Micro ATX board in dark finish with reinforced PCIe slot and four DDR5 slots

ASUS

ASUS ROG STRIX B760-G GAMING WIFI Intel motherboard

SKU CH-6WDQ-3ZF0C

A Micro ATX Intel B760 motherboard for 12th, 13th and 14th generation Core, Pentium Gold and Celeron processors with dual-channel DDR5 up to 192GB, PCIe 5.0 x16, 2.5Gb Ethernet.

  • CPU Socket TypeLGA 1700
  • CPU TypeApplicable to Intel Core, 14th and 13th generation processor
  • ChipsetIntel B760
  • Memory StandardSupports dual-channel DDR5 7800 + (OC)/7600 (OC)/7400 (OC)/7
  • Maximum Memory Supported192GB
  • PCI SlotsIntel 14th, 13th, and 12th generation processors 1 PCIe 5.0
  • Supports 12th, 13th, 14th gen Intel Core, Pentium Gold, Celeron processors via LGA 1700 socket
  • Dual-channel DDR5 memory up to 192GB capacity with speeds from 4800 to 7800 MHz
  • PCIe 5.0 x16 and PCIe 4.0 slots for high-speed graphics and expansion cards
  • Intel 2.5Gb Ethernet with LANGuard for reliable wired networking
  • ROG SupremeFX 7.1 channel audio with S1220A codec delivering 120 dB SNR

Socket and CPU Support

This Intel LGA 1700 motherboard accepts 12th, 13th and 14th generation Core processors plus Pentium Gold and Celeron models. It is built on the B760 chipset and uses a Micro ATX form factor measuring 24.4 by 24.4 centimetres. The board targets gamers and builders who want a compact platform with ROG feature set.

Memory and Expansion Checks

Verify that your DDR5 modules match the supported speeds from 4800 up to 7800 MT/s and that total capacity does not exceed 192 gigabytes across four slots. Confirm your chassis can fit a Micro ATX board and that the single PCIe 5.0 x16 slot, one PCIe 4.0 x16 slot running at x4 and two PCIe 4.0 x1 slots meet your add-in card plans. Check the two M.2 interfaces and four SATA ports against your storage devices.

Thermals Noise and Power

The voltage regulator uses a 16 plus one plus two phase design with heatsinks to handle sustained loads from high-end CPUs. M.2 slots include thermal shields to limit throttle during long transfers. The SupremeFX S1220A codec delivers 120 decibel signal-to-noise ratio for clean audio. Intel 2.5 gigabit Ethernet and LANGuard provide wired networking with surge protection.

Highlights

  • Supports 12th, 13th, 14th gen Intel Core, Pentium Gold, Celeron processors via LGA 1700 socket
  • Dual-channel DDR5 memory up to 192GB capacity with speeds from 4800 to 7800 MHz
  • PCIe 5.0 x16 and PCIe 4.0 slots for high-speed graphics and expansion cards
  • Intel 2.5Gb Ethernet with LANGuard for reliable wired networking
  • ROG SupremeFX 7.1 channel audio with S1220A codec delivering 120 dB SNR

Specifications

BrandASUS
SeriesASUS ROG STRIX B760-G GAMING WIFI
ModelASUS ROG STRIX B760-G GAMING WIFI
CPU Socket TypeLGA 1700
CPU TypeApplicable to Intel Core, 14th and 13th generation processors, Intel Core, 12th generation, Pentium Gold and Celeron processors
The Intel slot LGA1700 supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 *
ChipsetIntel B760
Memory StandardSupports dual-channel DDR5
7800 + (OC)/7600 (OC)/7400 (OC)/7200 (OC)/7000 (OC)/6800 (OC)/6600 (OC)/6400 (OC)/6200 (OC)/6000 (OC)/5800 (OC)/5600/5400/5200/5000/4800MHz Non-EC Memory
Maximum Memory Supported192GB
PCI SlotsIntel 14th, 13th, and 12th generation processors
1 PCIe 5.0 x16 slot Intel
B760 chipset
1 PCIe 4.0 x16 slot (supports x4 mode)
2 PCIe 4.0 x1 slots
SATA RAID2XM.2 interface, 4xSATA III interface
Audio ChipsetROG SupremeFX 7.1 channel height
Fidelity Audio Codec S1220A
- Front and back
Impedance detection of headphone output
- Support: jack detection,
Multi-stream, front panel jack reassignment
- High-quality 120 dB SNR stereo playback
Output and 113 dB SNR recording input (line input)
- Supports playback up to 32 bit/192 kHz *
Audio characteristics
- SupremeFX shielding technology
- Savitech SV3H712 AMP
- Advanced Audio Capacitors
- Audio cover
* Due to HAD bandwidth limitations,
7.1 Surround sound audio does not support 32-bit/192 kHz.
LAN Chipset1 x Intel 2.5Gb Ethernet
ASUS LANGuard
Onboard USBRear USB (9 ports in total)
1 x USB 3.2 Gen 2x2 interface (1 x USB
Type-C)
1 x USB 3.2 Gen 2 interface (1 x Type-A)
3X USB 3.2 Gen 1 interface (2 x Type-A, 1 x
USB Type-C)
4 x USB 2.0 ports (4 x Type-A)
Front USB (7 ports in total)
1 x USB 3.2 Gen 2 interface (supports USB)
Type-C)
1 x USB 3.2 Gen 1 pin support
Additional 2 USB 3.2 Gen ports 1 port
2 USB 2.0 connectors support an additional 4
USB 2.0 ports

Questions about this item

What comes in the box and what must be purchased separately?

The package includes the motherboard, one SATA cable and the chassis I/O back panel. CPU, DDR5 memory, storage drives, graphics card, power supply and chassis are not included and must be bought separately.

Which DDR5 speed should I choose for this board?

The board supports DDR5 from 4800 MHz up to 7800 MHz when overclocked. Pick a kit that matches your budget and desired frequency; any speed in that range will work at its rated or default JEDEC setting.

What does the 2.5 Gb Ethernet port deliver in practice?

The onboard Intel 2.5Gb Ethernet controller provides up to 2.5 Gbps wired throughput, so large file transfers and low-latency gaming benefit from the higher bandwidth over standard 1 Gb connections.
