Green rectangular motherboard with silver CPU socket, two black memory slots, white PCI and blue PCIe slots, silver rear I/O panel

ASUS

ASUS P5GC-MX Intel 945GC LGA-775 DDR2 Intel motherboard

SKU CH-1FKK-JCKX8 MPN P5GC-MX

Intel 945GC micro-ATX board with LGA-775 socket, 2 GB DDR2 limit, integrated GMA 950 graphics, 5.1-channel audio, four SATA and one IDE port, plus two PCI and two PCI Express slots

  • Supports Intel LGA-775 processors up to 800 MHz FSB
  • Integrated Intel GMA 950 graphics for basic display output
  • Realtek ALC883 codec delivers 5.1 channel audio
  • Four SATA 300 ports and one IDE interface for storage
  • Two DDR2 slots accept up to 2 GB memory

Socket LGA-775 platform

The ASUS P5GC-MX is an Intel 945GC motherboard for Socket T LGA-775 processors. It supports Pentium 4, Pentium D, Celeron and Core 2 Duo CPUs with front-side bus speeds of 533 or 800 MHz. Two DDR2 slots accept up to 2 GB of DDR2-400 or DDR2-533 memory. Integrated Intel GMA 950 graphics and 5.1-channel Realtek ALC883 audio are built in.

Builders keeping legacy LGA-775 systems running

This board suits anyone repairing or maintaining an existing Socket T machine that needs integrated graphics and DDR2 memory. It does not suit builders who want more than two memory slots, higher memory capacity, discrete graphics expansion beyond a single PCI Express x16 slot, or modern storage interfaces.

Two DDR2 slots limited to 2 GB total

The maximum memory capacity is 2 GB across two DDR2 slots running at up to 533 MHz. This ceiling decides whether the board can meet the memory needs of the intended operating system and applications.

Highlights

  • Supports Intel LGA-775 processors up to 800 MHz FSB
  • Integrated Intel GMA 950 graphics for basic display output
  • Realtek ALC883 codec delivers 5.1 channel audio
  • Four SATA 300 ports and one IDE interface for storage
  • Two DDR2 slots accept up to 2 GB memory

Specifications

No published specifications for this item yet.

Questions about this item

How can I verify the Intel GMA 950 graphics are working after installing the board?

Enter the BIOS and confirm the on-board video chipset is detected, then boot the operating system and check that the display outputs an image at the native resolution without adding a separate graphics card.

What cables and accessories are included with the P5GC-MX and what must be sourced separately?

The box contains the motherboard, I/O shield, driver disc and user guide; SATA cables for the four SATA/300 ports, an IDE cable for the single IDE interface and a floppy cable are not included and must be purchased if those drives are used.

Which memory configuration should I choose for the two DDR2 slots given the 2 GB maximum?

Install two 1 GB DDR2-533/PC2-4200 modules to reach the 2 GB limit at the highest supported speed; a single 2 GB module is not supported because the chipset caps total memory at 2 GB across both slots.
