Green Micro ATX motherboard, LGA 1200 socket, DDR4 slots, PCIe x16, SATA ports, rear I/O panel

ASUS

ASUS Prime H510M-K R2.0 Intel motherboard

SKU CH-6EF6-NGPPZ

Micro ATX board for 10th and 11th Gen Intel CPUs with LGA 1200 socket, dual-channel DDR4 up to 64 GB, PCIe 4.0 and 3.0 slots, four SATA ports and 1 Gbps LAN

  • CPU Socket TypeLGA 1200
  • CPU TypeCore i9 / i7 / i5 / i3 (11th / 10th Gen, LGA1200)
  • Number of Memory Slots2x288pin (DDR4)
  • Maximum Memory Supported64GB
  • Channel SupportedDual Channel
  • PCI Express 4.0 x161 x PCI Express 4.0 x16
  • Supports 11th and 10th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 64 GB across two 288-pin slots
  • PCIe 4.0 x16 and PCIe 3.0 x16 slots for graphics and expansion
  • Four SATA 6 Gb/s ports plus Gigabit LAN for storage and network connectivity
  • Micro ATX form factor with HDMI and multiple USB 3.2 Gen 1 and USB 2.0 ports

ASUS Prime H510M-K R2.0 motherboard

This Micro ATX board uses the Intel H510 chipset and an LGA 1200 socket for 10th and 11th Generation Core i9, i7, i5 and i3 processors. It provides two DDR4 slots that support up to 64 GB in dual-channel mode. The layout includes one PCIe 4.0 x16 slot, one PCIe 3.0 x16 slot and four SATA 6 Gb/s ports. A single Gigabit Ethernet port handles wired networking.

Check your parts before ordering

Verify that your CPU is a 10th or 11th Generation Intel Core processor with an LGA 1200 package. Ensure you have DDR4 memory modules, because the board has two 288-pin slots and does not accept other memory types. Confirm your chassis can fit a Micro ATX motherboard and that your power supply carries the required ATX and CPU power connectors. The board offers one PCIe 4.0 x16 and one PCIe 3.0 x16 slot, so plan expansion cards accordingly.

Rear I/O and onboard headers

The back panel supplies one HDMI output, two USB 3.2 Gen 1 Type-A ports and four USB 2.0 ports alongside the RJ-45 LAN jack. Internal headers provide additional USB 2.0 and front-panel connections for case controls. The UEFI BIOS includes a search function and an advanced tuning mode for manual adjustments. ASUS software utilities let you monitor temperatures, control fan curves and update the firmware from within Windows.

Highlights

  • Supports 11th and 10th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 64 GB across two 288-pin slots
  • PCIe 4.0 x16 and PCIe 3.0 x16 slots for graphics and expansion
  • Four SATA 6 Gb/s ports plus Gigabit LAN for storage and network connectivity
  • Micro ATX form factor with HDMI and multiple USB 3.2 Gen 1 and USB 2.0 ports

Specifications

BrandASUS
SeriesPrime
ModelH510M-K R2.0
CPU Socket TypeLGA 1200
CPU TypeCore i9 / i7 / i5 / i3 (11th / 10th Gen, LGA1200)
Number of Memory Slots2x288pin (DDR4)
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 4.0 x161 x PCI Express 4.0 x16
PCI Express 3.0 x161 x PCI Express 3.0 x16
Serial ATA (SATA)4 x SATA 6Gb/s
Max LAN Speed1Gbps
Form FactorMicro ATX

Questions about this item

Does the motherboard ship with any cables, back-plate or mounting hardware, or must those be purchased separately?

The retail box includes the board, a rear I/O shield, SATA cables and the usual mounting screws. No CPU, memory, storage, graphics card or operating system are supplied.

Should I choose a 10th or 11th Generation Intel Core i9, i7, i5 or i3 processor for the LGA 1200 socket?

Both 10th and 11th Generation Core i9, i7, i5 and i3 CPUs fit the LGA 1200 socket. Pick the generation and tier that match your performance target and budget.

What does the single PCI Express 4.0 x16 slot mean for a graphics card or add-in card installed in this Micro ATX board?

The top x16 slot runs at PCIe 4.0 speeds with an 11th Gen CPU and at PCIe 3.0 speeds with a 10th Gen CPU. The second x16-size slot is wired for PCIe 3.0 x4.
