ASUS
ASUS FA401KM-DS74 gaming laptop
A 14 inch 165 Hz laptop with an AMD Ryzen AI 7 350 processor and GeForce RTX 5060 graphics for portable gaming power
- ColorJaeger Gray
- Operating SystemWindows 11 Home
- CPUAMD Ryzen AI 7 350
- Screen14"
- Memory16GB
- Storage1 TB
- 14-inch 165 Hz display for smooth gameplay
- AMD Ryzen AI 7 350 eight-core CPU for fast multitasking
- GeForce RTX 5060 Laptop GPU with 8 GB GDDR7 for high frame rates
- 16 GB LPDDR5x 7500 memory and 1 TB PCIe 4.0 NVMe SSD for quick loads
- 22 lb chassis with HDMI 2.1 and USB 3.2 Gen 2 ports for easy connectivity
14-inch 165 Hz Copilot+ gaming laptop
The ASUS TUF Gaming A14B26 pairs an AMD Ryzen AI 7 350 processor with an NVIDIA GeForce RTX 5060 Laptop GPU in a 14-inch chassis. Sixteen gigabytes of LPDDR5x 7500 memory and a 1 TB PCIe 4.0 NVMe M.2 SSD support fast load times. The 2560 x 1600 non-touch panel refreshes at 165 Hz for smooth motion. Windows 11 Home and Copilot+ PC features ship pre-installed.
Thermals, noise and power draw in daily use
The compact 12.24 by 8.94 by 0.67-0.78 inch frame weighs 3.22 lbs and relies on the TUF thermal design to manage the Ryzen AI 300 Series chip and RTX 5060 GPU. Wi-Fi 6E and Bluetooth 5.3 handle wireless duties without adding significant heat. One HDMI 2.1 port, one USB 3.2 Gen 2 Type-C and two USB 3.2 Gen 2 Type-A ports provide connectivity while the fans stay quiet during light workloads.
Sustained-load behaviour rather than burst
Under extended gaming or compute sessions the eight-core Ryzen AI 7 350 and its 16 MB L3 cache maintain clocks while the RTX 5060 Laptop GPU with 8 GB GDDR7 video memory drives the 165 Hz display. The 1 TB NVMe SSD sustains throughput without thermal throttling. Fan speed ramps up to keep the slim profile stable during long renders or multi-hour play sessions.
Highlights
- 14-inch 165 Hz display for smooth gameplay
- AMD Ryzen AI 7 350 eight-core CPU for fast multitasking
- GeForce RTX 5060 Laptop GPU with 8 GB GDDR7 for high frame rates
- 16 GB LPDDR5x 7500 memory and 1 TB PCIe 4.0 NVMe SSD for quick loads
- 22 lb chassis with HDMI 2.1 and USB 3.2 Gen 2 ports for easy connectivity
Specifications
| Brand | ASUS |
|---|---|
| Series | TUF Gaming A14B26 |
| Model | FA401KM-DS74 |
| Part Number | 90NR0KG1-M000A0 |
| Color | Jaeger Gray |
| Operating System | Windows 11 Home |
| CPU | AMD Ryzen AI 7 350 |
| Screen | 14" |
| Memory | 16GB |
| Storage | 1 TB |
| Graphics Card | NVIDIA GeForce RTX 5060 Laptop GPU |
| Video Memory | 8GB |
| AI Features | Copilot+ PC |
| Dimensions (W x D x H) | 12.24" x 8.94" x 0.67"-0.78" |
| Weight | 3.22 lbs. |
| CPU Type | AMD Ryzen AI 300 Series |
| Processor Name | AMD Ryzen AI 7 350 |
| Number of Cores | 8-core Processor |
| CPU L2 Cache | 8MB |
| CPU L3 Cache | 16 MB |
| Screen Size | 14" |
| Touchscreen | Non-Touch Screen |
| Wide Screen Support | Yes |
| Resolution | 2560 x 1600 |
| Refresh Rate | 165 Hz |
| GPU/VPU | GeForce RTX 5060 Laptop GPU |
| Graphic Type | Dedicated Card |
| SSD | 1TB NVMe |
| Storage Spec | 1 TB PCIe 4.0 NVMe M.2 SSD |
| Memory Speed | LPDDR5x 7500 |
| Max Memory Supported | 16 GB |
| Optical Drive Type | No |
| WLAN | 802.11ax Wireless LAN |
| WiFi Generation | Wi-Fi 6E |
| Bluetooth | Bluetooth 5.3 |
| USB | 1 x USB 3.2 Gen 2 Type-C / 2 x USB 3.2 Gen 2 Type-A |
| Thunderbolt | 1 x Thunderbolt 4 / USB4 |
| HDMI | 1 x HDMI 2.1 |
| Audio Ports | 1 x Headphone/Microphone Combo Jack |
| Audio | Built-in array microphone AI noise-canceling technology Dolby Atmos Hi-Res certification (for headphone) Support Microsoft Cortana near field/far field |
| Speaker | 2-speaker system |
| Virtual Reality Ready | Yes |
| Keyboard | Backlit Chiclet Keyboard Single Light With Copilot key |
| Backlit Keyboard | Backlit |
| Webcam | 1080P FHD IR Camera for Windows Hello |
| Card Reader | microSD (UHS-II) |
| Style | Thin and Light |
| Type | Gaming |
| Usage | Consumer |
| AC Adapter/Charger | 200W AC Adapter Output: 20V DC, 10A, 200W Input: 100-240V AC, 50/60Hz universal |
| Battery | 73WHrs, 4S1P, 4-cell Li-ion |
| Shipping weight | 2.70 kg |
| Package size | 445 × 295 × 81 mm |
Questions about this item
How do I install a second NVMe drive in the FA401KM-DS74 and what step do people miss?
The laptop ships with a single 1 TB PCIe 4.0 NVMe M.2 SSD installed; the chassis has only one M.2 slot, so a second drive cannot be added — buyers who order a second stick find nowhere to fit it.
Which component will need replacement first during the laptop's life?
The 16 GB LPDDR5x 7500 memory is soldered to the mainboard and the maximum supported capacity is 16 GB, so the RAM can never be upgraded or replaced without a full board swap.
What thermal limit appears first when the Ryzen AI 7 350 and RTX 5060 run flat-out for long sessions?
The 3.22 lb chassis measures only 0.67–0.78 in thick, leaving minimal heatsink volume; sustained loads push CPU and GPU clocks down within minutes as the cooling saturates.
