Green mATX motherboard with silver heatsinks and rear I/O shield

ASUS

ASUS PRIME B760M-A WIFI D4 LGA 1700 mATX Intel motherboard PCIe 4.0 two M.2 slots Realtek 2.5Gb Ethernet

SKU CH-Z6SZ-G6DY5

An Intel LGA 1700 mATX board with PCIe 4.0, two M.2 slots, 2.5 Gb Ethernet, Wi-Fi 6 and DDR4 support up to 128 GB

  • CPU TypeIntel Core 13th Gen (LGA 1700)
  • Supports 12th and 13th Gen Intel Core processors via LGA 1700 socket
  • PCIe 4.0 and two M.2 slots enable fast storage expansion
  • Realtek 2.5Gb Ethernet plus Wi-Fi 6 give high-speed wired and wireless connectivity
  • DDR4 memory up to 5333 MHz OC with ASUS OptiMem II for stable overclocking
  • DisplayPort 1.4 and HDMI 2.1 outputs support 4K 60 Hz video

Ready for 13th and 12th Gen Intel processors

The ASUS PRIME B760M-A WIFI D4 is an mATX motherboard built on the Intel B760 chipset with an LGA 1700 socket. It targets builders who want a compact board that supports current-generation Core, Pentium Gold and Celeron CPUs. Four DDR4 DIMM slots allow up to 128 GB of memory with XMP and OptiMem II support for overclocking headroom.

Check CPU cooler clearance

The board uses the LGA 1700 mounting pattern, so existing coolers must list that socket or include an adapter kit. Two M.2 slots are provided; verify the physical length of any drive you plan to install matches the slot spacing. Rear video outputs include DisplayPort 1.4 and two HDMI 2.1 ports, but integrated graphics depend entirely on the chosen processor.

VRM, M.2 and PCH heatsinks with hybrid fan headers

Onboard cooling covers the power delivery, the primary M.2 slot and the chipset, while Fan Xpert 2+ manages hybrid headers for PWM or DC fans. Front-panel connectivity includes a USB 3.2 Gen 1 Type-C header and USB 3.2 Gen 2 ports at the rear. Addressable Gen 2 and standard RGB headers enable Aura Sync lighting control. Realtek 2.5 Gb Ethernet and Wi-Fi 6 handle wired and wireless networking.

Highlights

  • Supports 12th and 13th Gen Intel Core processors via LGA 1700 socket
  • PCIe 4.0 and two M.2 slots enable fast storage expansion
  • Realtek 2.5Gb Ethernet plus Wi-Fi 6 give high-speed wired and wireless connectivity
  • DDR4 memory up to 5333 MHz OC with ASUS OptiMem II for stable overclocking
  • DisplayPort 1.4 and HDMI 2.1 outputs support 4K 60 Hz video

Specifications

CPU TypeIntel Core 13th Gen (LGA 1700)
