ASUS
ASUS ROG-THOR-1000P2-EVA-GAMING 1000 W power supply
A 1000 W fully modular ATX power supply with 80 PLUS Platinum efficiency, a 135 mm PWM fan, Cybenetics A++ noise rating, an OLED power-draw display and a full set of sleeved cables including
- TypeATX12V
- Maximum Power1000 W
- Fans1 x 135 mm
- PCI-Express Connector8 x 6+2-Pin
- SATA Power Connector12
- Max PSU Length190 mm
- Real-time power monitoring via integrated OLED display
- Near-silent operation with Cybenetics A++ noise certification
- Efficient 80 PLUS Platinum delivery at 1000 W output
- Fully modular cabling with 12 SATA and 8 PCI-E connectors
- Synchronised lighting through Aura Sync RGB integration
ROG Thor 1000 W Platinum PSU
The ASUS ROG Thor 1000 W Platinum II EVA Edition is a fully modular ATX12V power supply rated for 1000 W continuous output. It carries 80 PLUS Platinum and Cybenetics Lambda A++ certifications for high efficiency and very low noise. An integrated OLED panel shows real-time power draw, while Aura Sync addressable RGB lighting can be coordinated with other compatible components. The unit uses 100 % Japanese capacitors and ROG heatsinks on critical parts.
Installation notes and common pitfalls
Full modularity means only the required cables are fitted, reducing clutter in tight builds. The 135 mm Axial-tech fan supports a 0 dB mode that stops the fan at low loads, so silence is normal until the load rises. Builders must route the 610 mm motherboard cable, two 1000 mm CPU cables and the 675 mm PCI-E 16-pin cable carefully because lengths are fixed. The three SATA 1-to-4 cables use 120 mm spacing between connectors, which may not match every drive bay layout.
Pre-purchase checklist
Verify the case accepts a PSU up to 190 mm long, 150 mm wide and 86 mm high. Confirm the motherboard needs both 24-pin and dual 4+4-pin CPU connectors. Count graphics-card power requirements: the box provides four 1-to-1 and two 1-to-2 PCI-E 6+2-pin cables plus one 8-pin to 16-pin adapter for newer GPUs. Ensure the 100-240 V input range matches local mains voltage. Buyers who need more than 12 SATA power connectors or more than six peripheral connectors should look elsewhere.
Highlights
- Real-time power monitoring via integrated OLED display
- Near-silent operation with Cybenetics A++ noise certification
- Efficient 80 PLUS Platinum delivery at 1000 W output
- Fully modular cabling with 12 SATA and 8 PCI-E connectors
- Synchronised lighting through Aura Sync RGB integration
Specifications
| Brand | ASUS |
|---|---|
| Model | ROG-THOR-1000P2-EVA-GAMING |
| Type | ATX12V |
| Maximum Power | 1000 W |
| Fans | 1 x 135 mm |
| PCI-Express Connector | 8 x 6+2-Pin |
| SATA Power Connector | 12 |
| Max PSU Length | 190 mm |
| Modular | Full Modular |
| Energy-Efficient | 80 PLUS PLATINUM Certified |
| PSU Noise Level | Cybenetics A++ |
| Protection | OPP/OVP/UVP/SCP/OCP/OTP |
| Input Voltage | 100 - 240 V |
| Output | +3.3V@25A, +5V@25A, +12V@83A, [email protected] , +5VSB@3A |
| Connectors | MB 24/20-pin x 1 CPU 4+4-pin x 2 PCI-E 16-pin x 1 PCI-E 6+2-pin x 8 SATA x 12 Peripheral x 6 |
| Dimensions | PSU Size (mm): 190 x 150x 86 mm Color Box (mm): 339 x 287 x 135 mm |
| Weight | Single PSU (KG): 2.35KG Product Weight (KG) (with packing): 4.9KG |
| Package Content | Power Cord x 1 Motherboard Power Cable x 1 (610mm) CPU Cable x 2 (1000mm) PCI-E 8pin/8pin to 16pin Cable x 1 (675mm) PCI-E 1-to-1 Cable x 4 (675mm) PCI-E 1-to-2 Cable x 2 (675+75mm) SATA 1-to-4 Cable x 3 (400+120+120+120mm) Peripheral 1-to-3 Cabel x 2 (450+120+120mm) Addressable RGB Cable x 1 (800mm) ROG x EVA Accessory x 1 ROG x EVA Cable Tie x 3 Cable Combs (6-pin) x 4 Cable Combs (8-pin) x 10 Cable Combs (24-pin) x 2 Chassis Screws Package x 1 User Manual x 1 |
| Shipping weight | 4.90 kg |
| Package size | 330 × 254 × 140 mm |
Questions about this item
Will this PSU fit in a case that only accepts units up to 190 mm long?
Yes, the PSU body is exactly 190 mm deep, 150 mm wide and 86 mm tall, so it matches that limit.
Does the box include a native 12VHPWR cable for a modern graphics card?
Yes, a PCI-E 8-pin to 16-pin cable measuring 675 mm is supplied.
Can I run the fan completely silently at low load?
The 135 mm PWM fan supports a 0 dB mode that stops the fan entirely under light loads.
