Green Micro ATX motherboard with silver LGA 1200 socket, black DDR4 slots and blue PCIe slots

ASUS

ASUS PRIME H410M-F LGA 1200 DDR4 64GB Micro ATX Intel motherboard

SKU CH-CQ97-FR14M

Micro ATX Intel H410 board with LGA 1200 socket for 10th Gen CPUs up to 65 W, four DDR4 slots to 64 GB, one PCIe 3.0 x16 and one x1 slot, three SATA III ports.

  • CPU Socket TypeLGA 1200
  • CPU TypeIntel Socket LGA1200 for 10t Gen Intel Core, Pentiume Gold a
  • ChipsetIntel H410
  • Memory StandardSupport DDR4 2933/2800/2666/2400/2133MHz memory
  • Maximum Memory Supported64GB
  • PCI SlotsIntel 10th Gen Processors1 x PCIe 3.0 x16 slot (supports x16
  • Supports 10th Gen Intel Core, Pentium Gold and Celeron processors via LGA 1200 socket
  • Up to 64GB DDR4 memory at speeds up to 2933MHz
  • PCIe 3.0 x16 and x1 slots for graphics and expansion cards
  • Realtek ALC887 7.1 surround sound with dedicated audio layers and shielding
  • Realtek RTL8111H 1Gb Ethernet with six rear USB ports including two USB 3.2 Gen 1

Socket LGA 1200 Micro ATX Board

The ASUS PRIME H410M-F is a Micro ATX motherboard built on the Intel H410 chipset for 10th Generation Intel Core, Pentium Gold and Celeron processors. It fits LGA 1200 CPUs rated up to 65 W and supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0. The board measures 21.3 by 18.8 cm and accepts up to 64 GB of DDR4 memory across two slots.

Bundled SATA Cable And I/O Shield

The retail package adds a single SATA cable and the chassis I/O back panel so you can connect one drive and finish the rear ports immediately. No other cables, brackets or documentation are included. The board itself provides three SATA III interfaces, six rear USB ports (two USB 3.2 Gen 1 Type-A and four USB 2.0 Type-A) plus front-panel headers for two more USB 3.2 Gen 1 and four USB 2.0 ports.

Budget Builders Needing Basic 10th Gen Support

This board suits builders assembling a low-cost office or home PC with a 65 W 10th Generation Intel processor and standard DDR4 memory. It offers 7.1 surround audio via the Realtek ALC887 codec, a single PCIe 3.0 x16 slot, one PCIe 3.0 x1 slot and 1 Gb Ethernet from the Realtek RTL8111H controller. Users who need overclocking, multiple M.2 drives, higher-wattage CPUs or newer processor generations should choose a different chipset.

Highlights

  • Supports 10th Gen Intel Core, Pentium Gold and Celeron processors via LGA 1200 socket
  • Up to 64GB DDR4 memory at speeds up to 2933MHz
  • PCIe 3.0 x16 and x1 slots for graphics and expansion cards
  • Realtek ALC887 7.1 surround sound with dedicated audio layers and shielding
  • Realtek RTL8111H 1Gb Ethernet with six rear USB ports including two USB 3.2 Gen 1

Specifications

BrandASUS
SeriesASUS PRIME H410M-F
ModelASUS PRIME H410M-F
CPU Socket TypeLGA 1200
CPU TypeIntel Socket LGA1200 for 10t Gen Intel Core, Pentiume Gold and
Celeron Processors*
Supports up to Intel 65W CPUSupports Intel 14nm CPU
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost MaxTechnology 3.0**
ChipsetIntel H410
Memory StandardSupport DDR4 2933/2800/2666/2400/2133MHz memory
Maximum Memory Supported64GB
PCI SlotsIntel 10th Gen Processors1 x PCIe 3.0 x16 slot (supports x16 mode)
Intel H410 Chipset
1 x PCIe 3.0 x1 slot
SATA RAID3XSATA III interface
Audio ChipsetRealtek ALC887 7.1 Surround Sound High Definition Audio CODEC
Jack-detection, Multi-streaming, Front Panel Jack-retasking
Supports up to 24-Bit192kHz playback
Audio Features
Audio Shielding
Dedicated audio PCB layers
LAN Chipset1 x Realtek RTL8111H 1Gb Ethernet
Onboard USBRear USB (Total 6 ports)2 x USB 3.2 Gen 1 ports (2 xType-A)4 x USB 2.0 ports (4 x Type-A)Front USB (Total 4 ports)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports1 x USB 2.0 header supports additional 2 USB 2.0 ports

Questions about this item

Will the Realtek ALC887 audio codec need a driver update or replacement during the board's life?

The Realtek ALC887 codec is integrated and does not require hardware replacement; driver updates are handled through the operating system or ASUS support site if needed.

What limits sustained CPU performance on this H410 board?

The board supports CPUs up to 65 W TDP; sustained loads on higher-power processors will hit the VRM thermal limit first.

How loud and hot does the board get when running all day?

With no active chipset fan, noise depends on the CPU cooler; the H410 chipset and Realtek RTL8111H LAN run cool under typical 24/7 workloads.
