Compact silver mini PC with front ports and vents

ASUS

ASUS NUC13ANHi5 barebone mini PC i5-1340P 32GB DDR4 1TB

SKU CH-C2V7-0AM6H MPN NUC13ANHi5

Compact barebone with a 12-core i5-1340P, 32 GB DDR4, 1 TB storage, Intel Iris Xe graphics, 2.5 GbE LAN, Wi-Fi 6E and dual Thunderbolt 4 ports

  • Integrated GraphicsIntel Iris Xe Graphics
  • Wireless LANIntel® Wi-Fi 6E AX211 (Gig+)
  • BluetoothBluetooth 5.3
  • LANIntel® Ethernet Controller i226-V
  • Max LAN Speed2.5Gbps
  • HDMI2 x HDMI 2.1 (TMDS)
  • 13th Gen Intel Core i5-1340P with 12 cores and 16 threads for responsive multitasking
  • 32GB DDR4 3200 memory installed and expandable to 64GB for demanding workloads
  • 1TB storage fitted plus 2.5" SATA bay and M.2 slot for flexible capacity growth
  • Intel Iris Xe Graphics with 96EU and 2 x HDMI 2.1 for multi-display productivity
  • Dual Thunderbolt 4, 2.5GbE LAN, Wi-Fi 6E AX211 and Bluetooth 5.3 for fast connectivity

Compact Business Mini-PC

The ASUS NUC13ANHi5 is a 4x4 form-factor barebone built around a 13th Gen Intel Core i5-1340P processor with 12 cores and 16 threads. It arrives with 32GB of DDR4 3200 memory in dual-channel configuration and a 1TB drive already installed. Integrated Intel Iris Xe Graphics with 96 execution units handle visual output through two HDMI 2.1 ports and two Thunderbolt 4 Type-C connections.

Suited For Managed Deployments

IT teams gain Intel vPro Enterprise remote-management capabilities plus the ASUS NUC Pro Software Suite for application monitoring and player failover. The 2.5Gbps Ethernet, Wi-Fi 6E AX211 and Bluetooth 5.3 cover modern connectivity needs. Buyers who want more storage than the single 2.5-inch SATA bay and one M.2 slot provide should look at larger chassis. Users needing discrete graphics performance will also need a different platform.

Sustained-Load Behaviour

The 12-core processor runs at 3.4GHz base and can reach 4.5GHz turbo, while Iris Xe graphics operate up to 1.50GHz dynamic frequency. Under continuous workloads the compact thermal solution balances clock speeds to stay within its power envelope, so extended compile jobs or signage loops settle at stable frequencies rather than peak burst rates. Dual-channel memory and 2.5Gbps networking keep data flowing without bottlenecking the sustained throughput.

Highlights

  • 13th Gen Intel Core i5-1340P with 12 cores and 16 threads for responsive multitasking
  • 32GB DDR4 3200 memory installed and expandable to 64GB for demanding workloads
  • 1TB storage fitted plus 2.5" SATA bay and M.2 slot for flexible capacity growth
  • Intel Iris Xe Graphics with 96EU and 2 x HDMI 2.1 for multi-display productivity
  • Dual Thunderbolt 4, 2.5GbE LAN, Wi-Fi 6E AX211 and Bluetooth 5.3 for fast connectivity

Specifications

BrandASUS
SeriesArena Canyon
ModelNUC13ANHi5
Integrated GraphicsIntel Iris Xe Graphics
Wireless LANIntel® Wi-Fi 6E AX211 (Gig+)
BluetoothBluetooth 5.3
LANIntel® Ethernet Controller i226-V
Max LAN Speed2.5Gbps
HDMI2 x HDMI 2.1 (TMDS)
Thunderbolt2 x Thunderbolt 4 Type-C
Rear USB1 x USB 3.2 Gen 2 Type-A
1 x USB 2.0 Type-A
RJ451 x RJ45 LAN
Memory slot2 x 262Pin SO-DIMM
Memory Type SupportedDDR4 3200
Max Memory Supported64GB
Dual Channel Memory SupportedYes
Memory installed32GB
Serial ATA1 x Support 128GB~2TB 2.5" SATA SSD/HDD Port1
Storage Installed1TB
M.2 Slot1 x M.2
CPU TypeIntel Core i5 13th Gen
Onboard AudioIntegrated
ChannelRealtek ALC269
Front USB2 x USB 3.2 Gen2 Type-A
Front Audio Ports1 x 3.5mm Headset Jack
Other Front Ports1 x Kensington Lock
Input20VDC, 6.0A
Power Supply120W
Dimensions117 x 112 x 54 [mm] (LxWxH)
Weight610g
PackagingOriginal packaging

Questions about this item

What display cables do I need to connect two monitors to the HDMI 2.1 ports on this NUC?

Standard HDMI cables are sufficient; the unit provides two HDMI 2.1 (TMDS) outputs that drive two displays simultaneously.

Will my existing DDR4 3200 SO-DIMMs work alongside the installed 32GB memory in the two 262-pin slots?

Yes, the board supports dual-channel DDR4 3200 up to 64GB total, so compatible modules can be added to the second slot or replace the existing kit.

How can I confirm the Intel Iris Xe Graphics with 96EU is active after installing drivers?

Open Device Manager or the Intel Graphics Command Center; the adapter will be listed as Intel Iris Xe Graphics with 96 execution units and a 1.50GHz dynamic frequency.
