Green rectangular ATX motherboard with silver CPU socket, four black memory slots, grey SATA ports and black expansion slots

ASUS

ASUS PRIME Z270-P Intel motherboard

SKU CH-AJXQ-3AYWB

ATX Intel Z270 board with LGA 1151 socket, four DDR4 slots up to 64 GB, dual M.2, four SATA 6 Gb/s ports, one PCIe 3.0 x16 plus a second at x4, four PCIe x1, Realtek ALC887 8-channel audio.

  • CPU Socket TypeLGA 1151
  • CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1151)
  • Supported CPU TechnologiesTurbo Boost Technology 2.0 / * Not Compatible with Intel 8th
  • ChipsetIntel Z270
  • Number of Memory Slots4x288pin (DDR4)
  • Memory StandardDDR4 3866(O.C.)/ 3733(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.
  • Supports up to 64GB DDR4 memory for demanding workloads
  • Dual M.2 sockets accept 2242, 2260 and 2280 drives
  • HDMI 1.4b output reaches 4096 x 2160 at 24Hz
  • Realtek ALC887 codec delivers 8-channel high-definition audio
  • Intel Z270 chipset enables CPU overclocking on LGA 1151 socket

LGA 1151 Z270 ATX motherboard

The ASUS PRIME Z270-P is an ATX Intel motherboard built around the Z270 chipset for LGA 1151 processors. It accepts Core i7, i5, i3, Pentium and Celeron CPUs with Turbo Boost 2.0 support. Four 288-pin DDR4 slots provide dual-channel memory up to 64 GB and speeds ranging from 2133 to 3866 MHz when overclocked.

Builders needing 64 GB dual-channel DDR4

This board suits builders who want up to 64 GB of dual-channel DDR4 and two M.2 sockets that accept 2242, 2260 and 2280 drives in either SATA or PCIe x4 modes. It is not compatible with Intel 8th Gen CPUs, so anyone planning a Coffee Lake upgrade should look at a 300-series chipset instead.

Two M.2 sockets share bandwidth with SATA_1

The two M.2 Socket 3 slots add fast storage options, but installing a SATA-mode drive in the M.2_1 socket disables the SATA_1 port. Rear I/O includes HDMI 1.4b for 4096 x 2160 at 24 Hz or 2560 x 1600 at 60 Hz, DVI-D at 1920 x 1200 at 60 Hz, four USB 3.0 ports, two USB 2.0 ports and dual PS/2 connectors. Realtek ALC887 8-channel audio and RTL8111H 1 Gbps LAN handle sound and networking.

Highlights

  • Supports up to 64GB DDR4 memory for demanding workloads
  • Dual M.2 sockets accept 2242, 2260 and 2280 drives
  • HDMI 1.4b output reaches 4096 x 2160 at 24Hz
  • Realtek ALC887 codec delivers 8-channel high-definition audio
  • Intel Z270 chipset enables CPU overclocking on LGA 1151 socket

Specifications

BrandASUS
ModelPRIME Z270-P
CPU Socket TypeLGA 1151
CPU TypeCore i7 / i5 / i3 / Pentium / Celeron (LGA1151)
Supported CPU TechnologiesTurbo Boost Technology 2.0 / * Not Compatible with Intel 8th Gen CPUs
ChipsetIntel Z270
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 3866(O.C.)/ 3733(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3300(O.C.)/ 3200(O.C.)/ 3000(O.C.)/ 2800(O.C.)/ 2666(O.C.)/ 2400(O.C.)/ 2133
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCIe 3.0/2.0 x16 (x16 mode) / 1 x PCIe 3.0/2.0 x16 (max at x4 mode)
PCI Express x14 x PCIe 3.0/2.0 x1
Serial ATA (SATA)4 x SATA 6Gb/s port(s), gray
M.22 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode) *1 / / *1 When a device in SATA mode is installed on the M.2_1 socket, SATA_1 port cannot be used.
SATA RAID0/1/5/10
Audio ChipsetRealtek ALC887
Audio Channels8 Channels
LAN ChipsetRealtek RTL8111H
Max LAN Speed1Gbps
Back I/O Ports1 x HDMI / 2 x PS/2 / 2 x USB 2.0/1.1 / 4 x USB 3.0
PS/21 x PS/2 keyboard (purple) / 1 x PS/2 mouse (green)
Video Ports1 x DVI-D
HDMI1 x HDMI
RJ451 x RJ45
USB 3.04 x USB 3.0 (blue) Type-A
USB 1.1/2.02 x USB 2.0
Audio Ports1 x 8-channel Audio I/O
Onboard USB2 x USB 3.0 connector(s) support(s) additional 4 USB 3.0 port(s) (19-pin) / 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
Other Connectors1 x CPU Fan connector(s) (1 x 4 -pin) / 2 x Chassis Fan connector(s) (2 x 4 -pin) / 1 x S/PDIF out header(s) / 1 x 24-pin EATX Power connector(s) / 1 x 8-pin ATX 12V Power connector(s) / 1 x Front panel audio connector(s) (AAFP) / 1 x Clear CMOS jumper(s) / 1 x System panel connector / 1 x COM port header
Form FactorATX
Power Pin24 Pin
FeaturesMulti-GPU Support: / Supports AMD CrossFireX Technology / / Special Features: / ASUS 5X Protection III: / - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage / - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges! / - ASUS Overvoltage Protection: World-class circuit-protecting power design / - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability! / - ASUS DIGI+ VRM: 7 Phase digital power design / ASUS EPU: / - EPU / ASUS Exclusive Features: / - AI Suite 3 / - Ai Charger / ASUS Quiet Thermal Solution: / - Styl
Package ContentsAccessories: / User's manual / I/O Shield / 2 x SATA 6Gb/s cable(s) / 2 x M.2 screws / 1 x SCD

Questions about this item

Will my DDR4-3200 memory run at its rated speed on this board?

Yes, DDR4-3200 is listed among the supported overclocked speeds, so the board can run it when XMP is enabled.

Can I use an 8th-generation Intel Core processor with this motherboard?

No, the specifications state the socket is not compatible with 8th-generation CPUs; it supports 6th and 7th-generation Core i7, i5, i3, Pentium and Celeron processors.

How many SATA 6Gb/s drives can I connect if I also use an M.2 SATA SSD in the first slot?

You can connect three SATA drives because installing a SATA-mode M.2 device in the first M.2 socket disables the first SATA port.
