansion cards
  • Realtek ALC887 7.1 surround sound with Japanese audio capacitors
  • Realtek RTL8111H 1Gb Ethernet and six rear USB ports including two USB 3.2 Gen 1

Socket & Chipset

The ASUS EX-H410M-V3 is a Micro ATX motherboard built around the Intel H410 chipset and the LGA 1200 socket. It accepts 10th generation Intel Core, Pentium Gold and Celeron processors with a 65 W power limit and 14 nm fabrication. The board targets budget office builds and basic home systems that need reliable Intel platform support.

Thermals, Noise & Power

The H410 chipset runs cool enough for passive cooling in typical desktop workloads, keeping system noise low. With a 65 W CPU ceiling the voltage-regulator area sees modest current, so standard case airflow is sufficient. No active chipset fan is present, eliminating a common source of high-frequency noise in compact chassis.

Memory Capacity

Four DDR4 slots support up to 64 GB at speeds of 2933, 2800, 2666, 2400 or 2133 MHz. This ceiling decides whether the board fits a multitasking workstation or stays limited to lighter duties.

Highlights

  • Supports 10th Gen Intel Core processors on LGA 1200 socket
  • Up to 64GB DDR4 memory at 2933MHz for responsive multitasking
  • PCIe 3.0 x16 slot plus x1 slot for graphics and expansion cards
  • Realtek ALC887 7.1 surround sound with Japanese audio capacitors
  • Realtek RTL8111H 1Gb Ethernet and six rear USB ports including two USB 3.2 Gen 1

Specifications

BrandASUS
SeriesASUS EX-H410M-V3
ModelASUS EX-H410M-V3
CPU Socket TypeLGA 1200
CPU TypeIntelp Socket LGA1200 for 10± Gen Intel Core, Pentiume Gold and CeleronsProcessors*
Supports up to Intel65W CPUSupports Intele 14nm CPU
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost MaxTechnology 3.0**
ChipsetIntel H410
Memory StandardSupport DDR4 2933/2800/2666/2400/2133MHz memory
Maximum Memory Supported64GB
PCI SlotsIntelo 10th Gen Processors
1 x PCIe 3.0x16 slot (supports x16 mode)
H410 Chipset
1 x PCIe 3.0 x1 slot
SATA RAID3XSATA III interface
Audio ChipsetRealtek ALC887 7.1 Surround Sound High Definition Audio CODEC
Jack-detection, Multi-streaming, Front Panel Jack-retasking
Supports up to 24-Bit192kHz playback
Audio Features
Premium Japanese audio capacitors
Audio Shielding
Dedicated audio PCB layers
LAN Chipset1 x Realtek RTL8111H 1Gb Ethernet
Onboard USBRear USB (Total 6 ports)
2 x USB 3.2 Gen 1 ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
Front USB (Total 4 ports)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports

Questions about this item

How do I fit the board into a Micro-ATX case and which standoff pattern is often missed?

The board measures 21.3 x 18.8 cm and uses the standard Micro-ATX mounting holes; the corner standoff near the I/O shield is the one builders most often forget to install.

Which onboard component will need attention after long-term use?

The Realtek RTL8111H 1 Gb Ethernet controller and Realtek ALC887 audio codec are soldered down; no user-serviceable parts are present, so only dust removal from the PCIe 3.0 x16 and x1 slots is practical.

What limit appears first when the CPU runs at full load for extended periods?

The power delivery is rated for processors up to 65 W, so sustained workloads that push the socket beyond that thermal envelope will throttle before any other onboard limit is reached.
