Compact square mini PC, dark matte finish, front USB-C and USB-A ports visible

ASUS

ASUS NUC13ANHi5 barebone mini PC i5-1340P 16GB 512GB

SKU CH-6M5Q-40V0M MPN NUC13ANHi5

Compact barebone with 13th Gen Intel Core i5, 16 GB DDR4, 512 GB SSD, Intel Iris Xe graphics, dual Thunderbolt 4, 2.5 GbE LAN and Wi-Fi 6E

  • Integrated GraphicsIntel Iris Xe Graphics
  • Wireless LANIntel® Wi-Fi 6E AX211 (Gig+)
  • BluetoothBluetooth 5.3
  • LANIntel® Ethernet Controller i226-V
  • Max LAN Speed2.5Gbps
  • HDMI2 x HDMI 2.1 (TMDS)
  • 13th Gen Intel Core i5-1340P with 12 cores and 16 threads for responsive multitasking
  • Intel Iris Xe Graphics with 96 EU at 1.50 GHz dynamic frequency for crisp visuals
  • 16 GB DDR4 3200 dual-channel memory pre-installed, expandable to 64 GB
  • 512 GB SSD plus 2.5-inch SATA bay and M.2 slot for flexible storage growth
  • Dual Thunderbolt 4, dual HDMI 2.1, 2.5 GbE LAN, Wi-Fi 6E and Bluetooth 5.3 for versatile connectivity

Compact Business Mini PC

The ASUS NUC13ANHi5 is a 4x4 barebone system built around a 13th Gen Intel Core i5-1340P processor with 12 cores and 16 threads. It ships with 16GB of DDR4 3200 memory and a 512GB SSD installed. Integrated Intel Iris Xe Graphics with 96EU handles display output. The unit targets commercial deployments such as digital signage, thin-client fleets, and space-constrained office workstations.

Expansion And Connectivity

Two SO-DIMM slots support up to 64GB of dual-channel DDR4, while a 2.5-inch SATA bay accepts an additional 128GB to 2TB drive and an M.2 slot provides further storage flexibility. Video connects through two HDMI 2.1 ports and two Thunderbolt 4 Type-C ports. Wired networking uses a 2.5Gbps Intel i226-V controller, and wireless links run on Wi-Fi 6E AX211 with Bluetooth 5.3. Rear USB includes one 3.2 Gen 2 Type-A and one 2.0 Type-A port.

Sustained Workload Behaviour

The 12-core processor operates between 3.4 and 4.5GHz with 12MB Smart Cache, enabling consistent throughput for multi-threaded business applications and extended signage playback. Intel vPro Enterprise support allows hardware-based remote management and stability features for unattended operation. The ASUS NUC Pro Software Suite adds application monitoring and player failover tools that keep services running during long deployments. Thermal design maintains performance within the compact chassis without acoustic distraction.

Highlights

  • 13th Gen Intel Core i5-1340P with 12 cores and 16 threads for responsive multitasking
  • Intel Iris Xe Graphics with 96 EU at 1.50 GHz dynamic frequency for crisp visuals
  • 16 GB DDR4 3200 dual-channel memory pre-installed, expandable to 64 GB
  • 512 GB SSD plus 2.5-inch SATA bay and M.2 slot for flexible storage growth
  • Dual Thunderbolt 4, dual HDMI 2.1, 2.5 GbE LAN, Wi-Fi 6E and Bluetooth 5.3 for versatile connectivity

Specifications

BrandASUS
SeriesArena Canyon
ModelNUC13ANHi5
Integrated GraphicsIntel Iris Xe Graphics
Wireless LANIntel® Wi-Fi 6E AX211 (Gig+)
BluetoothBluetooth 5.3
LANIntel® Ethernet Controller i226-V
Max LAN Speed2.5Gbps
HDMI2 x HDMI 2.1 (TMDS)
Thunderbolt2 x Thunderbolt 4 Type-C
Rear USB1 x USB 3.2 Gen 2 Type-A
1 x USB 2.0 Type-A
RJ451 x RJ45 LAN
Memory slot2 x 262Pin SO-DIMM
Memory Type SupportedDDR4 3200
Max Memory Supported64GB
Dual Channel Memory SupportedYes
Memory installed16GB
Serial ATA1 x Support 128GB~2TB 2.5" SATA SSD/HDD Port
Storage Installed512GB SSD
M.2 Slot1 x M.2
CPU TypeIntel Core i5 13th Gen
Onboard AudioIntegrated
ChannelRealtek ALC269
Front USB2 x USB 3.2 Gen2 Type-A
Front Audio Ports1 x 3.5mm Headset Jack
Other Front Ports1 x Kensington Lock
Input20VDC, 6.0A
Power Supply120W
Dimensions117 x 112 x 54 [mm] (LxWxH)
Weight610g
PackagingOriginal packaging

Questions about this item

When does the i5-1340P hit its 12 MB Smart Cache limit during sustained workloads?

The 12 MB Smart Cache is shared across all 12 cores and 16 threads; once the working set exceeds that capacity the processor must fetch data from main memory, which becomes the first bottleneck under continuous heavy use.

How do thermals and fan noise behave during all-day operation with the Iris Xe 96EU graphics at 1.50 GHz?

The compact 4x4 chassis uses an internal blower that ramps up when the 28 W i5-1340P and Iris Xe 96EU sustain load; expect audible airflow but no published dB or surface-temperature figures are available.

Which display cables and mounts must I already own to use the dual HDMI 2.1 and Thunderbolt 4 ports?

You need two HDMI 2.1 cables for the HDMI outputs and USB-C or Thunderbolt 4 cables for the Type-C ports; a VESA bracket is also required if you plan to mount the unit behind a monitor.
