ATX motherboard in matte black with silver VRM and chipset heatsinks, four DDR5 slots, PCIe x16 slot, M.2 shield

ASUS

ASUS PRIME B650-PLUS WIFI AMD motherboard

SKU CH-3QP0-YM3QZ

Supports Ryzen 9000, 8000 and 7000 CPUs on AM5 with DDR5 up to 192 GB, PCIe 5.0 M.2, WIFI 6E, 2.5 Gb LAN and Thunderbolt 4 header

  • CPU Socket TypeAM5
  • ChipsetAMD B650
  • Number of Memory Slots4x288pin (DDR5)
  • Memory Standard7600+(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(
  • Maximum Memory Supported192GB
  • Channel SupportedDual Channel
  • Supports AMD Ryzen 9000, 8000 and 7000 series processors with AM5 socket
  • DDR5 memory up to 7600 MT/s overclocked across four slots for 192 GB maximum capacity
  • PCIe 5.0 M.2 slot, WIFI 6E and 2.5 Gbps LAN deliver high-speed connectivity
  • VRM, M.2 and PCH heatsinks plus hybrid fan headers keep thermals under control
  • BIOS FlashBack updates firmware safely without a CPU installed

AM5 Socket for Ryzen 9000 8000 7000 Series

This ATX motherboard fits the AM5 socket and supports AMD Ryzen Desktop 9000, 8000 and 7000 Series processors. Four DDR5 slots accept up to 192 GB of memory in dual-channel mode. The board provides a PCIe 4.0 x16 slot, four SATA 6 Gbps ports, 2.5 Gbps LAN, WIFI 6E and Bluetooth for a complete desktop foundation.

VRM M.2 and PCH Heatsinks Under Load

A dedicated VRM heatsink, an M.2 heatsink and a PCH heatsink work with hybrid fan headers and Fan Xpert 2+ to manage thermals during extended workloads. The PCIe 5.0 M.2 slot keeps storage temperatures in check while the power delivery remains stable across long rendering or compile sessions.

ATX Layout With Front USB Type-C

The ATX form factor offers four 288-pin DDR5 slots, a front-panel USB 10 Gbps Type-C connector and a Thunderbolt 4 header for high-speed peripherals. BIOS FlashBack updates firmware via a USB stick without a CPU installed. Aura Sync addressable Gen 2 and standard RGB headers let lighting match the rest of the build.

Highlights

  • Supports AMD Ryzen 9000, 8000 and 7000 series processors with AM5 socket
  • DDR5 memory up to 7600 MT/s overclocked across four slots for 192 GB maximum capacity
  • PCIe 5.0 M.2 slot, WIFI 6E and 2.5 Gbps LAN deliver high-speed connectivity
  • VRM, M.2 and PCH heatsinks plus hybrid fan headers keep thermals under control
  • BIOS FlashBack updates firmware safely without a CPU installed

Specifications

BrandASUS
SeriesB650
Model90MB1KP0-M0AAY0
CPU Socket TypeAM5
ChipsetAMD B650
Number of Memory Slots4x288pin (DDR5)
Memory Standard7600+(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200/5000
Maximum Memory Supported192GB
Channel SupportedDual Channel
ECC SupportedNon-ECC
PCI Express 4.0 x16AMD Ryzen™ 9000 & 7000 Series Desktop Processors*
1 x PCIe 4.0 x16 slot (supports x16 mode)
AMD Ryzen™ 8000 Series Desktop Processors
1 x PCIe 4.0 x16 slot (supports x8/x4 mode)**
Serial ATA (SATA)4 x SATA 6Gb/s
Audio Channels7.1 Channels
Max LAN Speed2.5Gbps
Wireless LANWIFI 6E
BluetoothYes
Form FactorATX
Windows 11Supported

Questions about this item

How much power does the VRM heatsink and Fan Xpert 2+ cooling handle when the Ryzen 9000 CPU runs all day?

The board uses a VRM heatsink, PCH heatsink, M.2 heatsink and hybrid fan headers controlled by Fan Xpert 2+ to manage thermals during sustained loads.

Which DDR5 memory kit do I need to reach the 7600 MT/s overclocked speed listed for the 4x288pin slots?

The four 288-pin slots support DDR5 up to 7600+(OC) and a maximum of 192 GB in dual-channel mode; non-ECC modules are required.

Will my existing SATA 6 Gbps drives and PCIe 4.0 x16 graphics card work without bandwidth loss on this B650 board?

Four SATA 6 Gbps ports and one PCIe 4.0 x16 slot running at x16 mode with Ryzen 9000 or 7000 CPUs provide full compatibility for current drives and GPUs.
