Black dual-fan graphics card with silver accents and PCIe 5.0 x8 connector

ASUS

ASUS PRIME GeForce RTX 5060 Ti 16GB graphics card PRIME-RTX5060TI-O16G

SKU CH-8XT1-BKP5F

16 GB GDDR7 memory on a 128-bit bus with 4608 CUDA cores, HDMI 2.1b, three DisplayPort 2.1b outputs and PCI Express 5.0 x8

  • InterfacePCI Express 5.0 x8
  • Chipset ManufacturerNVIDIA
  • GPU SeriesNVIDIA GeForce RTX 50 Series
  • GPUGeForce RTX 5060 Ti
  • ArchitectureBlackwell
  • CUDA Cores4608
  • 16 GB GDDR7 memory provides high bandwidth for 4K textures
  • 4608 CUDA cores accelerate rendering and compute workloads
  • PCI Express 5.0 x8 interface doubles host bandwidth over 4.0
  • DLSS 4.0 upscaling boosts frame rates with AI generation
  • HDMI 2.1b and three DisplayPort 2.1b outputs drive four displays

16GB GDDR7 for 1440p gaming

The ASUS PRIME GeForce RTX 5060 Ti 16GB targets players who need ample frame buffers at 1440p. Its 16GB of GDDR7 memory feeds 4608 CUDA cores through a 128-bit bus at 28 Gbps. The Blackwell architecture brings DLSS 4.0 upscaling and frame generation. A PCI Express 5.0 x8 link keeps data moving to modern platforms.

PCIe 5.0 x8 and modern display outputs

The card plugs into a PCI Express 5.0 x8 slot, compatible with current CPU platforms. Rear I/O provides one HDMI 2.1b port and three DisplayPort 2.1b connectors for up to four simultaneous displays. A black finish suits neutral builds. The 128-bit memory interface shapes PCB routing and cooler design.

Blackwell efficiency at 28 Gbps memory speed

GDDR7 at 28 Gbps delivers high bandwidth per watt, helping the Blackwell GPU stay composed under load. The 128-bit bus limits total power draw compared to wider designs. Fan curves can run at modest speeds during typical gaming sessions. DirectX 12 Ultimate and OpenGL 4.6 support ensure broad API coverage.

Highlights

  • 16 GB GDDR7 memory provides high bandwidth for 4K textures
  • 4608 CUDA cores accelerate rendering and compute workloads
  • PCI Express 5.0 x8 interface doubles host bandwidth over 4.0
  • DLSS 4.0 upscaling boosts frame rates with AI generation
  • HDMI 2.1b and three DisplayPort 2.1b outputs drive four displays

Specifications

BrandASUS
SeriesPRIME
ModelPRIME-RTX5060TI-O16G
Part Number90YV0MH2-M0AA00
InterfacePCI Express 5.0 x8
Chipset ManufacturerNVIDIA
GPU SeriesNVIDIA GeForce RTX 50 Series
GPUGeForce RTX 5060 Ti
ArchitectureBlackwell
CUDA Cores4608
Effective Memory Clock28 Gbps
Memory Size16GB
Memory Interface128-Bit
Memory TypeGDDR7
DirectXDirectX 12 Ultimate
OpenGLOpenGL 4.6
Multi-Monitor Support4
HDMI1 x HDMI 2.1b
DisplayPort3 x DisplayPort 2.1b
ColorBlack
Max Resolution7680 x 4320
CrossFireX SupportNo
SLI SupportNo
Virtual Reality ReadyYes
CoolerTriple Fans
Recommended PSU Wattage550W
Power Connector8-Pin
Features• AI Performance: 758 AI TOPS
• Powered by the NVIDIA Blackwell architecture and DLSS 4
• SFF-Ready Enthusiast GeForce Card
• Axial-tech fans feature a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure
• 2.5-slot design allows for greater build compatibility while maintaining cooling performance
• Dual-ball fan bearings last up to twice as long as standard sleeve bearings
• 0dB technology lets you enjoy light gaming in relative silence
• Dual BIOS switch lets you toggle between Quiet and Performance BIOS profiles
• Auto-Extreme man
Form FactorATX
Max GPU Length304 mm
Card Dimensions (L x H)304 x 120 x 50 mm
11.96 x 4.72 x 1.97 inch
Slot Width2.5 Slots

Questions about this item

Does the PCI Express 5.0 x8 interface limit bandwidth on a PCIe 4.0 motherboard?

The card runs at PCIe 5.0 x8 speeds; on a PCIe 4.0 slot it operates at 4.0 x8, which still delivers enough throughput for the GPU.

What physical space and power connections does the card need?

It occupies two expansion slots and draws power through a single 8-pin PCIe connector; check case length clearance and PSU cabling before buying.

What driver steps are required to enable DLSS 4.0?

Install the latest NVIDIA GeForce driver, then turn on DLSS 4.0 in each supported game's graphics settings; the feature is not active by default.
