White ATX power supply with EVA themed accents and side OLED display

ASUS

ASUS ROG Thor 1000W Platinum II EVA Edition 90YE00L3-B0AA00 power supply

SKU CH-BZJ6-Y68RT MPN 90YE00L3-B0AA00

A fully modular 1000 W ATX power supply with 80 PLUS Platinum efficiency, 190 mm length, eight PCI-E connectors, twelve SATA ports and addressable RGB lighting

  • TypeATX12V
  • Maximum Power1000 W
  • Max PSU Length190 mm
  • Energy-Efficient80 PLUS PLATINUM Certified
  • ConnectorsMB 24/20-pin x 1 CPU 4+4-pin x 2 PCI-E 6+2-pin x 8 SATA x 12
  • Cable SpecPower Cord x 1 Motherboard Power Cable x 1 CPU Cable x 2 PCI
  • 1000 W output powers demanding builds
  • 80 PLUS PLATINUM certification reduces energy waste
  • Fully modular cables simplify installation and airflow
  • Eight PCI-E 6+2-pin connectors support multi-GPU setups
  • Addressable RGB cable enables synchronised lighting control

1000W Platinum ATX PSU

The ASUS ROG Thor 1000W Platinum II EVA Edition is a fully modular ATX12V power supply rated for 1000 W maximum output. It carries 80 PLUS PLATINUM certification for high energy efficiency. The unit measures 190 mm in length and includes addressable RGB lighting integration. It targets enthusiasts building high-performance systems who value cable management flexibility and aesthetic coordination.

Capacity and headroom

The 1000 W rating delivers substantial headroom for multi-GPU configurations and heavily overclocked processors. Eight PCI-E 6+2-pin connectors support up to four graphics cards using 1-to-1 cables or two cards using 1-to-2 cables. Twelve SATA and six peripheral connectors accommodate extensive storage arrays and accessories. Builds requiring more than 1000 W or additional PCI-E connectors beyond the eight provided will exceed this unit's capabilities.

Build integration

Fully modular cabling lets builders install only the necessary leads, reducing clutter inside the chassis. Included cable combs for 24-pin, 8-pin and 6-pin connectors enforce clean routing. The addressable RGB cable synchronises lighting with compatible motherboards. An EVA-themed accessory and cable ties add visual cohesion for themed builds. The 190 mm depth requires a case with sufficient PSU clearance. No proprietary motherboard or chassis features are required beyond standard ATX mounting.

Highlights

  • 1000 W output powers demanding builds
  • 80 PLUS PLATINUM certification reduces energy waste
  • Fully modular cables simplify installation and airflow
  • Eight PCI-E 6+2-pin connectors support multi-GPU setups
  • Addressable RGB cable enables synchronised lighting control

Specifications

BrandASUS
TypeATX12V
Maximum Power1000 W
Max PSU Length190 mm
Energy-Efficient80 PLUS PLATINUM Certified
ConnectorsMB 24/20-pin x 1
CPU 4+4-pin x 2
PCI-E 6+2-pin x 8
SATA x 12
Peripheral x 6
Cable SpecPower Cord x 1
Motherboard Power Cable x 1
CPU Cable x 2
PCI-E Cable 1-to-1 x 4
PCI-E Cable 1-to-2 x 2
SATA Cable 1-to-4 x 3
Peripheral 1-to-3 x 2
Addressable RGB Cable x 1
Package ContentROG x EVA Accessory x 1
ROG x EVA Cable Tie x 3
Cable Combs (6-pin) x 4
Cable Combs (8-pin) x 10
Cable Combs (24-pin) x 2
Chassis Screws Package x 1
User Manual x 1
Shipping weight4.90 kg
Package size343 × 287 × 140 mm

Questions about this item

Will the 190 mm length fit in my older ATX case?

The unit is 190 mm long, so measure your case clearance before installing.

How can I verify the 80 PLUS PLATINUM efficiency is active?

The certification badge on the label confirms 80 PLUS PLATINUM rating; monitor software can log real-time efficiency.

Which cables and accessories ship with the PSU?

Box includes power cord, motherboard cable, two CPU cables, four 1-to-1 and two 1-to-2 PCI-E cables, three 1-to-4 SATA cables, two 1-to-3 peripheral cables, addressable RGB cable, four 6-pin combs, ten 8-pin combs, two 24-pin combs, three EVA cable ties, one EVA accessory, chassis screws and manual.
