Green Micro ATX motherboard with silver LGA 1151 socket, black DDR4 slots, blue SATA ports and passive chipset heatsink

ASUS

ASUS Intel Expedition EX-B360M-V3 LGA 1151 DDR4 Micro ATX Motherboard

SKU CH-BPC7-QHEAM

Micro ATX board with Intel B360 chipset and LGA 1151 socket supporting DDR4 up to 2666 MHz and 32 GB capacity

  • CPU Socket TypeLGA 1151
  • ChipsetIntel B360
  • Form FactorMicro ATX
  • Supports 8th- and 9th-gen Intel Core processors on LGA 1151 socket
  • Dual-channel DDR4 memory up to 2666 MHz with 32 GB maximum capacity
  • Four SATA ports for HDD and SSD storage expansion
  • 8-channel HD audio for immersive sound
  • Micro ATX form factor fits compact PC builds

ASUS EX-B360M-V3 Micro ATX Motherboard

This board uses the Intel B360 chipset in a Micro ATX form factor and fits LGA 1151 processors including Intel Celeron, Core i3, Core i5 and Core i7. It provides two DDR4 DIMM slots that run in dual-channel mode and accept unbuffered modules at 2666, 2400 or 2133 MHz up to a total of 32 GB. Video output is available through an HDMI 1.4b port and the board supplies 8.0-channel audio. Passive cooling keeps the chipset silent.

Verify CPU Socket, Memory and Case Compatibility

Confirm that your processor uses the LGA 1151 socket and is from the supported Celeron, Core i3, Core i5 or Core i7 series before ordering. The board only has two DDR4 slots so plan your memory kit accordingly and ensure the modules are unbuffered non-ECC DDR4 rated for 2666, 2400 or 2133 MHz. Your chassis must accept a Micro ATX motherboard and provide clearance for the passive chipset heatsink.

Sustained Load Behaviour With Passive Cooling

Under continuous workloads the Intel B360 chipset relies entirely on its passive heatsink and the airflow inside your case to stay within safe temperatures. The voltage regulator area also uses passive cooling so adequate case ventilation becomes important during long rendering, compilation or gaming sessions. Onboard monitoring reports CPU, fan, power supply, temperature and voltage readings so you can observe thermal trends over time.

Highlights

  • Supports 8th- and 9th-gen Intel Core processors on LGA 1151 socket
  • Dual-channel DDR4 memory up to 2666 MHz with 32 GB maximum capacity
  • Four SATA ports for HDD and SSD storage expansion
  • 8-channel HD audio for immersive sound
  • Micro ATX form factor fits compact PC builds

Specifications

CPU Socket TypeLGA 1151
ChipsetIntel B360
Form FactorMicro ATX

Questions about this item

What comes in the box and what must be purchased separately?

The motherboard includes the board itself and an I/O shield. You must buy a compatible LGA 1151 processor, DDR4 memory modules, storage drives, power supply, case and CPU cooler separately.

Which memory capacity should I choose for the two DDR4 slots?

Each slot accepts 8 GB or 16 GB unbuffered DDR4 modules. For 32 GB total install two 16 GB sticks; for 16 GB total install two 8 GB sticks or one 16 GB stick.

What does the 2666 MHz memory speed mean once the board is built?

Supported DDR4 clocks are 2666, 2400 and 2133 MHz. The memory controller will run installed modules at the highest matching speed, so 2666 MHz rated RAM operates at that rate with a compatible processor.
