Green Micro ATX motherboard with silver CPU socket and four black DDR4 slots

ASUS

ASUS PRIME H510M-K LGA 1200 DDR4 64GB Micro ATX Intel Motherboard

SKU CH-Q0GF-YV3DN

Micro-ATX Intel H510 board for LGA 1200 CPUs with dual-channel DDR4 up to 64 GB, one PCIe 4.0 x16 slot, four SATA III ports, Intel 1 Gb LAN and 7.1 audio

  • CPU Socket TypeLGA 1200
  • CPU TypeIntel Socket LGA1200 for 11th Gen Intel Core Processors & 10
  • ChipsetIntel H510
  • Memory StandardSupport dual-channel DDR4 3200 (OC)/2933/2800/2666/2400/2133
  • Maximum Memory Supported64GB
  • PCI SlotsIntel 11th & 10th Gen Processors 1 x PCIe 4.0/3.0 x16 slot -
  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 64GB with speeds to 3200MHz (OC)
  • PCIe 4.0 x16 graphics slot available with 11th Gen CPUs
  • Realtek 7.1 surround audio with shielding and 24-bit/192kHz playback
  • Six rear USB ports including two USB 3.2 Gen 1 Type-A connections

Socket and Chipset

The ASUS PRIME H510M-K is a Micro ATX motherboard built on the Intel H510 chipset with an LGA 1200 socket. It accepts 10th and 11th Gen Intel Core, Pentium Gold and Celeron processors. The board supports dual-channel DDR4 memory up to 64GB at speeds including 3200 (OC), 2933, 2800, 2666, 2400 and 2133MHz. It provides one PCIe x16 slot and one PCIe x1 slot plus four SATA III ports and one M.2 interface.

Upgrade Path

This board replaces an older LGA 1200 platform or serves as a fresh foundation for a 10th or 11th Gen Intel build. The jump is worth it when moving to a supported CPU that can use PCIe 4.0 x16 on 11th Gen or PCIe 3.0 x16 on 10th Gen. Realtek ALC897/887 7.1 audio with shielding and Intel 1Gb Ethernet with LANGuard are integrated. Rear I/O includes two USB 3.2 Gen 1 Type-A and four USB 2.0 Type-A ports. Internal headers add two more USB 3.2 Gen 1 and two USB 2.0 ports.

Installation Notes

The Micro ATX form factor measures 22.6 by 21.1cm and fits standard Micro ATX or larger cases. Mount the board using the standard standoff pattern, connect the 24-pin and CPU power headers, then install memory into the two DDR4 slots. The single M.2 slot and four SATA III connectors handle storage. Common issues include forgetting the I/O shield, not seating the CPU power cable fully, and mismatching 10th versus 11th Gen CPU expectations for PCIe lane speed.

Highlights

  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 64GB with speeds to 3200MHz (OC)
  • PCIe 4.0 x16 graphics slot available with 11th Gen CPUs
  • Realtek 7.1 surround audio with shielding and 24-bit/192kHz playback
  • Six rear USB ports including two USB 3.2 Gen 1 Type-A connections

Specifications

BrandASUS
SeriesASUS PRIME H510M-K
ModelASUS PRIME H510M-K
CPU Socket TypeLGA 1200
CPU TypeIntel Socket LGA1200 for 11th Gen Intel Core Processors & 10th Gen Intel Core , Pentium Gold and Celeron Processors
Supports Intel 14 nm CPU
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0**
ChipsetIntel H510
Memory StandardSupport dual-channel DDR4 3200 (OC)/2933/2800/2666/2400/2133MHz memory
Maximum Memory Supported64GB
PCI SlotsIntel 11th & 10th Gen Processors
1 x PCIe 4.0/3.0 x16 slot
- Intel 11th Gen processors support PCIe 4.0 x16
- Intel 10th Gen processors support PCIe 3.0 x16
Intel H510 Chipset
1 x PCIe 3.0 x1 slot
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Dedicated audio PCB layers
LAN Chipset1 x Intel 1Gb Ethernet
ASUS LANGuard
Onboard USBRear USB:Total 6 ports
2 x USB 3.2 Gen 1 ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports

Questions about this item

Will this board take a 10th-generation Core i5 and run its memory at 3200 MHz?

The socket accepts 10th and 11th generation Core, Pentium Gold and Celeron processors. With a 10th-generation CPU the top supported DDR4 speed is 2933 MHz; 3200 MHz is only available when overclocking with an 11th-generation processor.

How many internal drives can I connect at once?

Four SATA III ports and one M.2 interface are provided, so you can attach up to four SATA drives plus one M.2 drive simultaneously.

Does the rear panel include any video outputs for integrated graphics?

The specification lists six rear USB ports, Intel 1Gb Ethernet and 7.1 audio jacks, but no video connectors are mentioned.
