Green Micro ATX motherboard with silver heatsinks and black slots

ASUS

ASUS PRIME B250M-PLUS LGA 1151 Intel B250 Micro ATX motherboard

SKU CH-7MQP-3CD5F

Micro ATX board for LGA 1151 CPUs with four DDR4 slots up to 64 GB, one PCIe 3.0 x16 slot, six SATA ports, HDMI output and Intel gigabit LAN

  • CPU Socket TypeLGA 1151
  • CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1151)
  • Supported CPU TechnologiesTurbo Boost Technology 2.0 * Not Compatible with Intel 8th G
  • ChipsetIntel B250
  • Onboard Video ChipsetIntegrated Graphics Processor - Intel HD Graphics supportMul
  • Number of Memory Slots4x288pin (DDR4)
  • Supports 7th and 6th Gen Intel Core processors via LGA 1151 socket
  • Four DDR4 slots accept up to 64 GB at 2400 or 2133 MT/s
  • One M.2 Socket 3 key M supports 2242, 2260 and 2280 drives in SATA or PCIe x2 mode
  • Six SATA 6 Gb/s ports and two PCIe x16 slots (one at x4) give flexible storage and expansion
  • Realtek ALC887 8-channel audio and Intel I219-V Gigabit LAN handle sound and networking

Socket LGA 1151 Micro ATX Board

This motherboard uses the Intel B250 chipset and fits Micro ATX cases. It accepts Core i7, i5, i3, Pentium and Celeron processors built for the LGA 1151 socket. Four DDR4 slots support up to 64 GB of memory running at 2400 or 2133 MT/s in dual-channel mode.

Check CPU Generation Before Buying

The board does not work with 8th Generation Intel CPUs despite sharing the same physical socket. Verify that your processor is a 6th or 7th Generation part before ordering. Ensure your chassis has a Micro ATX mounting pattern and that your power supply provides the standard 24-pin and 4-pin CPU connectors required by this form factor.

Integrated Video Outputs And M.2 Flexibility

Onboard graphics from a compatible CPU can drive displays through HDMI, DVI-D and DisplayPort 1.2 connections. The single M.2 Socket 3 with M Key accepts 2242, 2260 or 2280 drives operating in either SATA or PCIe x2 mode, while a second M.2 slot supports PCIe x4 devices. Six SATA 6Gb/s ports and one PCIe x1 slot complete the expansion options.

Highlights

  • Supports 7th and 6th Gen Intel Core processors via LGA 1151 socket
  • Four DDR4 slots accept up to 64 GB at 2400 or 2133 MT/s
  • One M.2 Socket 3 key M supports 2242, 2260 and 2280 drives in SATA or PCIe x2 mode
  • Six SATA 6 Gb/s ports and two PCIe x16 slots (one at x4) give flexible storage and expansion
  • Realtek ALC887 8-channel audio and Intel I219-V Gigabit LAN handle sound and networking

Specifications

BrandASUS
ModelPRIME B250M-PLUS
CPU Socket TypeLGA 1151
CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1151)
Supported CPU TechnologiesTurbo Boost Technology 2.0 * Not Compatible with Intel 8th Gen CPUs
ChipsetIntel B250
Onboard Video ChipsetIntegrated Graphics Processor - Intel HD Graphics supportMulti-VGA output support: HDMI/DVI-D/DisplayPort 1.2 ports- Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz- Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz- Supports DisplayPort with max. resolution 4096 x 2304 @ 60 HzMaximum shared memory of 1024 MBSupports Intel InTru 3D, Quick Sync Video, Clear Video HD Technology, InsiderSupports up to 3 displays simultaneouslyDP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor daisy chain up to 3 displays
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 2400/2133
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCIe 3.0/2.0 x16 (x16 mode, gray)1 x PCIe 3.0/2.0 x16 (x4 mode, black)
PCI Express x11 x PCIe 3.0/2.0 x1
Serial ATA (SATA)6 x SATA 6Gb/s
M.21 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (both SATA & x2 PCIE mode) *11 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (x4 PCIE mode) *2*1 When a device in SATA mode is installed on the M.2_1 socket, SATA_1 port cannot be used.*2 Only M.2_2 socket can support Intel Optane Memory.
Audio ChipsetRealtek ALC887
Audio Channels8 Channels
LAN ChipsetIntel I219-V
Max LAN Speed1Gbps
PS/21 x PS/2 keyboard/mouse port
Video Ports1 x DVI-D1 x D-Sub
HDMI1 x HDMI
RJ451 x RJ45
DisplayPort1 x DisplayPort
USB 3.03 x USB 3.0 (blue) Type-A
USB 1.1/2.02 x USB 2.0
USB Type-C1 x USB 5Gb/s port(s) Type-C ( support 3A power output )
Audio Ports6 Ports
Onboard USB1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin)2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
Other Connectors1 x COM port(s) connector(s)1 x CPU Fan connector(s) (1 x 4-pin)2 x Chassis Fan connector(s) (2 x 4-pin)1 x S/PDIF out header(s)1 x 24-pin EATX Power connector(s)1 x 4-pin ATX 12V Power connector(s)1 x Front panel audio connector(s) (AAFP)1 x System panel(s)
Form FactorMicro ATX
Dimensions (W x L)9.6" x 8.8"
Power Pin24 Pin
FeaturesMulti-GPU Support:Supports AMD CrossFireX TechnologySpecial Features:ASUS 5X Protection III:- ASUS SafeSlot Core: Fortified PCIe Slot prevents damage- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!- ASUS Overvoltage Protection: World-class circuit-protecting power design- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!- ASUS DIGI+ VRM: 6 Phase digital power designASUS EPU:- EPUASUS Exclusive Features:- AI Suite 3- Ai Charger- ESD Guards- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interfaceAS
Package ContentsAccessories:User's manualI/O Shield2 x SATA 6Gb/s cable(s)2 x M.2 screws1 x Supporting DVD

Questions about this item

Does the board come with an I/O shield and cables, or must I buy them separately?

The motherboard ships with an I/O shield, two SATA 6Gb/s cables, a driver disc and a quick-start guide. No CPU, DDR4 memory, M.2 SSD or case standoffs are included.

Should I choose DDR4 2400 or DDR4 2133 modules for the four 288-pin slots?

Both standards work in the four slots up to 64 GB total. DDR4 2400 runs at its rated speed; DDR4 2133 runs at 2133 MHz. Pick 2400 for the highest supported frequency.

What does the HDMI 4096 x 2160 @ 24 Hz figure mean when I plug in a monitor?

The integrated Intel HD Graphics can drive one HDMI display at up to 4096 x 2160 resolution at 24 Hz. Higher refresh rates at that resolution are not supported over HDMI on this board.
