Green mini-ITX motherboard with silver heatsinks and black I/O shield

ASUS

ASUS H110I-PLUS LGA 1151 Intel H110 Mini ITX Intel Motherboard

SKU CH-V2EP-QTZZK

Mini-ITX board for LGA 1151 CPUs with DDR4 2133 support up to 32 GB, four SATA 6Gb/s ports, HDMI, USB 3.0 and gigabit LAN

  • CPU Socket TypeLGA 1151
  • CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1151)
  • Supported CPU TechnologiesTurbo Boost Technology 2.0
  • ChipsetIntel H110
  • Onboard Video ChipsetIntegrated Graphics
  • Number of Memory Slots2 x DIMM
  • Supports 6th/7th Gen Intel Core, Pentium and Celeron CPUs via LGA 1151 socket
  • Dual-channel DDR4 2133 memory up to 32 GB across two DIMM slots
  • Four SATA 6 Gb/s ports for high-capacity storage arrays
  • Realtek ALC887 7.1-channel audio with dedicated headphone amplification
  • Realtek RTL8111H Gigabit LAN plus HDMI, D-Sub and DVI video outputs

Compact LGA 1151 motherboard for small builds

The ASUS H110I-PLUS is a Mini ITX board built around the Intel H110 chipset. It accepts Core i7, i5, i3, Pentium and Celeron processors in the LGA 1151 socket. The compact layout targets compact desktop or embedded systems.

DDR4 2133 support up to 32 GB

Two DIMM slots run DDR4 2133 memory with a maximum capacity of 32 GB. This single specification decides whether the board matches your memory kit and capacity plans. Check your modules against the rated speed before purchase.

Fits Mini ITX cases with standard I/O

The board provides one PCI Express 3.0 x16 slot, four SATA 6Gb/s ports, HDMI, D-Sub and DVI video outputs, 7.1-channel audio via Realtek ALC887, and Gigabit LAN via Realtek RTL8111H. Rear I/O includes two USB 3.0 and four USB 2.0 ports plus a PS/2 combo port.

Highlights

  • Supports 6th/7th Gen Intel Core, Pentium and Celeron CPUs via LGA 1151 socket
  • Dual-channel DDR4 2133 memory up to 32 GB across two DIMM slots
  • Four SATA 6 Gb/s ports for high-capacity storage arrays
  • Realtek ALC887 7.1-channel audio with dedicated headphone amplification
  • Realtek RTL8111H Gigabit LAN plus HDMI, D-Sub and DVI video outputs

Specifications

BrandASUS
ModelH110I-PLUS
CPU Socket TypeLGA 1151
CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1151)
Supported CPU TechnologiesTurbo Boost Technology 2.0
ChipsetIntel H110
Onboard Video ChipsetIntegrated Graphics
Number of Memory Slots2 x DIMM
Memory StandardDDR4 2133
Maximum Memory Supported32GB
PCI Express 3.0 x161 x PCI Express 3.0 x16
Serial ATA (SATA)4 x SATA 6Gb/s
Audio ChipsetRealtek ALC887
Audio Channels7.1 Channels
LAN ChipsetRealtek RTL8111H
Max LAN Speed1Gbps
Back I/O Ports1 x HDMI / 1 x PS/2 Keyboard/Mouse Combo / 2 x USB 3.0 / 4 x USB 2.0/1.1
PS/21 x PS/2 keyboard/mouse port
Video PortsD-Sub + DVI
HDMI1 x HDMI
RJ451 x RJ45
USB 3.02 x USB 3.0
USB 1.1/2.04 x USB 2.0
Audio Ports3 Ports
Onboard USB1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s)1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
Other Connectors1 x COM port(s) connector(s)4 x SATA 6Gb/s connector(s)1 x CPU Fan connector(s) (1 x 4 -pin)1 x Chassis Fan connector(s) (1 x 4 -pin)1 x 24-pin EATX Power connector(s)1 x 4-pin ATX 12V Power connector(s)1 x Front panel audio connector(s) (AAFP)1 x Internal speaker connector(s)1 x System panel(s)1 x Chassis Intrusion connector(s)1 x Clear CMOS jumper(s)1 x 14-1 pin TPM connector
Form FactorMini ITX
Dimensions (W x L)6.7" x 6.7"
Power Pin24 Pin
FeaturesSupreme mini-ITX H110 with 5X Protection II for dependable stability, DDR4 support, and UEFI BIOS with EZ Flash 35X Protection II - Advanced hardware safeguards for all-round protectionDDR4 memory compatibilityMedia-acclaimed UEFI BIOS with EZ Flash 3Fan Xpert dedicated CPU and case fan controls for ultimate cooling and silent performanceAI Suite 3: One-stop access to innovative ASUS features

Questions about this item

How much DDR4 2133 memory can the H110I-PLUS actually use across its two slots?

The two DIMM slots support a combined maximum of 32GB of DDR4 2133 memory.

What display outputs does the board provide when paired with a CPU that has integrated graphics?

The rear panel includes one HDMI port plus D-Sub and DVI connectors for video output.

What physical footprint does the Mini ITX form factor require inside a case?

The board uses the standard Mini ITX mounting pattern with four screw holes.
