ATX motherboard with large silver VRM heatsinks and black PCB

ASUS

ASUS ROG STRIX X670E-F GAMING WIFI AMD X670 ATX AM5 DDR5 PCIe 5.0 NVMe M.2 backplate USB 3.2 Gen 2x2

SKU CH-Y0WE-Q2GZZ

Supports AMD Ryzen 7000, 8000 and 9000 series CPUs with 18+2 power stages, DDR5 memory, PCIe 5.0 NVMe M.2 slot with backplate and USB 3.2 Gen 2x2

  • CPU Socket TypeAM5
  • Ready for AMD Ryzen 7000, 8000 and 9000 series CPUs with AM5 socket
  • 18+2 teamed power stages and dual 8-pin ProCool II connectors deliver stable multi-core power
  • Massive VRM heatsinks, heatpipe, M.2 combo-sink and backplate keep PCIe 5.0 SSD cool
  • Dynamic OC Switcher, Core Flex and PBO Enhancement enable flexible overclocking
  • USB 3.2 Gen 2x2 provides high-speed peripheral connectivity

Ready for Ryzen 7000, 8000 and 9000 Series

This AM5 motherboard targets enthusiasts building high-end AMD systems. It supports DDR5 memory and PCIe 5.0 NVMe storage for modern workloads. The board suits gamers and creators who need strong multi-core performance.

18+2 power stages with ProCool II connectors

Teamed power stages and dual 8-pin connectors deliver stable current to multi-core CPUs. Massive VRM heatsinks, an integrated aluminium I/O cover and an L-shaped heatpipe dissipate heat efficiently. An M.2 backplate and three onboard M.2 heatsinks keep PCIe 5.0 drives cool during sustained transfers.

Dynamic OC Switcher and Core Flex included

These overclocking technologies let users tune performance per core or switch profiles automatically. AI Cooling II manages fan speeds based on system load. Builders who do not need advanced per-core tuning or extensive RGB ecosystems may prefer a simpler platform.

Highlights

  • Ready for AMD Ryzen 7000, 8000 and 9000 series CPUs with AM5 socket
  • 18+2 teamed power stages and dual 8-pin ProCool II connectors deliver stable multi-core power
  • Massive VRM heatsinks, heatpipe, M.2 combo-sink and backplate keep PCIe 5.0 SSD cool
  • Dynamic OC Switcher, Core Flex and PBO Enhancement enable flexible overclocking
  • USB 3.2 Gen 2x2 provides high-speed peripheral connectivity

Specifications

CPU Socket TypeAM5

Questions about this item

Does the PCIe 5.0 M.2 slot on this X670E board cap NVMe drive speed at 5.0 x4?

The PCIe 5.0 M.2_1 slot runs at full 5.0 x4 bandwidth, so a compatible NVMe drive can reach its rated sequential throughput without interface bottleneck.

What clearance do the massive VRM heatsinks and L-shaped heatpipe need for CPU cooler mounting?

The VRM heatsinks and integrated I/O cover sit close to the AM5 socket; low-profile or offset coolers fit best, while tall tower coolers may require offset brackets to clear the heatsink fins.

How is the M.2 backplate installed on the PCIe 5.0 M.2_1 slot, and what step is often missed?

Remove the pre-fitted M.2 screw, place the drive, secure it with the standoff, then attach the backplate using its captive screws — the missed step is forgetting to peel the protective film from the backplate thermal pad before tightening.
