Black tall barebone mini PC with Intel Core i3-1315U processor

ASUS

ASUS NUC 13 Pro RNUC13ANHI30000UI barebone mini PC i3-1315U DDR4

SKU CH-AG9W-GX343 MPN RNUC13ANHI30000UI

Barebone mini PC with a 13th Gen Intel Core i3-1315U, dual DDR4-3200 SO-DIMM slots supporting 64 GB, one M.2 2280 PCIe Gen4x4 NVMe slot, 2.5 Gbps LAN.

  • ColorBlack
  • Form FactorTall
  • CPU TypeIntel Core i3-1315U
  • Memory installedNo Memory
  • Memory slot2 x 260Pin SO-DIMM
  • Memory Type SupportedDDR4 3200
  • 13th Gen Intel Core i3-1315U processor delivers responsive performance
  • Dual-channel DDR4 3200 SO-DIMM slots support up to 64GB memory
  • 5Gbps Intel Ethernet plus Wi-Fi 6E enable fast wired and wireless links
  • M.2 2280 PCIe Gen4x4 and SATA 6.0Gb/s bays accept NVMe or 2.5" storage
  • Dual HDMI 2.1 and Thunderbolt 4 Type-C ports drive up to four 4K displays

ASUS NUC 13 Pro i3-1315U Barebone

This ASUS NUC 13 Pro barebone mini PC uses a 13th Gen Intel Core i3-1315U processor with integrated Intel UHD Graphics. It arrives without memory, storage or an operating system so you add the parts that fit your workload. The tall black chassis includes a VESA mount for wall or behind-monitor placement. It targets businesses needing compact, 24x7-qualified systems.

Installing memory and storage

Two 260-pin SO-DIMM slots accept DDR4 3200 modules up to 64 GB total. One M.2 2280 PCIe Gen4x4 slot takes NVMe SSDs from 128 GB to 8 TB. The tall SKU also provides a SATA 6.0 Gb/s header for a 2.5-inch SATA drive up to 2 TB. Insert the modules, secure the drive screws and attach the VESA bracket before powering on.

Check your parts before ordering

Verify you have DDR4 3200 SO-DIMMs, not another DDR generation, because the slots are keyed for DDR4 only. Confirm any M.2 drive is an NVMe model, as the slot does not support SATA M.2 SSDs. If you plan a 2.5-inch drive, ensure it is a SATA unit within the 128 GB to 2 TB range. The system ships without an OS, so prepare installation media separately.

Highlights

  • 13th Gen Intel Core i3-1315U processor delivers responsive performance
  • Dual-channel DDR4 3200 SO-DIMM slots support up to 64GB memory
  • 5Gbps Intel Ethernet plus Wi-Fi 6E enable fast wired and wireless links
  • M.2 2280 PCIe Gen4x4 and SATA 6.0Gb/s bays accept NVMe or 2.5" storage
  • Dual HDMI 2.1 and Thunderbolt 4 Type-C ports drive up to four 4K displays

Specifications

BrandASUS
SeriesNUC 13 PRO
ModelRNUC13ANHI30000UI
Part Number90AR00C1-M00020
ColorBlack
Form FactorTall
CPU TypeIntel Core i3-1315U
Memory installedNo Memory
Memory slot2 x 260Pin SO-DIMM
Memory Type SupportedDDR4 3200
Max Memory Supported64GB (2 x 32GB)
Other1 x Kensington Lock Slot
Storage InstalledNo Hard Drive
Serial ATA1 x SATA 6.0Gb/s
M.2 Slot1 x M.2 2280 PCIe Gen4x4, supports 128GB~8TB NVMe SSD
Integrated GraphicsIntel UHD Graphics
LANIntel i226V
Max LAN Speed2.5Gbps
2.5" Internal Bays1 x SATA Power/DATA header for 2.5in SSD/HDD, supports 128GB~2TB SATA drive (Tall SKU only)
Front USB2 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps)
Front Audio Ports1 x Audio Jack (Line out/Mic in/Headphone out)
HDMI2 x HDMI 2.1 (up to 4K@60Hz)
Rear USB2 x Thunderbolt 4 (with DP1.4 / 5V/3A, 40Gbps)
1 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps)
1 x USB 2.0 Type-A (5V/0.5A, 480Mbps)
RJ451 x 2.5GbE (RJ45)
Other Rear Ports1 x Cable Locking Arm
1 x DC-in
Power Supply90W
Dimensions2.13" x 4.61" x 4.41"
PackagingVESA Mount & Screws / AC Power Adapter / Power Cord (US Only)
Shipping weight1.59 kg
Package size191 × 170 × 127 mm

Questions about this item

How do I confirm the Intel Core i3-1315U is running correctly after installing memory and storage?

Enter the BIOS on first boot to verify the processor is detected at 13th Gen, then check Task Manager in Windows to confirm 6 cores and 12 threads are active.

Which parts must I buy separately to complete this barebone unit?

You need two DDR4 3200 SO-DIMM modules up to 64 GB total, an M.2 2280 PCIe Gen4 NVMe SSD, and optionally a 2.5-inch SATA drive; no memory or storage is included.

Should I choose the tall or standard chassis for a 2 TB SATA drive?

Select the tall chassis — it includes a SATA power/data header that supports a 2.5-inch drive up to 2 TB, which the standard version lacks.
