Green micro-ATX board with silver PCIe slots and black I/O shield

ASUS

ASUS PRIME H310M-K Intel Motherboard

SKU CH-J5EK-DEC0Z

Micro-ATX board for 8th-generation Intel Core CPUs with two DDR4 slots up to 32 GB, one PCIe 3.0 x16 slot, four SATA 6Gb/s ports, 7.1-channel audio and two USB 3.1 Gen 2 ports

  • CPU Socket TypeLGA 1151 (300 Series)
  • CPU TypeCore i7 / i5 / i3 (8th Gen, LGA1151)
  • Supported CPU TechnologiesTurbo Boost Technology 2.0
  • ChipsetIntel H310
  • Onboard Video ChipsetSupported only by CPU with integrated graphic
  • Number of Memory Slots2x288pin (DDR4)
  • Supports 8th Gen Intel Core i7, i5, i3 processors via LGA 1151 socket
  • Dual-channel DDR4 2666 memory up to 32 GB across two 288-pin slots
  • PCIe 3.0 x16 slot reinforced with SafeSlot Core for heavy GPU stability
  • Four SATA 6Gb/s ports and two USB 3.1 Gen 2 Type-A ports on rear I/O
  • Realtek ALC887 8-channel HD audio and Realtek 8111H Gigabit LAN built in

Socket LGA 1151 uATX Motherboard

The ASUS PRIME H310M-K is a micro-ATX board built on the Intel H310 chipset for 8th generation Core i7, i5 and i3 processors. It fits compact cases while providing the essential connectivity for a mainstream desktop build.

Ideal for Office and Home Builds

This board suits users assembling a basic productivity PC or upgrading an older LGA 1151 system with two DDR4 slots and four SATA 6Gb/s ports. Builders who need multiple graphics cards, extensive USB 3.1 Gen 2 headers, or overclocking headroom should consider a different chipset.

Dual-Channel DDR4 up to 32 GB

The two 288-pin slots support DDR4 2666 memory in dual-channel mode with a maximum capacity of 32 GB. This memory ceiling is the key figure that determines whether the board matches the planned system RAM.

Highlights

  • Supports 8th Gen Intel Core i7, i5, i3 processors via LGA 1151 socket
  • Dual-channel DDR4 2666 memory up to 32 GB across two 288-pin slots
  • PCIe 3.0 x16 slot reinforced with SafeSlot Core for heavy GPU stability
  • Four SATA 6Gb/s ports and two USB 3.1 Gen 2 Type-A ports on rear I/O
  • Realtek ALC887 8-channel HD audio and Realtek 8111H Gigabit LAN built in

Specifications

BrandASUS
ModelPRIME H310M-K
CPU Socket TypeLGA 1151 (300 Series)
CPU TypeCore i7 / i5 / i3 (8th Gen, LGA1151)
Supported CPU TechnologiesTurbo Boost Technology 2.0
ChipsetIntel H310
Onboard Video ChipsetSupported only by CPU with integrated graphic
Number of Memory Slots2x288pin (DDR4)
Memory StandardDDR4 2666
Maximum Memory Supported32GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16
PCI Express x12 x PCI Express x1
Serial ATA (SATA)4 x SATA 6Gb/s
Audio ChipsetRealtek ALC887
Audio Channels8 Channels
LAN ChipsetRealtek 8111H
Max LAN Speed1Gbps
Back I/O Ports2 x PS/2 / 2 x USB 2.0/1.1 / 2 x USB 3.1 Gen 2 Type-A
PS/22
Video PortsD-Sub + DVI
RJ451 x RJ45
USB 3.12 x USB 3.1
USB 1.1/2.02 x USB 2.0
Audio Ports3 Ports
Onboard USB2 x USB 3.1 + 4 x USB 2.0
Other Connectors1 x 4-pin CPU Fan connector for 4-pin PWM mode1 x 4-pin Chassis Fan connector for 3-pin (DC mode) and 4-pin (PWM mode) coolers control1 x Front panel audio connector1 x COM header1 x S/PDIF Out header1 x Speaker connector1 x Clear CMOS jumper (2-pin)1 x System Panel connector
Form FactoruATX
Dimensions (W x L)8.9" x 7.3"
Power Pin24 Pin
FeaturesASUS Special Features:ASUS 5X PROTECTION III:- ASUS SafeSlot Core: Fortified PCIe Slot prevents damage- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!- ASUS Overvoltage Protection: World-class circuit-protecting power design- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!- ASUS DIGI+ VRM: 4 Phase digital power designSuperb Performance:- The latest transfer technologies with up to 10Gb/s data transfer speedsUEFI BIOS- Most advanced options with fast response timeASUS OptiMem- Improved DDR4 stabilityGamin
Package ContentsAccessories:2 x Serial ATA 6.0Gb/s cables1 x I/O Shield1 x Support DVD1 x User's manual

Questions about this item

What maximum transfer rate do the four SATA 6Gb/s ports deliver in practice?

The four SATA 6Gb/s ports each support up to 6 Gb/s, so a SATA SSD or HDD connected to any of them can reach its rated sequential speed without a bottleneck from the motherboard.

How much clearance does the uATX board need inside a case?

The board measures 8.9 inches wide by 7.3 inches deep, so any chassis that accepts Micro-ATX will have the required mounting holes and internal space.

What is the correct way to seat the DDR4 DIMMs and which mistake should I avoid?

Open the single retention clip on each 288-pin DDR4 slot, align the notch on the module with the slot key, press straight down until the clip snaps shut, and do not force a module in backwards — the notch position prevents that, but excessive pressure can damage the slot.
