Green micro ATX motherboard with silver sockets and black heatsinks

ASUS

ASUS PRIME H310M-F Intel H310 LGA 1151 micro ATX motherboard

SKU CH-TJP4-VPZTT

Micro-ATX Intel H310 board for LGA 1151 CPUs with PCIe 3.0, USB 3.2 Gen 1, SATA 6 Gbps and Gigabit Ethernet

  • CPU Socket TypeLGA 1151

model PRIME H310M-F

  • Optimised trace routing for stable memory operation with ASUS OptiMem
  • Flexible fan curves and GPU-temperature sensing via Fan Xpert
  • Hardware safeguards from 5X Protection III for system longevity
  • PCIe 3.0 slot for graphics and add-in cards
  • SATA 6 Gbps ports for high-speed storage connections

Socket and Form Factor

The ASUS PRIME H310M-F is a micro ATX motherboard built around the Intel H310 chipset for LGA 1151 processors. It provides a compact foundation for office PCs, home workstations or basic gaming rigs that do not need enthusiast-class expansion. On-board Realtek 1 Gb Ethernet handles wired networking without an add-in card.

Who Should Choose This Board

Builders who want a small, affordable platform with PCIe 3.0 graphics support, D-Sub video output, USB 3.2 Gen 1 Type-A ports and SATA 6 Gbps storage will find the essentials covered. Buyers who need multiple full-length PCIe slots, integrated Wi-Fi, additional high-speed USB ports or overclocking headroom should look elsewhere.

Deciding Specification

The single specification that decides fit is the LGA 1151 socket paired with the H310 chipset; only processors designed for that socket and chipset combination will work, so confirm your CPU choice matches before purchase.

Highlights

  • Optimised trace routing for stable memory operation with ASUS OptiMem
  • Flexible fan curves and GPU-temperature sensing via Fan Xpert
  • Hardware safeguards from 5X Protection III for system longevity
  • PCIe 3.0 slot for graphics and add-in cards
  • SATA 6 Gbps ports for high-speed storage connections

Specifications

CPU Socket TypeLGA 1151

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What case size fits the micro ATX form factor of this ASUS PRIME H310M-F motherboard?

The micro ATX board fits any case that supports micro ATX or larger ATX form factors, using the standard mounting hole pattern.

How is the LGA 1151 processor installed on the ASUS PRIME H310M-F, and what step is often missed?

Lift the socket lever, align the CPU notches with the socket keys, place the chip gently, lower the lever, then secure the cooler — many forget to remove the protective socket cover first.

Which components on the ASUS PRIME H310M-F may need replacement after several years of use?

The CMOS battery that keeps BIOS settings and the electrolytic capacitors near the CPU power phase are the parts most likely to require replacement over time.
