Green Micro-ATX motherboard with silver LGA 1151 socket, two black DDR4 slots, blue USB 3.1 ports and black SATA connectors

ASUS

ASUS PRIME H310M-D Intel motherboard

SKU CH-4CK6-42DGE

Micro-ATX board with LGA 1151 socket, dual-channel DDR4 up to 32 GB, one PCIe 3.0 x16 slot, four SATA III ports, Realtek ALC887 audio and Gigabit LAN

  • CPU Socket TypeLGA 1151
  • CPU TypeLGA1151 socket for Intel 8th Generation Core i7 /i5 /i3, Pen
  • ChipsetIntel H310
  • Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 x PCI Express 3.0/2.0 x16 slot (at x16 mode) 2 x PCI Expre
  • Supports 8th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 up to 2666 MHz for responsive multitasking
  • 32 GB maximum memory capacity handles demanding workloads
  • Micro-ATX 22.6 x 18.5 cm form factor fits compact builds
  • Realtek 8111H Gigabit LAN with LANGuard protects network traffic

ASUS PRIME H310M-D LGA 1151 Micro ATX Motherboard

This board is an Intel H310 chipset motherboard built for the LGA 1151 socket. It accepts 8th Generation Intel Core i7, i5, i3, Pentium and Celeron processors. The Micro ATX form factor measures 22.6 by 18.5 cm and supports dual-channel DDR4 memory up to 32 GB.

Ideal for budget builds using 8th Gen Intel CPUs

It suits users assembling a basic office or home PC with a supported processor and up to 32 GB of DDR4 at 2666, 2400 or 2133 MHz. Builders needing CPU overclocking, multiple PCIe x16 slots, or newer 9th Generation support should choose a different chipset board.

LGA 1151 socket limited to 8th Generation Intel

The CPU socket only works with 8th Generation Intel Core, Pentium and Celeron chips on a 14 nm process. This constraint decides whether the motherboard matches your existing or planned processor.

Highlights

  • Supports 8th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 up to 2666 MHz for responsive multitasking
  • 32 GB maximum memory capacity handles demanding workloads
  • Micro-ATX 22.6 x 18.5 cm form factor fits compact builds
  • Realtek 8111H Gigabit LAN with LANGuard protects network traffic

Specifications

BrandASUS
SeriesASUS PRIME H310M-D
ModelASUS PRIME H310M-D
CPU Socket TypeLGA 1151
CPU TypeLGA1151 socket for Intel 8th Generation Core i7 /i5 /i3, Pentium , and Celeron processors
Supports Intel 14nm CPu
Supports Intel Turbo Boost Technology 2.0*
ChipsetIntel H310
Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 x PCI Express 3.0/2.0 x16 slot (at x16 mode)
2 x PCI Express 2.0 x1 slots
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC887 8-channel High Definition Audio CODEC
LAN ChipsetRealtek 8111H Gigabit LAN supports LANGuard
Onboard USBIntel H310 Chipset:
4 x USB 3.1 Gen 1 (up to 5Gbps) ports (2 ports at mid-board; 2 ports at backpanel, blue, Type A)
6 xUSB 2.0/1.1 ports (4 ports at mid-board; 2 ports at back panel)

Questions about this item

Should I pick the 32GB DDR4 option or a smaller kit for this H310 board?

The board supports up to 32GB of DDR4 across two slots, so a 32GB kit uses the full capacity while a 16GB kit leaves room to add more later.

What does the DDR4 2666MHz rating mean once the board is running in my PC?

Memory will run at up to 2666MHz in dual-channel mode; if you install slower 2400MHz or 2133MHz modules they will operate at their rated speed instead.

Which M.2 standard does the single slot use and what speed ceiling does it impose?

The single M.2 interface is wired through the H310 chipset using SATA signalling, so any drive installed there is limited to SATA III throughput.
