Green rectangular ATX server board with silver CPU socket, four black memory slots, dual LAN ports and silver heatsinks

ASUS

ASUS P11C-X LGA1151 C242 DDR4 ATX Intel motherboard

SKU CH-X88R-ZWAKS

ATX server board with LGA 1151 socket, Intel C242 chipset, dual Gigabit LAN, six SATA ports, dual M.2 slots and four DDR4 2666 DIMM slots supporting 64 GB

  • CPU Socket TypeLGA 1151
  • CPU TypeCore i7 / i5 / i3 (8th Gen, LGA1151)
  • ChipsetIntel C242
  • Onboard Video ChipsetAspeed AST2510 with 64MB VRAM
  • Number of Memory Slots4x288pin (DDR4)
  • Memory StandardDDR4 2666
  • Intel C242 chipset with LGA1151 socket supports Xeon E and 8th/9th Gen Core processors up to 95W
  • Dual Intel Gigabit LAN using I219-LM and I210AT controllers enables teaming for load balancing and failover
  • Four 288-pin DDR4 slots accept ECC and non-ECC UDIMM up to 128GB at 2666 MT/s
  • Dual M.2 slots up to 22110 length plus six SATA 6Gb/s ports provide flexible NVMe and SATA storage with RAID 0/1/5/10
  • ATX 12 x 9.6 inch rack-optimised layout positions CPU and memory for efficient airflow in 1U/2U chassis

Server Motherboard for Xeon E and Core i3

The ASUS P11C-X is an ATX server motherboard built on the Intel C242 chipset with an LGA1151 socket. It supports Intel Xeon E-2100 and E-2200 series processors as well as 8th and 9th generation Core i3, Pentium and Celeron CPUs up to 95W TDP. The board targets small to mid-size businesses needing a cost-effective platform for web, file, mail or storage servers and entry-level workstations.

Straightforward ATX Install with Rack Focus

Installation follows standard ATX 12 by 9.6 inch mounting points so it fits regular chassis and rack enclosures. The CPU and memory are positioned for maximum cooling efficiency in rack environments which helps thermal performance. Builders must use DDR4 2666 or 2400 UDIMMs in the four 288pin slots and should verify ECC or non-ECC compatibility with their chosen processor. Dual M.2 slots accept drives up to 22110 length for both PCIe and SATA interfaces.

128GB DDR4 Capacity Decides Fit

The four memory slots support up to 128GB of DDR4 2666 dual channel memory which is the key specification for memory-intensive server workloads. This capacity ceiling determines whether the board suits virtualization hosts, database servers or high-density storage nodes. Storage expandability includes 6 SATA 6Gb/s ports with RAID 0, 1, 5, 10 and two M.2 slots with RAID 0/1 while dual Intel Gigabit LAN (I219LM and I210AT) provides teaming support.

Highlights

  • Intel C242 chipset with LGA1151 socket supports Xeon E and 8th/9th Gen Core processors up to 95W
  • Dual Intel Gigabit LAN using I219-LM and I210AT controllers enables teaming for load balancing and failover
  • Four 288-pin DDR4 slots accept ECC and non-ECC UDIMM up to 128GB at 2666 MT/s
  • Dual M.2 slots up to 22110 length plus six SATA 6Gb/s ports provide flexible NVMe and SATA storage with RAID 0/1/5/10
  • ATX 12 x 9.6 inch rack-optimised layout positions CPU and memory for efficient airflow in 1U/2U chassis

Specifications

BrandASUS
SeriesServer Boards
ModelP11C-X
CPU Socket TypeLGA 1151
CPU TypeCore i7 / i5 / i3 (8th Gen, LGA1151)
ChipsetIntel C242
Onboard Video ChipsetAspeed AST2510 with 64MB VRAM
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 2666
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16
PCI Express x8PCI-E x8 (Gen3 X4 Link)
PCI Slots2xPCI 32bit/33MHz
Serial ATA (SATA)6 x SATA 6Gb/s
M.22 x M.2
SATA RAID0/1/0+1/5/10
LAN Chipset1 x Intel® I210AT
Second LAN Chipset1 x i219-LM
Max LAN Speed1Gbps
Back I/O Ports1 x PS/2 Keyboard/ Mouse Port
PS/21
RJ452 x RJ45 LAN Ports
DisplayPort1 x VGA Port (onboard Aspeed AST2510)
USB 3.12 x USB 3.1
USB 3.02 x USB 3.0
USB 1.1/2.02 x USB 2.0
Windows 11Supported
Form FactorATX
Dimensions (W x L)ATX (12"x9.6", 305mm x 244mm)
Power Pin24 Pin
Package ContentsThe Motherboard with an IO-Shield Only

Questions about this item

How can I confirm the ASpeed AST2510 video chipset is active after first boot?

Connect a monitor to the VGA port; the ASpeed AST2510 with 64MB VRAM will display POST output and BIOS screens without any discrete graphics card installed.

What comes in the box and what must I source separately?

The board ships with an I/O shield, SATA cables and documentation; you must supply an LGA1151 CPU up to 95W, DDR4 2666 UDIMMs (ECC or non-ECC), M.2 drives up to 22110 length and a standard ATX power supply.

Should I choose the 64GB or 128GB memory limit for my build?

The board has four 288-pin DDR4 slots supporting dual-channel operation; populate all four slots with 32GB modules to reach the 128GB ceiling, or use 16GB modules for a 64GB configuration.
