Dark green Micro-ATX board with black heatsinks and silver I/O shield

ASUS

ASUS ROG STRIX B360-G GAMING Intel motherboard

SKU CH-ERHB-T1V0A

Micro-ATX board for 8th generation Intel Core CPUs with dual M.2 slots, USB 3.1 Gen2 and Intel Optane Memory support

  • CPU Socket TypeLGA 1151 (300 Series)
  • CPU Type8th generation Intel Core processors* Not backward compatibl
  • Supported CPU TechnologiesTurbo Boost Technology 2.0* Intel Turbo Boost Technology 2.0
  • ChipsetIntel B360
  • Onboard Video ChipsetIntegrated Graphics Processor - Intel HD Graphics support Mu
  • Number of Memory Slots4x288pin (DDR4)
  • Supports 8th Gen Intel Core CPUs via LGA 1151 socket
  • Dual M.2 slots enable NVMe and SATA storage up to 2280
  • DDR4 memory up to 2666 MHz with OptiMem trace isolation
  • SupremeFX S1220A audio and Intel I219-V 1Gbps LAN
  • FanXpert 4 Core and pre-mounted I/O shield simplify build and cooling

LGA 1151 300 Series Micro-ATX Motherboard

This micro-ATX motherboard uses the Intel B360 chipset and an LGA 1151 socket limited to 300 series. It accepts 8th generation Intel Core processors and four DDR4 DIMMs up to 64 GB total. Dual-channel memory runs at 2666 2400 or 2133 MT/s depending on the CPU installed.

Builders Who Need 8th Gen Support Only

The board suits builders upgrading to an 8th generation Intel Core CPU on a compact micro-ATX form factor. It provides dual M.2 slots, six SATA 6 Gb/s ports and a single PCIe 3.0 x16 SafeSlot. Anyone requiring 6th or 7th generation CPU compatibility or more than one full-length PCIe x16 slot should choose a different platform.

Single PCIe 3.0 x16 SafeSlot

Only one PCIe 3.0 x16 SafeSlot operates at full x16 electrical width; the second x16-sized slot is wired for x4 mode. This constraint decides whether the board can host a single high-end graphics card or a multi-GPU configuration. The two M.2 sockets support 2242 2260 and 2280 drives in both SATA and PCIe 3.0 modes.

Highlights

  • Supports 8th Gen Intel Core CPUs via LGA 1151 socket
  • Dual M.2 slots enable NVMe and SATA storage up to 2280
  • DDR4 memory up to 2666 MHz with OptiMem trace isolation
  • SupremeFX S1220A audio and Intel I219-V 1Gbps LAN
  • FanXpert 4 Core and pre-mounted I/O shield simplify build and cooling

Specifications

BrandASUS
SeriesROG
ModelSTRIX B360-G GAMING
CPU Socket TypeLGA 1151 (300 Series)
CPU Type8th generation Intel Core processors* Not backward compatible with older generation of LGA 1151 CPUs
Supported CPU TechnologiesTurbo Boost Technology 2.0* Intel Turbo Boost Technology 2.0 support depends on the CPU types
ChipsetIntel B360
Onboard Video ChipsetIntegrated Graphics Processor - Intel HD Graphics support Multi-VGA output support: HDMI/DVI ports - Supports DVI with max. resolution 1920 x 1200 @ 60Hz - Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 30Hz Maximum shared memory of 1024MB
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 2666/ 2400/ 2133 * Due to Intel chipset limitation, DDR4 2666MHz memory frequency is only supported by 8th Generation Intel 6-core processors. Higher memory modules will run at the maximum transfer rate of DDR4 2666MHz.
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCIe 3.0 x16 Safeslot 1 x PCIe 3.0 x16 slot (max. at x4 mode)
PCI Express x12 x PCIe 3.0 x1 slots
Serial ATA (SATA)6 x SATA 6Gb/s
M.21 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x2 modes) 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x4 mode)
Intel Optane ReadyYes
Audio ChipsetROG SupremeFX S1220A Codec
LAN ChipsetIntel I219-V
Max LAN Speed1Gbps
Back I/O Ports1 x HDMI / 1 x Optical S/PDIF Out / 1 x PS/2 Keyboard/Mouse Combo / 2 x USB 2.0/1.1 / 4 x USB 3.1 Gen 2 Type-A
PS/21 x PS/2 keyboard/mouse port
Video Ports1 x DVI
HDMI1 x HDMI 1.4b
RJ451 x RJ45
USB 3.12 x USB 3.1 Gen 2 ports (2 x Type-A [Red]) 2 x USB 3.1 Gen 1 ports
USB 1.1/2.02 x USB 2.0
S/PDIF Out1 x Optical
Audio Ports5 x Gold-plated audio jacks
Onboard USB1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
Other Connectors1 x AAFP connector(s) 1 x 4-pin RGB Header(s) 1 x TPM connector(s) 1 x COM port(s) connector(s) 1 x AIO_Pump connector(s) (4-pin) 1 x CPU Fan connector(s) (4-pin) 2 x Chassis Fan connector(s) (4-pin) 1 x Clear CMOS jumper(s) 1 x System panel connector(s)
Form FactorMicro ATX
LED LightingRGB
Dimensions (W x L)9.6" x 9.6"
Power Pin1 x 8-pin EATX 12V Power connector(s) 1 x 24-pin EATX Power connector(s)
FeaturesMulti-GPU Support:Supports AMD 2-Way CrossFireX TechnologySpecial Features:Gamer's Guardian: - ESD Guards on LAN, Audio, KBMS and USB3.0/2.0 ports - DRAM Overcurrent Protection - Stainless Steel Back I/O - Highly Durable Components - DIGI+ VRM - SafeSlot GPU Boost ASUS Exclusive Features: - AI Suite 3 - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface - ASUS Aura lighting controlASUS EZ DIY: - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS MyLogo ASUS Q-Design: - ASUS Q-Slot - ASUS Q-DIMM Pre-mounted I/O Shield Fan Xpert 4 CORE BIOS:1 x 128MB Flash ROM, UEFI AMI BIOS
Package ContentsAccessories:User's manual 1 x (2-in-1) SATA 6Gb/s cable(s) 1 x M.2 Screw Package 1 x Supporting DVD 1 x ROG Strix Door Hanger 1 x ROG Strix stickers 1 x CABLE TIE BLACK

Questions about this item

Will this board accept a 7th generation Intel processor?

No, the LGA 1151 (300 Series) socket is designed exclusively for 8th generation Intel Core processors and is not backward compatible with older generations.

What memory speeds can I run with an 8th generation 6-core CPU?

DDR4 2666 MHz is supported with 8th generation 6-core processors; other CPUs will run memory at up to 2400 MHz or 2133 MHz depending on the specific processor installed.

Can I install two NVMe SSDs on this motherboard?

Yes, there are two M.2 sockets: one supports PCIe 3.0 x4 and the other PCIe 3.0 x2 (also SATA), allowing two NVMe drives simultaneously.
