Black dual-fan ASUS PRIME Radeon RX 9060 XT graphics card with silver backplate

ASUS

ASUS PRIME Radeon RX 9060 XT 16GB graphics card

SKU CH-3EA2-1TFFX

16 GB GDDR6 memory on a 128-bit bus with 2048 stream processors and PCI Express 5.0 x16 for 1440p and entry-level 4K gaming

  • InterfacePCI Express 5.0 x16
  • Chipset ManufacturerAMD
  • GPU SeriesAMD Radeon RX 9000 Series
  • GPURadeon RX 9060 XT
  • ArchitectureRDNA 4
  • Stream Processors2048
  • 16 GB GDDR6 memory gives headroom for high-resolution textures
  • 128-bit bus with 20 Gbps effective clock feeds the GPU quickly
  • 2048 stream processors handle parallel workloads efficiently
  • PCI Express 5.0 x16 link doubles bandwidth over the previous standard
  • HDMI 2.1b and dual DisplayPort 2.1a drive up to 7680 x 4320 resolution

16GB RDNA 4 graphics card

The ASUS PRIME Radeon RX 9060 XT ships with 16GB of GDDR6 memory on a 128-bit bus running at 20 Gbps. It uses the RDNA 4 architecture and provides 2048 stream processors for 1440p gaming workloads. A PCI Express 5.0 x16 interface connects the card to the platform.

Upgrade from 8GB or 12GB models

Moving to 16GB removes the frame-buffer ceiling that forces texture streaming compromises in modern titles. The extra capacity matters when ray-tracing assets or high-resolution texture packs exceed smaller buffers. PCIe 5.0 bandwidth also reduces transfer stalls on compatible motherboards.

1440p high-refresh comfort zone

The 16GB frame buffer and 20 Gbps memory speed handle 1440p ultra settings in current releases with headroom for ray-tracing. 4K gaming is possible with quality presets lowered or upscaling enabled. DisplayPort 2.1a and HDMI 2.1b outputs drive 7680 x 4320 resolution at high refresh rates.

Highlights

  • 16 GB GDDR6 memory gives headroom for high-resolution textures
  • 128-bit bus with 20 Gbps effective clock feeds the GPU quickly
  • 2048 stream processors handle parallel workloads efficiently
  • PCI Express 5.0 x16 link doubles bandwidth over the previous standard
  • HDMI 2.1b and dual DisplayPort 2.1a drive up to 7680 x 4320 resolution

Specifications

BrandASUS
SeriesPRIME
ModelPRIME-RX9060XT-O16G
InterfacePCI Express 5.0 x16
Chipset ManufacturerAMD
GPU SeriesAMD Radeon RX 9000 Series
GPURadeon RX 9060 XT
ArchitectureRDNA 4
Stream Processors2048
Effective Memory Clock20 Gbps
Memory Size16GB
Memory Interface128-Bit
Memory TypeGDDR6
DirectXDirectX 12 Ultimate
OpenGLOpenGL 4.6
Multi-Monitor Support3
HDMI1 x HDMI 2.1b
DisplayPort2 x DisplayPort 2.1a
ColorBlack
Max Resolution7680 x 4320
CrossFireX SupportNo
SLI SupportNo
Virtual Reality ReadyYes
CoolerTriple Fans
Recommended PSU Wattage550W
Power Connector8-Pin
HDCP ReadyYes
Form FactorATX
Max GPU Length304 mm
Card Dimensions (L x H)304 x 126 x 50mm
Slot Width2.5 Slots
Package Contents1 x Thank you card
1 x Speedsetup Manual

Questions about this item

How many PCIe 5.0 x16 slots does the ASUS PRIME Radeon RX 9060 XT 16GB occupy in an ATX case?

The card uses a single PCI Express 5.0 x16 slot. Verify your motherboard has one free x16 slot and that the case length clearance matches the card dimensions.

Which power connectors must be attached during installation of the PRIME-RX9060XT-O16G?

Connect the required 8-pin or 12VHPWR power cables from the PSU to the card before securing the bracket; missing this step prevents the GPU from posting.

When should the thermal paste on the Radeon RX 9060 XT be replaced?

Reapply thermal compound only if temperatures rise unexpectedly after several years; otherwise the factory paste on the 2048 stream-processor GPU remains effective.
