Small black square mini PC on a plain background

ASUS

ASUS NUC13ANKi7 barebone mini PC Core i7-1360P 64GB DDR4 2TB NVMe

SKU CH-NP23-P1FWF MPN NUC13ANKi7

Barebone mini PC with 13th Gen Intel Core i7-1360P, 64 GB DDR4-3200 and 2 TB NVMe, plus dual Thunderbolt 4, 2.5 GbE and Wi-Fi 6E

  • CPU TypeIntel Core i7 13th Gen
  • Memory installedNo Memory
  • Memory slot2 x 288Pin DIMM
  • Memory Type SupportedDDR4 3200
  • Max Memory Supported64GB
  • Dual Channel Memory SupportedYes
  • 12 cores and 16 threads handle heavy workloads
  • 64 GB DDR4-3200 dual-channel memory for smooth multitasking
  • 5 Gbps Ethernet plus Wi-Fi 6E for fast networking
  • Two Thunderbolt 4 ports drive dual 4K displays
  • 1-channel audio via HDMI for immersive sound

Compact barebone for commercial workloads

The ASUS NUC13ANKi7 is a 4x4 mini PC barebone built around an Intel Core i7-1360P processor with 12 cores and 16 threads. Integrated Iris Xe graphics with 96 execution units handle 4K output at 60 Hz over dual HDMI 2.1 ports. The chassis includes two M.2 slots and dual-channel DDR4-3200 support up to 64 GB.

Suited for IT-managed fleets

Buyers who need vPro Enterprise remote manageability, 2.5 Gbps Ethernet, Wi-Fi 6E and Bluetooth 5.3 in a space-saving enclosure will find the feature set aligned. Organisations that require discrete GPU performance, additional PCIe expansion or legacy serial ports should look elsewhere.

Dual M.2 layout dictates storage strategy

One M.2 2280 key M slot accepts PCIe 4.0 x4 NVMe drives and the second M.2 2242 key B slot accepts PCIe 3.0 x1 or SATA devices, so capacity and redundancy plans must fit those two physical interfaces.

Highlights

  • 12 cores and 16 threads handle heavy workloads
  • 64 GB DDR4-3200 dual-channel memory for smooth multitasking
  • 5 Gbps Ethernet plus Wi-Fi 6E for fast networking
  • Two Thunderbolt 4 ports drive dual 4K displays
  • 1-channel audio via HDMI for immersive sound

Specifications

BrandASUS
SeriesArena Canyon
ModelNUC13ANKi7
CPU TypeIntel Core i7 13th Gen
Memory installedNo Memory
Memory slot2 x 288Pin DIMM
Memory Type SupportedDDR4 3200
Max Memory Supported64GB
Dual Channel Memory SupportedYes
Storage InstalledNo Hard Drive
M.2 Slot2 x M.2
Discrete Graphic CardIntel Iris Xe Graphics 96EU
Onboard AudioIntegrated
Channel7.1 Channel
LANIntel® Ethernet Controller i226-V
Max LAN Speed2.5Gbps
Wireless LANIntel® Wi-Fi 6E AX211 (Gig+)
Bluetooth5.3
Front USB2x USB 3.2
Front Audio Ports3.5mm headphone/mic jack
Thunderbolt 32x Thunderbolt™ 4
Rear USB2x USB 4 (type C)
RJ451
Input20V
Power Supply120W
Dimensions117 x 112 x 37 [mm] (LxWxH)
Weight1.5kg
PackagingOriginal packaging

Questions about this item

How do I install memory in the NUC13ANKi7 and what step is often missed?

Open the chassis, insert two DDR4-3200 SODIMMs into the 288-pin slots at 1.2 V, then enable dual-channel mode in BIOS — skipping the BIOS step leaves the system in single-channel operation.

Which parts of the NUC13ANKi7 will need replacement or maintenance over time?

The CMOS battery on the motherboard will eventually need swapping; the M.2 2280 NVMe and 2242 SATA drives can be upgraded later, and the fan assembly can be cleaned or replaced if airflow drops.

What limit appears first on the NUC13ANKi7 during sustained heavy workloads?

The 35 W processor base power and compact thermal solution cause CPU throttling once the cooling saturates, capping sustained turbo below the 5.0 GHz peak.
