Green Micro-ATX board with silver LGA 1851 socket, two black DDR5 slots and a single PCIe 5.0 x16 SafeSlot

ASUS

ASUS PRO H810M-CT-CSM Intel H810 motherboard

SKU CH-YR86-ACZA3

Micro-ATX board for Intel Core Ultra Series 2 CPUs, DDR5 to 6400 MT/s, PCIe 5.0 x16, four SATA 6Gb/s ports, one M.2 PCIe 4.0 x4 slot, 1 GbE LAN and Realtek 7.1 audio

  • CPU Socket TypeLGA 1851
  • CPU TypeIntel Core Ultra Processors (Series 2)
  • ChipsetIntel H810
  • Number of Memory Slots2x288pin (DDR5)
  • Memory StandardSupports up to 6400MT/s
  • Maximum Memory Supported128GB
  • Ready for Intel Core Ultra Series 2 processors with LGA 1851 socket
  • Dual-channel DDR5 memory up to 6400 MT/s and 128 GB capacity
  • PCIe 5.0 x16 SafeSlot plus PCIe 4.0 x4 M.2 for high-speed expansion
  • Realtek 7.1 surround audio with 24-bit 192 kHz playback
  • Intel I219-V 1 Gbps LAN with ASUS Control Center Express management

LGA 1851 Intel H810 Motherboard

The ASUS PRO H810M-CT-CSM is a Micro-ATX board built around the Intel H810 chipset for LGA 1851 Core Ultra Series 2 processors. It targets business deployments that need a stable supply chain and simplified fleet management. ASUS CSM programme backing adds end-of-life notices and dedicated IT software tools.

IT-managed fleets, not enthusiast builds

This motherboard suits organisations that value ASUS Control Center Express for remote monitoring and a self-recovering BIOS with TPM 2.0 for baseline security. Builders who need multiple M.2 slots, PCIe 5.0 storage, or overclocking headroom should look at higher-tier chipsets instead.

Single PCIe 5.0 x16 SafeSlot

The board provides one PCIe 5.0 x16 SafeSlot for a discrete graphics card or accelerator. A second PCIe 4.0 x16 slot operates at x1 speed, and one PCIe 4.0 x1 slot rounds out expansion. Storage connects through four SATA 6Gb/s ports and one M.2 socket limited to PCIe 4.0 x4.

Highlights

  • Ready for Intel Core Ultra Series 2 processors with LGA 1851 socket
  • Dual-channel DDR5 memory up to 6400 MT/s and 128 GB capacity
  • PCIe 5.0 x16 SafeSlot plus PCIe 4.0 x4 M.2 for high-speed expansion
  • Realtek 7.1 surround audio with 24-bit 192 kHz playback
  • Intel I219-V 1 Gbps LAN with ASUS Control Center Express management

Specifications

BrandASUS
ModelPRO H810M-CT-CSM
Part Number90MB1MMM-MVAAYC
CPU Socket TypeLGA 1851
CPU TypeIntel Core Ultra Processors (Series 2)
ChipsetIntel H810
Number of Memory Slots2x288pin (DDR5)
Memory StandardSupports up to 6400MT/s
Maximum Memory Supported128GB
Channel SupportedDual Channel
Memory Performance ProfileIntel XMP 3.0
Memory FeatureSupports up to 6400MT/s, Non-ECC, Un-buffered, Clocked Unbuffered DIMM (CUDIMM)
Dual channel memory architecture
DIMM Fit
Supports Intel Extreme Memory Profile (XMP) memory module
ASUS Enhanced Memory Profile II (AEMP II)
PCI Express 5.0 x161 x PCIe 5.0 x16 SafeSlot
PCI Express 4.0 x161 x PCIe 4.0 x16 slot (supports x1 mode)
PCI Express x11 x PCIe 4.0 x1 slot
Serial ATA (SATA)4 x SATA 6Gb/s
M.21 x M.2 (Support PCIe 4.0 x4)
Audio ChannelsRealtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
LAN ChipsetIntel I219-V
Max LAN Speed1Gbps
Wireless LANM.2 slot only 2230 (Key E, CNVi & PCIe)
* Wi-Fi module is sold separately.
Back I/O Ports2 x USB 10Gbps ports (2 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
2 x DisplayPort
1 x HDMI port
1 x Intel 1Gb Ethernet port
3 x Audio jacks
1 x COM port
1 x PS/2 keyboard/mouse combo port
Onboard USB1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
3 x USB 2.0 headers support 6 additional USB 2.0 ports
Other ConnectorsFan and Cooling Related
1 x 4-pin CPU Fan header
2 x 4-pin Chassis Fan headers
Miscellaneous
1 x Clear CMOS header
1 x Chassis Intrusion header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x COM Debug header
1 x LPT header
1 x Mono-Out Audio header (with Amp IC)
1 x M.2 slot (Key E)
1 x SMBUS header
1 x Speaker header
1 x SPI header (14-5 pin)
1 x 10-1 pin Front Panel System header
BIOS Feature256 (128+128) Mb Flash ROM, UEFI AMI BIOS
SoftwareASUS Exclusive Software
ASUS DriverHub
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash
- ASUS MyHotkey
Windows 11Windows 11 (22H2 & later), Windows 10 64-bit (21H2 & later)
Form FactorMicro ATX
Dimensions (W x L)9.6" x 8.75"
Power Pin1 x 24-pin Main Power connector
1 x 8-pin +12V CPU Power connector
FeaturesASUS Q-Design
- Q-LED Core
- Q-Slot
ASUS Thermal Solution
- Aluminum heatsink design
ASUS EZ DIY
- Box headers
- Dual DIMM clips
- SafeSlot
Bespoke Motherboard Design & Business Focused Features
- ASUS Self-Recovering BIOS
- ASUS Event Log
- ASUS Commercial BIOS Kit*
- Anti-moisture coating
- BIOS EZ Deploy
- 24/7 reliability
- Overcurrent protection
TXT support
TPM IC onboard
* Please contact local FAE for Commercial BIOS kit.
Package ContentsCables
2 x SATA 6Gb/s cables
Miscellaneous
1 x I/O shield
1 x M.2 anchor package
1 x Screw package for M.2 Key E
Documentation
1 x ACC Express activation key card
1 x Quick start guide

Questions about this item

What case and cooler clearance does the Micro-ATX board need?

The board uses the Micro-ATX form factor and fits standard Micro-ATX or larger cases. The LGA 1851 socket follows the Intel mounting pattern for compatible coolers.

Which step is often missed when seating the DDR5 CUDIMM modules?

Align the notch on each 288-pin DDR5 CUDIMM with the slot key, press down firmly until both side clips click, and enable the XMP 3.0 or AEMP II profile in BIOS to reach 6400MT/s.

When will the M.2 slot or SATA ports need attention later?

The single M.2 slot supports PCIe 4.0 x4 drives and the four SATA 6Gb/s ports accept standard SATA SSDs or HDDs; replace or add drives when capacity or speed requirements change.
