Green micro-ATX board with silver heatsinks and black ports

ASUS

ASUS H97M-E LGA 1150 Intel motherboard

SKU CH-T3SG-VNJ7X

Micro-ATX board with LGA 1150 socket, four DDR3 slots up to 16 GB, one PCIe x16 slot, three PCI slots, six SATA III ports, one M.2 slot, HDMI, DVI, VGA, six USB 3.0 and eight USB 2.0 ports.

  • CPU Socket TypeLGA 1150
  • CPU Type4th Gen Core i7/i5/i3/Pentium/Celeron
  • ChipsetH97
  • Number of Memory Slots4×DDR3 DIMM
  • Memory StandardDDR3 1600/1333MHz
  • Maximum Memory Supported16GB
  • Supports 4th Gen Intel Core processors on LGA 1150 socket
  • Four DDR3 DIMM slots handle up to 16 GB system memory
  • M.2 slot plus six SATA ports give flexible storage options
  • Six USB 3.0 and eight USB 2.0 ports cover peripheral needs
  • Micro ATX board measures 24.4 × 19.8 cm for compact builds

Socket and chipset

The ASUS H97M-E is a Micro ATX motherboard built around the Intel H97 chipset and the LGA 1150 socket. It accepts 4th Generation Core i7, i5, i3, Pentium and Celeron processors with integrated graphics.

Memory and expansion fit

Four DDR3 DIMM slots support dual-channel memory at 1600 or 1333 MHz up to 16 GB total. One PCI Express 3.0 x16 slot and three legacy PCI slots handle graphics and add-in cards, while six SATA III ports and a single M.2 connector provide storage options.

Rear I/O and onboard features

The back panel supplies one HDMI, one VGA and one DVI output for multi-monitor setups, six USB 3.0 ports, a PS/2 combo port and an Intel I218V Gigabit LAN jack. Onboard audio uses the Realtek ALC887 8-channel codec, and power is delivered through a 24-pin plus an 8-pin connector.

Highlights

  • Supports 4th Gen Intel Core processors on LGA 1150 socket
  • Four DDR3 DIMM slots handle up to 16 GB system memory
  • M.2 slot plus six SATA ports give flexible storage options
  • Six USB 3.0 and eight USB 2.0 ports cover peripheral needs
  • Micro ATX board measures 24.4 × 19.8 cm for compact builds

Specifications

BrandASUS
ModelH97M-E
CPU Socket TypeLGA 1150
CPU Type4th Gen Core i7/i5/i3/Pentium/Celeron
ChipsetH97
Number of Memory Slots4×DDR3 DIMM
Memory StandardDDR3 1600/1333MHz
Maximum Memory Supported16GB
PCI Express x161×PCI-E X16
PCI Slots3×PCI
Other Slots6×SATA III
M.21 x M.2
SATA RAID0/1/5/10
Back I/O Ports1 x HDMI / 1 x PS/2 Keyboard/Mouse Combo / 6 x USB 3.0
PS/21 x PS/2 keyboard/mouse port
Video PortsVGA, DVI
HDMI1 x HDMI
RJ451 x RJ45
USB 3.06×USB3.0
USB 1.1/2.08×USB2.0
Form FactorMicro ATX
Dimensions (W x L)24.4×19.8cm
FeaturesOnly motherboard and IO shield

Questions about this item

What CPU and memory do I need to use this LGA 1150 board with its DDR3 1600/1333 MHz slots?

You need a 4th Gen Core i7, i5, i3, Pentium or Celeron processor in the LGA 1150 socket and up to 16 GB of DDR3 DIMMs running at 1600 or 1333 MHz across the four slots.

Will my existing PCI cards and SATA drives work with the three PCI slots and six SATA III ports on this H97 board?

Yes, the three PCI slots accept legacy PCI cards and the six SATA III ports connect existing SATA hard drives or SSDs at up to 6 Gb/s.

How can I confirm the integrated graphics and Intel i218V Gigabit LAN are active after assembly?

Connect a display to the HDMI, DVI or VGA port to see video from the CPU's built-in graphics, then verify the RJ45 link light and network adapter appears in the OS.
